Excel VBA to dynamically highlight bar color based on drop down list value

Question

Edit: I want the vba code to iterate through the x values(categories) in the pivot chart and if the xvalue equals what is in cell C4 then I want it to make that bar color red. Otherwise, the bars should be blue.

This is what I have so far, but it doesnt do anything: Sub color_chart()

Dim c As Chart
Dim s As Series
Dim iPoint As Long
Dim nPoint As Long

Charts("Chart 2").Activate
Set c = ActiveChart
Set s = c.SeriesCollection(1)

nPoint = s.Points.Count
For iPoint = 1 To nPoint
    If s.XValues(iPoint) = Range("C4").Value Then
        s.Points(iPoint).Interior.Color = RGB(255, 78, 0)
    End If
Next iPoint

End Sub

More info: I am wondering if there is a way to make the color on the bar red which corresponds to the name that is chosen in the drop down list. So for example, for employee name lets say I choose Judith Blake from the drop down data validation list. I want the bar of Judith Blake in the pivot chart to be red. I want this to be done dynamically. So if I choose James Lewis for example in the drop down, the James Lewis bar becomes red and all others blue. Is this possible to do with VBA? For reference, the chart is called Chart3 and the corresponding pivot table is PivotTable2. I am new to VBA and have searched everywhere but haven't found a solution. Any help is appreciated!!

Worksheet Image

I tried a few other stack overflow solutions but none worked out

Ok the screenshot is appreciated - but this part "which *corresponds* to the name that is chosen in the drop down list." how do you see Judith corresponding to red - is there a separate list saying which names must be which colours (is this what you'er not sure about?) — JB-007, Mar 10 '23 at 06:27
No, basically whichever name is chosen in the drop down list I want to be highlighted red, and all other names to be blue. The purpose is that when a name is chosen in the drop down list, the viewer can quickly see it highlighted in the pivot chart — Shokhina Badrieva, Mar 10 '23 at 13:27
Edit: I want the vba code to iterate through the x values(categories) in the pivot chart and if the xvalue equals what is in cell C4 then I want it to make that bar color red. Otherwise, the bars should be blue. — Shokhina Badrieva, Mar 10 '23 at 14:49
When you have adequate points/rep to do so - kindly refer back to this Q/my soln below to award / deduct votes as you deem fit to assist future users as advised/recommended. If something below doesn't work for you - let me know and If I can update, will surely try/to assist etc. Cheers — JB-007, Mar 15 '23 at 02:57

JB-007 · Answer 1 · 2023-03-15T03:41:27.727

Here (read only)/screenshots refer:

In action

Key features

Single drop down list allows one to either remove or add the desired name to the 'different bar colour-series'
Multiple entries (with common names) can be dealt with using single validation drop down tool (validaiton list)
Dynamic lists (varies in length, bespoke functions that extend downt to final 'non-blank' cell (i.e. ranges need not be contiguous)

If this is what you're looking to achieve - then see link / below in more detail:

*Note: ranges B5: c12 = user input/static entries to begin wih:

Helper data: complete list, unselected and selected, formulated as follows:

complete list (cell G5, array function)

=FILTER(C5:C12,B5:B12<>"")

unselected (cell H5):

=FILTER(G5#,--NOT(ISNUMBER(MATCH(G5#,$I$5:$I$12,0))))

Named ranges:

Not critical - but for parsimony, VB etc. may reference following:

complete (name), refers to:

=Sheet1!$G$5:OFFSET(Sheet1!$G$5,MAX(FILTER(SEQUENCE(ROWS(Sheet1!$G:$G),1,-ROW(Sheet1!$G$5)+1,1),--(Sheet1!$G:$G<>""))),0)

selected, refers to:

=IF(Sheet1!$I$5="",Sheet1!$I$5,Sheet1!$I$5:OFFSET(Sheet1!$I$5,MAX(FILTER(SEQUENCE(ROWS(Sheet1!$I:$I),1,-ROW(Sheet1!$I$5)+1,1),--(Sheet1!$I:$I<>""))),0))

unselected (name), refers to:

=IF(Sheet1!$H$5="",Sheet1!$H$5,Sheet1!$H$5:OFFSET(Sheet1!$H$5,MAX(FILTER(SEQUENCE(ROWS(Sheet1!$H:$H),1,-ROW(Sheet1!$H$5)+1,1),--(Sheet1!$H:$H<>""))),0))

These are dynamic / variable length ranges (will always select down to final non-blank cell; if no populated cell in respective range, the cell where the first such entry would occur is selected)

drop-down (name), refers to:

=Sheet1!$L$4

Graph data:

Comprises col1_sel and col2_sel (colours 1/2 resp) as follows:

col1_sel

=LET(x_,IFERROR(INDEX($B$5:$B$12,MATCH($G5#,H5#,0)),""),IF(ISERROR(--x_),"",B5:B12))

col2_sel

=IF(D5#="",B5:B12,"")

VB code:

Finally: see here for how to create macro pertainin to sheet, to be executed whenever specified target range of cell(s) is altered.

Below - I include bespoke/tailored code for the case in question:

Private Sub Worksheet_Change(ByVal Target As Range)
    If (Not Intersect(Target, Range("drop_down")) Is Nothing) And (Range("drop_down").Value <> "") Then
        ActiveSheet.Calculate
        If Range("i5").Value = "" Then
            Range("i5").Value = Range("drop_down").Value
            'Range("drop_down").ClearContents
            Exit Sub
        End If
        k = 1
        For Each c In Range("selected").Cells

            If Range("drop_down").Value = c.Value Then
                c.ClearContents
                k = 0
            End If
        Next
        If k = 0 Then
            ActiveSheet.Sort.SortFields.Add2 Key:=Range("selected"), SortOn:=xlSortOnValues, Order:=xlAscending, DataOption:=xlSortNormal
            ActiveSheet.Sort.Apply

            'Range("drop_down").ClearContents
            Range("b3:i15").Calculate
            Exit Sub
        Else:
            If Range("i5").Value = "" Then
                Range("i5").Select
            Else
                Range("i4").End(xlDown).Offset(1).Select
            End If
            Selection.Value = Range("drop_down").Value
            'Range("drop_down").ClearContents
            Range("b3:i15").Calculate
        End If

    End If

End Sub

## ̿̿ ̿̿ ̿’̿’\̵͇̿̿\З= ( ▀ ͜͞ʖ▀) =Ε/̵͇̿̿/’̿’̿ ̿ ̿̿ ̿̿ ̿̿ ##

Alternatively

Within the Private Sub Worksheet_Change VBA code above, you could include something like this to cyce through the bars and colour them as req (instead of the 'hack' I provide above which relies upon two series being defined etc.

ActiveSheet.ChartObjects("Chart 2").Activate
With ActiveChart.SeriesCollection(1)
    For i = 1 To 8
        If Range("d5").Offset(i - 1).Value = "" Then
            .Points(i).Select
            With Selection.Format.Fill
                .Visible = msoTrue
                .ForeColor.RGB = RGB(255, 255, 0)
                .Solid
            End With

        Else:
            .Points(i).Select
            Selection.Format.Fill.Visible = msoTrue
        With Selection.Format.Fill
            .Visible = msoTrue
            .ForeColor.RGB = RGB(0, 112, 0)
            .Solid
        End With

        End If

    Next
End With

This still requires helper tables to identify col_1 vs _2 etc.

Pre-requsities:

Office 365 compatible Excel (similar can be achieved without, but specific functions adopted here happen to rely upon this)
