Jolt transform - how to rename field with field value?

Question

I'm wondering if there is any way to rename the field by concatenating the values of JSON attributes into existing attribute names using JOLT transformation.

Suppose we have input here:

{
  "auth_id": "0000-0000-0000",
  "read_time": "2022-01-10T00:00:00.0",
  "src_name": "REQ-A001",
  "reading_a": "150.18",
  "reading_b": "12.10",
  "reading_c": "3.00",
  "note": 1
}

What I expect is to concatenate field values from auth_id and read_time before all existing field name, with a colon (:) as separator and the result would become:

Expected:

{
  "0000-0000-0000:2022-01-10T00:00:00.0:auth_id": "0000-0000-0000-0000-0000",
  "0000-0000-0000:2022-01-10T00:00:00.0:read_time": "2022-01-10T00:00:00.0",
  "0000-0000-0000:2022-01-10T00:00:00.0:src_name": "REQ-A001",
  "0000-0000-0000:2022-01-10T00:00:00.0:reading_a": "150.18",
  "0000-0000-0000:2022-01-10T00:00:00.0:reading_b": "12.10",
  "0000-0000-0000:2022-01-10T00:00:00.0:reading_c": "3.00",
  "0000-0000-0000:2022-01-10T00:00:00.0:note": 1
}

So far I've referred to

Khusan Sharipov's question for concatenating field value
DSC's digest of JOLT documentation to clarify how the operators do their job

and come up with a JOLT spec:

[
  {
    "operation": "modify-default-beta",
    "spec": {
      // concatenate field value auth_id and read_time, while using ":" as separator
      "ukey": "=concat(@(1,auth_id),':',@(1,read_time))"
    }
  },
  {
    "operation": "shift",
    "spec": {
      "*": {
        // concatenate field values before field name
        "@": "@(2,ukey):&"
      }
    }
  }
]

But I got this output:

{
  "0000-0000-0000:2022-01-10T00:00:00.0": {
    ":auth_id": "0000-0000-0000",
    ":read_time": "2022-01-10T00:00:00.0",
    ":src_name": "REQ-A001",
    ":reading_a": "150.18",
    ":reading_b": "12.10",
    ":reading_c": "3.00",
    ":note": 1
  }
}

I expect to use the JOLT spec in the JoltTransformJSON processor in Nifi.

Any help or guidance is much appreciated!

Thank you! This community has saved my sanity crisis on the job for over five years, and though I haven't answered a question yet, I think I could give out a neat, readable question. — Linden HSU, Mar 09 '23 at 06:17

Barbaros Özhan · Answer 1 · 2023-03-08T13:58:48.283

You can use the following transformation spec

[
  {
    "operation": "modify-overwrite-beta",
    "spec": {
      "ukey": "=concat(@(1,auth_id),':',@(1,read_time),':')"
    }
  },
  {
    "operation": "shift",
    "spec": {
      "*": {
        "$": "@(0)" // reverse key-value pairs
      },
      "ukey": "&"
    }
  },
  {
    "operation": "modify-overwrite-beta",
    "spec": {
      "*": "=concat(@(1,ukey),@(1,&))"
    }
  },
  {
    "operation": "remove",
    "spec": {
      "ukey": ""
    }
  },
  {
    "operation": "shift",
    "spec": {
      "*": {
        "$": "@(0)" // reverse key-value pairs back
      }
    }
  },
  {
    "operation": "modify-overwrite-beta",
    "spec": {
      "*note": "=toInteger"
    }
  }
]

the demo1 on the site http://jolt-demo.appspot.com/ is :

the alternative option, which gives the same result , uses consecutive shift transformation specs after having used the modify transformation you already have, as follows

[
  {
    "operation": "modify-default-beta",
    "spec": {
      "ukey": "=concat(@(1,auth_id),':',@(1,read_time))"
    }
  },
  { // nest the attributes under common object with "ukey" key
    "operation": "shift",
    "spec": {
      "*": {
        "@": "@(2,ukey).&"
      }
    }
  },
  {// concatenate upper object and one level inner object keys for the attributes except for "ukey"
    "operation": "shift",
    "spec": {
      "*": {
        "*": {
          "@": "&2:&1" // concatenation
        },
        "ukey": {      // exception case
          "*": {
            "*": ""
          }
        }
      }
    }
  }
]

the demo2 on the site http://jolt-demo.appspot.com/ is :

Though in the first spec, I found that it will **merge field names into an array** on the first key-value reverse if they share the same value (such as `0`, `null` etc.), which I wasn't expecting, the second spec is highly readable and looks nice to people who weren't familiar with the wildcards. Thank you! — Linden HSU, Mar 09 '23 at 06:19
You're welcome @LindenHSU have a nice study and work! Yes, I've thought on case to make it better after the first one. Best wishes. — Barbaros Özhan, Mar 09 '23 at 06:19

Mohammadreza Khedri · Accepted Answer · 2023-03-08T20:05:53.193

You can use this shorter spec:

[
  {
    "operation": "shift",
    "spec": {
      "*": "@(1,auth_id).@(1,read_time).&"
    }
  },
  {
    "operation": "shift",
    "spec": {
      "*": {
        "*": {
          "*": "&2:&1:&"
        }
      }
    }
  }
]

Or you can use another way like below:

[
  {
    "operation": "shift",
    "spec": {
      "*": {
        "@(2,auth_id)": "keys[#2]",
        "@(2,read_time)": "keys[#2]",
        "$": "keys[#2]",
        "@": "values"
      }
    }
  },
  {
    "operation": "modify-overwrite-beta",
    "spec": {
      "keys": {
        "*": "=join(':',@0)"
      }
    }
  },
  {
    "operation": "shift",
    "spec": {
      "values": {
        "*": "@(2,keys[#1])"
      }
    }
  }
]

1, Shift operation Create keys and values separately.

2, Modify operation Concate all keys with :.

3, Shift operation Create our desired output.

Note: Please run each spec separately to understand this code better.

I didn't know using the wildcards in these specs would be this neat! I've read both specs about how the data transform from one operation to another, and wow, such a super move. Though both of you have a great answer, still, I'm accepting this one as the answer. — Linden HSU, Mar 09 '23 at 06:20
