I'm learning risc-v instruction set. I know that "addi sp,sp,-40" will be converted to "fd810113". But I don't know why "addi sp,sp,-32" is converted to binary code "11 01".

enter image description here

Peter Cordes
  • 328,167
  • 45
  • 605
  • 847
Chris633
  • 3
  • 1

1 Answers1

3

That is using the compressed instruction format:

C.ADDI[2:0] nzimm[5] dest[4:0] nzimm[4:0] C1[1:0]

With C.ADDI being 000, SP being register #2 and C1 being 01 it gives:

000 1 00010 00000 01 = 0001 0001 0000 0001 = 0x1101

Note that the compressed instruction only takes immediate from -32 to +31 due to having 6 bits of space which is why the other instruction with -40 is using the 32 bit format.

Jester
  • 56,577
  • 4
  • 81
  • 125
  • 3
    Side note: The `addi sp, sp, -64` instruction is translated into `c.addi16sp`. This instructions requires the immediate to be a multiple of 16, which is why `addi sp, sp, -64` can be compressed whereas `addi sp, sp, -40` can't. – Lindydancer Apr 17 '23 at 14:22
  • That's only for the case mentioned by @Lindydancer though. – Jester Apr 17 '23 at 14:44
