Azure traffic manager ARM template wouldn't take resourceTargetId

Question

I am trying to deploy Traffic manager profile using ARM template but when deploying I am getting the following error . I am referring the resourceid to "resourceTargetId". Also when I create the traffic manager profile from the portal it just seems to work with both deployed apps and no shows no errors.

ERROR

The 'resourceTargetId' property of endpoint 'Primarysite' is invalid or missing. The property must be specified only for the following endpoint types: AzureEndpoints, NestedEndpoints. You must have read access to the resource to which it refers.

ARM template


    {
       "$schema":"https://schema.management.azure.com/schemas/2019-04-01/deploymentTemplate.json#",
       "contentVersion":"1.0.0.0",
       "parameters":{
          "DnsName":{
             "type":"string"
          },
          "Name":{
             "type":"String"
          },
          "RoutingMethod":{
             "type":"String"
          },
          "Location":{
             "type":"String"
          }
       },
       "resources":[
          {
             "type":"Microsoft.Network/trafficmanagerprofiles",
             "apiVersion":"2018-08-01",
             "name":"[parameters('Name')]",
             "location":"[parameters('Location')]",
             "properties":{
                "profileStatus":"Enabled",
                "trafficRoutingMethod":"[parameters('RoutingMethod')]",
                "dnsConfig":{
                   "relativeName":"[parameters('DnsName')]",
                   "ttl":30
                },
                "monitorConfig":{
                   "protocol":"HTTPS",
                   "port":443,
                   "path":"/",
                   "expectedStatusCodeRanges":[
                      {
                         "min":200,
                         "max":202
                      },
                      {
                         "min":301,
                         "max":302
                      }
                   ]
                },
                "endpoints":[
                   {
                      "type":"Microsoft.Network/TrafficManagerProfiles/AzureEndpoints",
                      "name":"Primarysite",
                      "properties":{
                         "target":"https://website1.azurewebsites.net",
                         "resourceTargetId":"/subscriptions/xxxxxxxxx-xxxxx-xxxxx-xxxx-xxxxxxxxxxxxxxxx/resourceGroups/RGTest/providers/Microsoft.Web/sites/website1",
                         "endpointStatus":"Enabled",
                         "endpointLocation":"eastus"
                      }
                   },
                   {
                      "type":"Microsoft.Network/TrafficManagerProfiles/AzureEndpoints",
                      "name":"Secondarysite",
                      "properties":{
                         "target":"https://website2.azurewebsites.net",
                         "resourceTargetId":"/subscriptions/xxxxxxxxx-xxxxx-xxxxx-xxxx-xxxxxxxxxxxxxxxxx/resourceGroups/RGTest/providers/Microsoft.Web/sites/website2",
                         "endpointStatus":"Enabled",
                         "endpointLocation":"westus"
                      }
                   }
                ]
             }
          }
       ]
    }

You can export the template from a manually created traffic manager profile and compare the resulting template: https://learn.microsoft.com/en-us/azure/azure-resource-manager/templates/export-template-portal — Alex AIT, Oct 24 '22 at 20:37

score 4 · Answer 1 · answered Oct 26 '22 at 09:11

I am not sure from where you got the ARM template that is mentioned in the question. But the issue is with the name of EndpointProperties attribute in your ARM template. The attribute name should be "targetResourceId" and not "resourceTargetId".

Following are the list of supported attribute names in EndpointProperties:

customHeaders
endpointLocation
endpointMonitorStatus
endpointStatus
geoMapping
minChildEndpoints
minChildEndpointsIPv4
minChildEndpointsIPv6
priority
subnets
target
targetResourceId
weight

More info about the attributes is available in the following EndpointProperties link.

You can also find a sample traffic manager ARM template in the following official azure quickstart templates link.

score 3 · Answer 2 · edited Oct 28 '22 at 02:20

I have tried to reproduce the above one by following below steps and ,I have modified a bit in the given code

Create a .json file in vs code
Use the below code

{
  "$schema": "https://schema.management.azure.com/schemas/2019-04-01/deploymentTemplate.json#",
  "contentVersion": "1.0.0.0",
  "parameters": {
    "DnsName": {
      "type": "string"
    },
    "Name": {
      "type": "String"
    },
    "RoutingMethod": {
      "type": "String"
    },
    "Location": {
      "type": "String"
    }
  },
  "resources": [
    {
      "type": "Microsoft.Network/trafficmanagerprofiles",
      "apiVersion": "2018-08-01",
      "name": "[parameters('Name')]",
      "location": "[parameters('Location')]",
      "properties": {
        "profileStatus": "Enabled",
        "trafficRoutingMethod": "[parameters('RoutingMethod')]",
        "dnsConfig": {
          "relativeName": "[parameters('DnsName')]",
          "ttl": 30
        },
        "monitorConfig": {
          "protocol": "HTTPS",
          "port": 443,
          "path": "/",
          "expectedStatusCodeRanges": [
            {
              "min": 200,
              "max": 202
            },
            {
              "min": 301,
              "max": 302
            }
          ]
        },
        "endpoints": [
          {
            "type": "Microsoft.Network/TrafficManagerProfiles/AzureEndpoints",
            "name": "Primarysite",
            "properties": {
              "target": "URL of the app which you want to add ",
              "targetResourceId": "ResourceID of the app which you have provide the URL",
              "endpointStatus": "Enabled",
              "endpointLocation": "exact location of the app service "
            }
          },
          {
            "type": "Microsoft.Network/TrafficManagerProfiles/AzureEndpoints",
            "name": "Secondarysite",
            "properties": {
              "target": "URL of the app which you want to add",
              "targetResourceId": "ResourceID of the app which you have provide the URL",
              "endpointStatus": "Enabled",
              "endpointLocation": "exact location of the app service"
            }
          }
        ]
      }
    }
  ]
}

create a parameter.json in the same folder and use the below code

{
  "$schema": "https://schema.management.azure.com/schemas/2019-04-01/deploymentParameters.json#",
  "contentVersion": "1.0.0.0",
  "parameters": {
    "DnsName": {
      "value": "zapper0108"
    },
    "Name": {
      "value": "trafficmanager"
    },
    "RoutingMethod": {
      "value": "Performance"
    },
    "Location": {
      "value": "global"
    }
  }
}

Run the code using PowerShell using the below command

New-AzResourceGroupDeployment -ResourceGroupName "ResourceGroupName" -TemplateFile "FileName.json" -TemplateParameterFile "parameter.json"

After the execution you will get below one as output

After deploying once check in the azure portal you will see below one
