Not able to save Azure Logic Apps standard workflow in VS Code after adding Scope shape

Question

This seems very simple, all I am trying is to add a scope shape in the designer of Logic App Standard VS Code and it doesn't get saved whereas without Scope it is saving the workflow. Is this a bug or am i missing something?

without Scope section just with the actions it does save, Anyone else facing this issue?

I tried with and without Scope action on the Designer.

I expected Both to save as normal whereas it doesn't.

score 0 · Answer 1 · answered Aug 11 '23 at 05:06

I have reproduced in my environment and below are my observations:

Firstly, I have faced a similar issue as you have like below and the design is not saving with scope and when i worked with VS code and Standard Logic apps before sometime, it worked correctly for me, so this may be a bug and I guess it will be updated by VS code team.

The below designing is not been saved:

enter image description here

But one the of the workaround to work with Logic apps in VS code is by using workflow.json and with the use of below code it saved my logic app and in the design i am able to see the updations:

{
    "definition": {
        "$schema": "https://schema.management.azure.com/providers/Microsoft.Logic/schemas/2016-06-01/workflowdefinition.json#",
        "actions": {
            "Scope": {
                "actions": {
                    "Compose": {
                        "inputs": "Hello Rithwik",
                        "runAfter": {},
                        "type": "Compose"
                    }
                },
                "runAfter": {},
                "type": "Scope"
            }
        },
        "contentVersion": "1.0.0.0",
        "outputs": {},
        "parameters": {},
        "triggers": {
            "manual": {
                "inputs": {
                    "schema": {}
                },
                "kind": "Http",
                "type": "Request"
            }
        }
    },
    "parameters": {}
}

Now the logic app has been saved:

enter image description here

NOTE:

As of today this is an issue(bug), so try to use code first approach rather than design first approach to play around with Logic apps in VS Code.
