How to plot visualize a Linestring over a map

Question

I have some coordinates from Lng and lat, that I combined to a Linestring.

The Linestring is made of 2 Points. From one point starting=origin and from one point ending = destination.

This is the code for the Linestring column

erg2['Linestring'] = erg2.apply(lambda x: LineString([(x['latitude_origin'], x['longitude_origin']), (x['latitude_destination'], x['longitude_destination'])]), axis = 1)

I am trying everything to plot the Linestring from origin to destination without any good results..\

You would help me out a lot!\

This is the dataframe erg2 with lng and lat and the combined Linestrings... How can I plot them over a map. The numbers in the columns of origin and destination are location ids of a city..

What would you as an experienced programmer plot. The two points with scatter or the combined Linestrings?? Following I am putting in my dataframe.head().

Usually the df has [19600 rows x 8 columns]

origin	destination	move	longitude_origin	latitude_origin
88	88	20	13.481016	52.457055
88	89	0	13.481016	52.457055
88	110	0	13.481016	52.457055
88	111	0	13.481016	52.457055
88	112	0	13.481016	52.457055
87	83	0	13.479667	52.479600

longitude_destination	latitude_destination	Linestring
13.481016	52.457055	LINESTRING (52.45705489204205 13.4810161067992...
13.504075	52.443923	LINESTRING (52.45705489204205 13.4810161067992...
13.613772	52.533194	LINESTRING (52.45705489204205 13.4810161067992...
13.586891	52.523562	LINESTRING (52.45705489204205 13.4810161067992...
13.559341	52.507418	LINESTRING (52.45705489204205 13.4810161067992...
13.481016	52.457055	LINESTRING (52.45705489204205 13.4810161067992...

I am trying out to plot the Lines with the sample code from geopandas from @RobRaymond

The result shows lines which dont make sense.. This is the output:

All the lines have this description in the hover all start at 87-... In my dataframe you see that we have origin 88 etc...

It is also important to plot the Lines depending on the movements. Since zero movements don't need to be plotted... I really hope that I am making the question clear. It is really getting above my head a bit.

Answer 1

• setup some data that are lines between points. Have used 5 random UK hospitals
• created a LineString geometry between the origin and destination
• used https://plotly.com/python/lines-on-mapbox/#lines-on-mapbox-maps-from-geopandas example to show using LineString as geometry works as per example

import requests, io, json
import geopandas as gpd
import shapely.geometry
import pandas as pd
import numpy as np
import itertools
import plotly.express as px

# get some public addressess - hospitals.  data that has GPS lat / lon
dfhos = pd.read_csv(io.StringIO(requests.get("http://media.nhschoices.nhs.uk/data/foi/Hospital.csv").text),
    sep="¬",engine="python",).loc[:, ["OrganisationName", "Latitude", "Longitude"]]

a = np.arange(len(dfhos))
np.random.shuffle(a)
# establish N links between hospitals
N = 10
df = (
    pd.DataFrame({0:a[0:N], 1:a[25:25+N]}).merge(dfhos,left_on=0,right_index=True)
    .merge(dfhos,left_on=1, right_index=True, suffixes=("_origin", "_destination"))
)

# build a geopandas data frame that has LineString between two hospitals
gdf = gpd.GeoDataFrame(
    data=df,
    geometry=df.apply(
        lambda r: shapely.geometry.LineString(
            [(r["Longitude_origin"], r["Latitude_origin"]),
             (r["Longitude_destination"], r["Latitude_destination"]) ]), axis=1)
)

# sample code https://plotly.com/python/lines-on-mapbox/#lines-on-mapbox-maps-from-geopandas
lats = []
lons = []
names = []

for feature, name in zip(gdf.geometry, gdf["OrganisationName_origin"] + " - " + gdf["OrganisationName_destination"]):
    if isinstance(feature, shapely.geometry.linestring.LineString):
        linestrings = [feature]
    elif isinstance(feature, shapely.geometry.multilinestring.MultiLineString):
        linestrings = feature.geoms
    else:
        continue
    for linestring in linestrings:
        x, y = linestring.xy
        lats = np.append(lats, y)
        lons = np.append(lons, x)
        names = np.append(names, [name]*len(y))
        lats = np.append(lats, None)
        lons = np.append(lons, None)
        names = np.append(names, None)

fig = px.line_mapbox(lat=lats, lon=lons, hover_name=names)

fig.update_layout(mapbox_style="stamen-terrain",
                  mapbox_zoom=4,
                  mapbox_center_lon=gdf.total_bounds[[0,2]].mean(),
                  mapbox_center_lat=gdf.total_bounds[[1,3]].mean(),
                  margin={"r":0,"t":0,"l":0,"b":0}
                 )

simplified version

• using dataframe of links between hospitals as sample data
• plotly documentation and labels clearly note need to delimit lines with None in arrays passed to px.line_mapbox(). construct these in a far more direct way using numpy there is no need to construct LineString, use geopnadas or shapely

# plotly takes array delimited with None between lines. Use numpy padding and shaping to generate this array
# from pair of features
def line_array(df, cols):
    return np.pad(df.loc[:,cols].values, [(0, 0), (0, 1)], constant_values=None).reshape(1,(len(df)*3))[0]


fig = px.line_mapbox(lat=line_array(df, ["Latitude_origin", "Latitude_destination"]),
                     lon=line_array(df, ["Longitude_origin", "Longitude_destination"]),
                     hover_name=line_array(df, ["OrganisationName_origin", "OrganisationName_destination"]),
)

fig.update_layout(mapbox_style="stamen-terrain",
                  mapbox_zoom=4,
                  mapbox_center_lon=df.loc[:,["Longitude_origin","Longitude_destination"]].mean().mean(),
                  mapbox_center_lat=df.loc[:,["Latitude_origin","Latitude_destination"]].mean().mean(),
                  margin={"r":0,"t":0,"l":0,"b":0}
                 )

Answer 2

Using the examples and data from the official plotly reference, I have replaced your questions and identified the issues that prevent line segments from being drawn. You need to specify a column of text that indicates the group to be set in color. So set the color to the column that is the group key in your data.

import plotly.express as px
import pandas as pd

df_airports = pd.read_csv('https://raw.githubusercontent.com/plotly/datasets/master/2011_february_us_airport_traffic.csv')
df_airports.head()

df_flight_paths = pd.read_csv('https://raw.githubusercontent.com/plotly/datasets/master/2011_february_aa_flight_paths.csv')
df_flight_paths.sort_values('cnt', ascending=False, inplace=True)

df_flight_paths = df_flight_paths.query("airport2 in ['DFW','LAX']")

df_flight_paths.head()
start_lat   start_lon   end_lat     end_lon     airline     airport1    airport2    cnt
33  33.942536   -118.408074     32.895951   -97.0372    AA  LAX     DFW     914
50  29.533694   -98.469778  32.895951   -97.0372    AA  SAT     DFW     826
44  41.979595   -87.904464  32.895951   -97.0372    AA  ORD     DFW     825
20  30.194533   -97.669872  32.895951   -97.0372    AA  AUS     DFW     820
19  33.640444   -84.426944  32.895951   -97.0372    AA  ATL     DFW     580

fig = px.line_mapbox(df_flight_paths,
                     lat="start_lat",
                     lon="start_lon",
                     color="airport2",
                     hover_name="airport1",
                     #animation_frame="time",
                     center =dict(lon=-97.0,lat=38.0),
                     zoom=3, height=600
                    )

fig.update_layout(mapbox_style="stamen-terrain",
                  mapbox_zoom=4,
                  mapbox_center_lon=-97.0,
                  mapbox_center_lat=38.0,
                  margin={"r":0,"t":0,"l":0,"b":0}
                 )

fig.show()
