SwiftUI Plain List How to remove top header padding in iOS16

Question

I'm looking for a way to remove top section padding in my SwiftUI List

With iOS 15, we can do UITableView.appearance().sectionHeaderTopPadding = 0

However, with iOS 16, List has been reimplemented with UICollectionView and I couldn't find a way to remove the section header top padding

Here is sample code

import SwiftUI

struct TaskRow: View {
    var body: some View {
        Text("Task data goes here")
    }
}

struct HeaderText: View {
    var text:String
    var body: some View {
        Text(text)
            .font(.system(.title3))
            .fontWeight(.bold)
            .foregroundColor(.primary)
    }
}

struct ListWithSections: View {
    init() {
        if #available(iOS 15.0, *) {
            UITableView.appearance().sectionHeaderTopPadding = 0
        } else {
            // Fallback on earlier versions
        }
    }

    var body: some View {
        if #available(iOS 16.0, *) {
            List {
                Section(header: HeaderText(text: "Section 1")) {
                    TaskRow()
                    TaskRow()
                    TaskRow()
                }

                Section(header: HeaderText(text: "Section 2")) {
                    TaskRow()
                    TaskRow()
                    TaskRow()
                }

            }
            .scrollContentBackground(.hidden)
            .background(Color.gray)
            .listStyle(.plain)
        } else {
            List {
                Section(header: HeaderText(text: "Section 1")) {
                    TaskRow()
                    TaskRow()
                    TaskRow()
                }

                Section(header: HeaderText(text: "Section 2")) {
                    TaskRow()
                    TaskRow()
                    TaskRow()
                }

            }
            .background(Color.gray)
            .listStyle(.plain)
        }
    }
}

Images for comparing between iOS 16 and iOS 15

Any way we can achieve it with List Plain Style?

Update: Using ListRowInset as @Yrb suggested will give almost same UI. However when we scroll, we have minor difference

Here what scroll in ios15 looks like (what I want to achieve in ios16)

Here what scroll in ios16 looks like (with listRowInset as @Yrb suggested)

Thanks in advance.

Best regards.

Answer 1

SwiftUI has had a native implementation of this since iOS 13, but no one talked about it because you could reach under and set the UITableView.appearance(). What you are dealing with in SwiftUI is listRowInsets and the padding that Apple adds to the section header. Essentially what you do is take control of all of the insets. This is a double edged sword as you now control it all, you can't just set one and leave the rest as a default.

One thing you will find is that the defaults have changed from iOS 15 to iOS 16, so you can't use the same numbers. In iOS 16, you will also need to set the defaultMinListHeaderHeight in .environment.

I also extracted your section to save the repetition.

struct ListSecHeaderHeightView: View {
    var body: some View {
        List {
            Section(header: SectionView(text: "Section 1")) {
                Text("TaskRow")
                Text("TaskRow")
                Text("TaskRow")
            }
            Section(header: SectionView(text: "Section 2")) {
                Text("TaskRow")
                Text("TaskRow")
                Text("TaskRow")
            }
        }
        .scrollContentBackground(.hidden)
        .environment(\.defaultMinListHeaderHeight, 0) // Only necessary in iOS 16. For 15, use 30
        .background(Color.gray)
        .listStyle(.plain)
    }
}

struct SectionView: View {
    let text: String
    var body: some View {
        HStack {
            Text(text)
                .font(.system(.title3))
                .fontWeight(.bold)
                .foregroundColor(.primary)
        }
        // Set it here.
        // iOS 15:
        // The top goes to -8 to cancel out the padding.
        // The leading goes to 16 as you had the section in line with the rows.
        // iOS 16:
        // The top goes to -20.
        // The leading goes to 20 as you had the section in line with the rows.
        .listRowInsets(EdgeInsets(top: -8, leading: 16, bottom: 0, trailing: 0))
    }
}

Lastly, please post Minimum Reproducible Examples. We should be able to run your code as posted.
