How can I read multiple large CSVs in chunks in parallel using R?

Question

I have 10 very large CSV files (which may or may not have the same headers) that I am reading in and processing consecutively in chunks using "readr" package read_csv_chunked(). Currently, I am able to read the 10 files in parallel using 10 cores. The process still takes an hour. I have 128 cores. Can I split each CSV into 10 chunks to process in parallel for each of the files hence utilizing 100 cores? Here is what I currently have (creating two sample files only for testing):

library(doParallel)
library(foreach)

# Create a list of two sample CSV files and a filter by file
df_1 <- data.frame(matrix(sample(1:300), ncol = 3))
df_2 <- data.frame(matrix(sample(1:200), ncol = 4))
filter_by_df <- data.frame(X1 = 1:100)

write.csv(df_1, "df_1.csv", row.names = FALSE)
write.csv(df_2, "df_2.csv", row.names = FALSE)

files <- c("df_1.csv", "df_2.csv")

# Create a function to read and filter each file in chunks
my_function <-
  function(file) {
    library(dplyr)
    library(plyr)
    library(readr)

    filter_df <-
      function(x, pos) {
        subset(x, X1 %in% filter_by_df$X1 | X2 %in% filter_by_df$X1)
      }

    readr_df <-
      read_csv_chunked(file,
                       callback = DataFrameCallback$new(filter_df),
                       progress = F,
                       chunk_size = 50) %>%
      as.data.frame() %>%
      distinct()
    return(readr_df)
  }

# Apply the custom function created above to all files in parallel and combine them
df_foreach <-
  foreach(i = files, .combine = rbind.fill, .packages = c("plyr")) %dopar% my_function(i)

I am researching nested foreach() but am not sure how to pass different functions in a nested manner (read_csv_chunked with .combine = rbind and my custom function filter_df() with .combine = rbinf.fill()). I also looked into "future" package. Any advice is greatly appreciated. Thank you.

Answer 1

As mentioned by Sirius, data.table::fread() is hands down the fastest csv reader for R, and the built-in multi-threading should make good use of the resources you have at your disposal.

One other thought though - since you only want a subset of the rows in your final result, the arrow package is a great option here. Instead of reading the entire file into memory, you can use arrow's "push-down" capabilities to scan a multi-file dataset and only read the rows matching your criteria into memory.

arrow partially implements the functionality of dplyr, so depending on your experience, the syntax may already be familiar.

library(arrow)
library(dplyr)

DS <- arrow::open_dataset(sources = c("df_1.csv","df_1.csv"),
                          format = "csv")

DS |>
  filter(X1 %in% filter_by_df[["X1"]]| X2 %in% filter_by_df[["X1"]] ) |>
  distinct() |>
  collect()

One note - this answer assumes an R version of 4.1 or greater. For earlier R versions, the magrittr pipe %>% can be used in lieu of the base R pipe - |> - introduced 4.1.

Answer 2

For processing large csv files I would only ever use fread() from data.table.

One way to achieve what you want would be this:

library(data.table)
library(purrr)

# Create a list of two sample CSV files and a filter by file
set.seed(100)
df_1 <- data.frame(matrix(sample(1:300), ncol = 3))
df_2 <- data.frame(matrix(sample(1:200), ncol = 4))
filter_by_df <- data.frame(X1 = 1:100)

write.csv(df_1, "df_1.csv", row.names = FALSE)
write.csv(df_2, "df_2.csv", row.names = FALSE)

files <- c("df_1.csv", "df_2.csv")

filedata <- map(
    files,
    ~{
        d <- fread(.x)
        d[ X1 %in% filter_by_df$X1 | X2 %in% filter_by_df$X1 ]
    }
)

df_final <- rbindlist( filedata, fill=TRUE )

head( df_final )

It produces this:

> head( df_final )
    X1  X2  X3 X4
1: 206 100  54 NA
2:   4 276 144 NA
3:  98  27 205 NA
4:   7 159 134 NA
5: 146  71 180 NA
6: 258  39 176 NA

As the others have alluded to, your system most likely can parse csv faster than the storage backend can serve the csv data anyway, so parallelizing over multiple cores might not help, or would help only marginally.

Also as @Roland pointed out before I edited out my first parallellized approach, fread is already parallellized, no need to do it again.

You should go ahead and see how fast fread() can read your file, and then see if reading the same file at the same time from two different R sessions run the same speed or slower.

Answer 3

Your situation in terms of hardware and size of data seems like it is not easy to replicate for the average user here. There were already some good insights shared by others, but ultimately without access to your hardware and data, it all stay speculative.

So what you could do is to run some benchmarks to optimise your approach as different tools will work better depending on the bottleneck of your setup. So here are some tips I found useful when benchmarking.

test data

Choose a representative set of data. In your original question, the datasets/files were rather small, which creates unique challenges (e.g., parallelization creates some overhead, which might kill any gains in speed for smaller files, but on larger files you might see huge improvements as the overhead become negligible compared to the total run time). I use your test data, but increase the data size slightly the approach from the question but increase the number of data points.

df_1 <- data.frame(matrix(sample(1:30000), ncol = 3))
df_2 <- data.frame(matrix(sample(1:20000), ncol = 4))
filter_by_df <- data.frame(X1 = 1:100)

write.csv(df_1, "df_1.csv", row.names = FALSE)
write.csv(df_2, "df_2.csv", row.names = FALSE)

the functions

The benchmarking tool I recommend (bench) wants to compare different functions, so it makes sense to wrap your code into a function per approach (there are workarounds but it’s easier this way).

The original approach with furrr for parallelisation:

library(dplyr)
library(readr)
library(furrr)

filter_df <- function(x, pos) {
  subset(x, X1 %in% filter_by_df$X1 | X2 %in% filter_by_df$X1)
}

my_function <- function(files, cores) {
  plan(multisession, workers = cores)
  future_map_dfr(files, function(file) {
    suppressMessages(read_csv_chunked(file,
                                      callback = DataFrameCallback$new(filter_df),
                                      progress = FALSE,
                                      chunk_size = 50)) %>%
      as.data.frame() %>%
      distinct()
  })
}

The arrow function by Matt Summersgill.

library(arrow)

my_arrow <- function(files, cores) { # cores are ignored, just for comparability

  DS <- arrow::open_dataset(sources = files,
                            format = "csv")

  DS |>
    filter(X1 %in% filter_by_df[["X1"]]| X2 %in% filter_by_df[["X1"]] ) |>
    distinct() |>
    collect()
}

Two slightly altered versions of Sirius data.table approach:

library(data.table)
my_data_table_native <- function(files, cores) {
  setDTthreads(cores)
  df_out <- data.table::rbindlist(lapply(files, data.table::fread), fill = TRUE)[ X1 %in% filter_by_df$X1 | X2 %in% filter_by_df$X1 ]
}


my_data_table_furrr <- function(files, cores) {
  setDTthreads(cores)
  plan(multisession, workers = cores)
  future_map_dfr(files, function(file) {
    data.table::fread(file)[ X1 %in% filter_by_df$X1 | X2 %in% filter_by_df$X1 ]
  })
}

benchmarks

I recommend the excellent bench package for benchmarking as it can run your functions in a grid, produces very detailed data and makes some really nice plots for comparison. I set it up to test two things:

• what happens with different numbers of files
• what differents does paralleisation make

results <- bench::press(
  n_files = c(2, 5, 10, 25, 50, 100, 200, 1000), # test different resamplings
  n_cores = 1:4, # test different numbers of cores
  {
    bench_sample <- sample(c("df_1.csv", "df_2.csv"), n_files, replace = TRUE)
    bench::mark(
      my_function = my_function(bench_sample, n_cores),
      my_arrow = my_arrow(bench_sample, n_cores),
      my_data_table_native = my_data_table_native(bench_sample, n_cores),
      my_data_table_furrr = my_data_table_furrr(bench_sample, n_cores),
      iterations = 5L, # rerun each combination 5 times
      check = FALSE # usually bench checks if the outcome is 100% identical, but the approaches differ in insubstantial ways
    )
  }
)

If you search in a grid, the easiest way to compare results is to use a plot:

ggplot2::autoplot(results)

But you can also have a close look at the individual runs:

summary(results)

Warning: Some expressions had a GC in every iteration; so filtering is
disabled.

# A tibble: 128 × 8
   expression           n_files n_cores      min   median `itr/sec` mem_alloc
   <bch:expr>             <dbl>   <int> <bch:tm> <bch:tm>     <dbl> <bch:byt>
 1 my_function                2       1 125.47ms 125.71ms      7.46   11.79MB
 2 my_arrow                   2       1  47.39ms  50.93ms     18.3    15.85MB
 3 my_data_table_native       2       1   2.61ms   2.68ms    197.      3.21MB
 4 my_data_table_furrr        2       1  17.95ms  18.27ms     51.2     1.28MB
 5 my_function                5       1 256.08ms 256.81ms      3.87    8.11MB
 6 my_arrow                   5       1  42.06ms   43.8ms     22.2   167.66KB
 7 my_data_table_native       5       1   5.76ms   6.19ms    166.      2.51MB
 8 my_data_table_furrr        5       1  22.44ms   22.6ms     42.4     2.37MB
 9 my_function               10       1 402.88ms 409.96ms      2.44   12.06MB
10 my_arrow                  10       1  47.22ms  47.88ms     20.0   168.19KB
# … with 118 more rows, and 1 more variable: `gc/sec` <dbl>

summary(results, relative = TRUE)

Warning: Some expressions had a GC in every iteration; so filtering is
disabled.

# A tibble: 128 × 8
   expression           n_files n_cores    min median `itr/sec` mem_al…¹ gc/se…²
   <bch:expr>             <dbl>   <int>  <dbl>  <dbl>     <dbl>    <dbl>   <dbl>
 1 my_function                2       1  53.5   53.0       323.    72.2      Inf
 2 my_arrow                   2       1  20.2   21.5       791.    97.1      Inf
 3 my_data_table_native       2       1   1.11   1.13     8505.    19.7      Inf
 4 my_data_table_furrr        2       1   7.66   7.71     2216.     7.84     NaN
 5 my_function                5       1 109.   108.        168.    49.7      Inf
 6 my_arrow                   5       1  17.9   18.5       960.     1.00     Inf
 7 my_data_table_native       5       1   2.46   2.61     7166.    15.4      NaN
 8 my_data_table_furrr        5       1   9.57   9.53     1833.    14.5      Inf
 9 my_function               10       1 172.   173.        105.    73.9      Inf
10 my_arrow                  10       1  20.1   20.2       863.     1.01     Inf
# … with 118 more rows, and abbreviated variable names ¹​mem_alloc, ²​`gc/sec`

I like to look at the second one since you can quickly see, for example that my_data_table_native with two files is roughly 7 times faster than my_data_table_native.

What sticks out is that parallelisation only improves the original function when there are a lot of files involved. But parallelisation always hurts performance with data.table, likely because the workers are standing in each other’s way and the bottleneck is the disk read speed. So my conclusion would be to use the normal data.table approach for up to about 50 files of the size used here and otherwise use arrow.

However, your hardware is very different to mine. In the comments you said that parallelisation actually improves the processing speeds, which could point to a CPU bottleneck, while I seem mostly limited by the SSD read speed of my machine. Matt Summersgill also pointed out that data.table is heavy on memory usage for larger files, which could explain why your machine slows down with that generally very fast package. Ultimately you will need to run the benchmark yourself to find out.
