I’m quite confused as to how classDef default works with Mermaid Graphs. I want a flowchart where I don’t need to add a style tag to each node. Mermaid Doc says that I should just add classDef default and it should change every node, that doesn’t has a class attached to it, to this default-settings. However, trying it out with this Diagram

flowchart LR
δ:
B:::hidden --> 0
0((q<sub>0)) -->|a|1(((q<sub>1)))
1(((q<sub>1))) -->|b| 1(((q<sub>1)))
0((q<sub>0</sub>)) -->|a| 2(((q<sub>2)))
2(((q<sub>2))) -->|c| 2(((q<sub>2)))
classDef default stroke:white

I - for some reason - only get the single circled nodes to have a white stroke, while the double-circled nodes stay transparent. Adding style stroke:white however does work.

Graph with style <node> stroke:white Result of style <node> stroke:white

Graph with classDef default stroke:white Result of classDef default

Note, I'm not using a standalone version of Mermaid but instead the integrated version of Mermaid inside Obsidian.
