How can I integrate these plots by putting them near each other?

Question

I have these two plots (a heatmap and a stacked barplot). How can I put these plots near each other? Indeed I want to integrate these two plots.

Thanks for any help.

Here is my script:

df.bar <- data.frame(Gene.name=c('Gene1','Gene1','Gene1','Gene2','Gene2','Gene2','Gene3','Gene3','Gene3',
                                 'Gene4','Gene4','Gene4'),
                     Alteration.frequency=c(0.0909, 2.1838, 0.6369, 0.1819, 1.0919, 0.3639, 0.4549,0.7279,
                                            0.7279, 0.000, 0.3639, 0.4549),
                     Alteration.Type=c("Deep deletion",  "Amplification",  "Point mutation", "Deep deletion",
                                       "Amplification",  "Point mutation", "Deep deletion",  "Amplification" ,
                                       "Point mutation", "Deep deletion",  "Amplification" , "Point mutation"))


library(ggplot2)
ggplot(df.bar,
       aes(fill=factor(Alteration.Type, levels = c('Point mutation','Amplification','Deep deletion')),
           y=Alteration.frequency, x=Gene.name)) +
  geom_bar(position="stack", stat="identity")+theme_bw()+
  theme(axis.text.x = element_text(size = 10, angle = 45, hjust = 1, colour = 'black'))+
  scale_fill_manual(values=c("seagreen2", "maroon2",'deepskyblue3'))+
  labs(fill = 'Alteration type')

df.heatmap <- data.frame(Gene_name=c('Gene1','Gene2','Gene3','Gene4'),
                 log2FC=c(0.56,-1.5,-0.8,2))
library(gplots)
heatmap.2(cbind(df.heatmap$log2FC, df.heatmap$log2FC), trace="n", Colv = NA,
          dendrogram = "none", labCol = "", labRow = df$Gene_name, cexRow = 0.75,
          col=my_palette)

I need such this plot.

Allan Cameron · Accepted Answer · 2022-12-03T13:12:32.613

There are various ways to mix base R graphics like heatmap.2 and grid-based graphics like ggplot, but this case is a little more complex due to the fact that heatmap.2 seems to use multiple plotting regions. However, the following solution should do the trick:

library(gplots)
library(ggplot2)
library(patchwork)
library(gridGraphics)

p1 <- ggplot(df.bar,
       aes(fill = factor(Alteration.Type, levels = c('Point mutation',
                                                     'Amplification',
                                                     'Deep deletion')),
           y = Alteration.frequency, x = Gene.name)) +
  geom_col(position = "stack") +
  theme_bw() +
  theme(axis.text.x = element_text(size = 10, angle = 45, hjust = 1,
                                   colour = 'black')) +
  scale_fill_manual(values = c("seagreen2", "maroon2", 'deepskyblue3')) +
  labs(fill = 'Alteration type')

heatmap.2(cbind(df.heatmap$log2FC, df.heatmap$log2FC), trace = "n",
          Colv = NA, dendrogram = "none", labCol = "",
          labRow = df.heatmap$Gene_name, cexRow = 0.75,
          col = colorRampPalette(c("red", "white", "blue")))

grid.echo()
p2 <- wrap_elements(grid.grab())

p1 + p2

Edit

From the comments, it seems we want one plot on top of the other, and that the OP was using heatmap.2 because it didn't seem possible to get a single variable heatmap in ggplot.

This edit solves both these issues:

library(ggplot2)
library(patchwork)

p1 <- ggplot(df.bar,
       aes(fill = factor(Alteration.Type, levels = c('Point mutation',
                                                     'Amplification',
                                                     'Deep deletion')),
           y = Alteration.frequency, x = Gene.name)) +
  geom_col(position = "stack") +
  theme_bw() +
  theme(axis.text.x = element_blank()) +
  scale_fill_manual(values = c("seagreen2", "maroon2", 'deepskyblue3')) +
  labs(fill = 'Alteration type', x = NULL)

p2 <- ggplot(df.heatmap, aes(y = "A", x = Gene_name,
                             fill = log2FC)) +
  geom_tile() +
  scale_fill_viridis_c() +
  scale_y_discrete(NULL, position = "right") +
  scale_x_discrete(NULL, expand = c(0.17, 0.1)) +
  theme_minimal() +
  theme(axis.text.y = element_blank(),
        plot.title = element_blank())

p1 / p2 + plot_layout(height = c(3, 1))

Thanks for your reply. Actually, the thing that I need is a heatmap with a barplot at the top. Since I need a heatmap with only a column, I couldn't draw with ggplot2 or other packages. I've just found the heatmap.2 appropriate for drawing such heatmap. — zahra abdi, Dec 03 '22 at 10:20
@zahraabdi it is possible to draw your heat map in ggplot too. — Allan Cameron, Dec 03 '22 at 10:57

score 1 · Answer 2 · answered Dec 03 '22 at 10:09

Another option could be using plot_grid from the package cowplot to combine ggplot and basegraphics or other framework. For the heatmap you could use ~ and I slightly modified the size of the legend to fit it better. Here is a reproducible example:

library(ggplot2)
library(cowplot)
library(gridGraphics)
library(gplots)

# first plot
p1 <- ggplot(df.bar,
       aes(fill=factor(Alteration.Type, levels = c('Point mutation','Amplification','Deep deletion')),
           y=Alteration.frequency, x=Gene.name)) +
  geom_bar(position="stack", stat="identity")+theme_bw()+
  theme(axis.text.x = element_text(size = 10, angle = 45, hjust = 1, colour = 'black'))+
  scale_fill_manual(values=c("seagreen2", "maroon2",'deepskyblue3'))+
  labs(fill = 'Alteration type')

# Second plot
p2<- ~heatmap.2(cbind(df.heatmap$log2FC, df.heatmap$log2FC), trace="n", Colv = NA,
          dendrogram = "none", labCol = "", labRow = df.heatmap$Gene_name, cexRow = 0.75,
          col=my_palette, key.par=list(mar=c(3,0,3,0), cex.main = 0.75), keysize = 1.5)

# combine all plots together
plot_grid(p1, p2)

^{Created on 2022-12-03 with reprex v2.0.2}
