Hidding toolbar for reports created using SSRS 2008 in CRM 2011

Question

I have created report in SSRS 2008 and have attached them to the dashboard. The report is displaying fine, except for the fact that about 15-20 % of the space gets occupied by SSRS menu toolbar which has options for printing/zooming etc. Is there a way for me to minimize that tool bar? I also have a parameter bar that I can hide. But it doesn't stay hidden by default. Is there a way for me to temporarily hide the parameter bar when the dashboard loads? while googling i got this link but when i add that parameter to the report which is deployed i am getting CRM error. i am not very sure on the usage of the parameter which i am trying. i am very sure some sort of mistake i am doing. i am using the url in this way:

this is my url with parameter: http://xxx3:5555/CCPFINCRM/crmreports/viewer/viewer.aspx?action=filter&helpID=Test.rdl&id=%7bEFAB0D42-2165-E111-916B-90FBA631DAFB%7d&rc:Toolbar=false

The Error Message is as follows: enter image description here

There will be a more detailed error message in your trace logs (see here for how to set tracing up: http://support.microsoft.com/kb/907490), can you post that? — BenPatterson1, Mar 08 '12 at 14:05

score 1 · Answer 1 · answered Jul 27 '12 at 04:40

Sample of working

My solution involves several steps, mostly unsupported - but it works.

Clone the existing C:\Program Files\Microsoft Dynamics CRM\CRMWeb\CRMReports\viewer\viewer.aspx to .\viewerNoToolbar.aspx

Update in viewerNoToolbar.aspx the following code to remove the Toolbar from SSRS :-

function reportLoaded()
{

if (oFrame.readyState === "complete")
{
    addToRecent();
}

to

function reportLoaded()
{

if (oFrame.readyState === "complete")
{
    addToRecent();
    var frameDoc = oFrame.contentDocument || oFrame.contentWindow.document;
    var reportViewerToolbar = frameDoc.getElementById("reportViewer_Toolbar");
    reportViewerToolbar.style.display = "none";
}

Insert a DIV to hide the existing CRM toolbar and move the existing resultFrame IFrame out of the DIV

</div>
<table cellspacing="0" cellpadding="0" width="100%" height="100%">

to

</div>
<div style="display: none">
    <table cellspacing="0" cellpadding="0" width="100%" height="100%">

also close it off by changing the below from

     </table>
 </body>

to (and remove the existing td block related to resultFrame)

        </table>
    </div>
    <table cellspacing="0" cellpadding="0" width="100%" height="100%">
        <tr style="height: 100%;">
            <td colspan="2" style="padding-top: 5px; padding-bottom: 10px; border-width: 2px;
                border-color: #000000">
                <div id="divResultFrame">
                    <iframe name="resultFrame" id="resultFrame" src="/_static/blank.htm" style="border: 0px;
                        margin: 0px; padding: 0px; width: 100%; height: 100%;"></iframe>
                </div>
            </td>
        </tr>
    </table>
</body>

Change your query to

http://xxx3:5555/CCPFINCRM/crmreports/viewer/viewerNoToolBar.aspx?

and don't worry about rc:Toolbar

Good luck Glenn
