VS Code Branching Snippet Completion Items Extension

Question

I am attempting to add Completion snippets to an extension I'm writing based on the completions sample ( https://github.com/microsoft/vscode-extension-samples/tree/main/completions-sample ). I would like to have it branch complete. In my extension, SET is a keyword that then has possible params. Each param then has further params.

Ex: SET FOO|BAR|BAS where SET FOO can be ON|OFF, SET BAR is 1|2|3, and SET BAS is RED|BLUE.

I've tried to do it with

            const SetCompletion = new vscode.CompletionItem('SET');
            SetCompletion.insertText = new vscode.SnippetString('SET ${1|FOO,BAR,BAS|};');

And then Follow on with

            const SetFooCompletion = new vscode.CompletionItem('FOO');
            SetFooCompletion.insertText = new vscode.SnippetString('FOO ${1|ON,OFF|};');

            const SetBarCompletion = new vscode.CompletionItem('BAR');
            SetBarCompletion.insertText = new vscode.SnippetString('BAR ${1|1,2,3|};');

            const SetBasCompletion = new vscode.CompletionItem('BAS');
            SetBasCompletion.insertText = new vscode.SnippetString('BAS ${1|RED,BLUE|};');

And this sort of works if I retrigger completion after the first item is inserted. I think there might be a better way. In my real world code, there are about 15 SET things that I can call on, and each one has different types of params. Some are ON|OFF, some are numbers, some strings. In the above snippets, SET BAR ON is invalid, since BAR is an integer and only FOO is ON|OFF so I don't want to provide all possible parameters to all SET statements. They should be specific to the SET command that resolves in the first completion.

Is this possible?

Edit: Fixed typos in sample code

Answer 1

The following code works.

const linePrefix = document.lineAt(position).text.substr(0, position.character);
if (linePrefix.endsWith('SET')) {
  const setCompletion = new vscode.CompletionItem('SET', vscode.CompletionItemKind.Snippet);
  setCompletion.insertText = new vscode.SnippetString('SET ${1|FOO,BAR,BAS|};');
  const setFooCompletion = new vscode.CompletionItem('SET FOO', vscode.CompletionItemKind.Snippet);
  setFooCompletion.insertText = new vscode.SnippetString('SET FOO ${1|ON,OFF|};');
  const setBarCompletion = new vscode.CompletionItem('SET BAR', vscode.CompletionItemKind.Snippet);
  setBarCompletion.insertText = new vscode.SnippetString('SET BAR ${1|1,2,3|};');
  const setBasCompletion = new vscode.CompletionItem('SET BAS', vscode.CompletionItemKind.Snippet);
  setBasCompletion.insertText = new vscode.SnippetString('SET BAS ${1|RED,BLUE|};');
  return [setCompletion, setFooCompletion, setBarCompletion, setBasCompletion];
}

If you use new vscode.CompletionItem('FOO'); it does not work. Looks like the label must match the last word of the line.

Also the line

blablaSET

does not give completion items. The SET must be a separate word. The completion items are created but are not shown.

---

Or you can try:

const linePrefix = document.lineAt(position).text.substr(0, position.character);
if (linePrefix.endsWith('SET')) {
  const setCompletion = new vscode.CompletionItem('SET', vscode.CompletionItemKind.Snippet);
  setCompletion.insertText = new vscode.SnippetString('SET ${1|FOO,BAR,BAS|}$0;');
  return [setCompletion];
}
if (linePrefix.endsWith('SET FOO')) {
  const setFooCompletion = new vscode.CompletionItem('FOO', vscode.CompletionItemKind.Snippet);
  setFooCompletion.insertText = new vscode.SnippetString('FOO ${1|ON,OFF|}');
  return [setFooCompletion];
}
if (linePrefix.endsWith('SET BAR')) {
  const setBarCompletion = new vscode.CompletionItem('BAR', vscode.CompletionItemKind.Snippet);
  setBarCompletion.insertText = new vscode.SnippetString('BAR ${1|1,2,3|}');
  return [setBarCompletion];
}
if (linePrefix.endsWith('SET BAS')) {
  const setBasCompletion = new vscode.CompletionItem('BAS', vscode.CompletionItemKind.Snippet);
  setBasCompletion.insertText = new vscode.SnippetString('BAS ${1|RED,BLUE|}');
  return [setBasCompletion];
}

You have to trigger the CompletionItems with Ctrl+Space after selecting one of the SET options. Look carefully when you leave the snippet (or double snippet) when using TAB (multiple times)

Answer 2

I took a long look at this trying to figure out what is going on and concluded that because your first snippet is a choice snippet that you will not be able to do it as simply as you would like.

Normally, if you used this

const SetCompletion  = new vscode.CompletionItem('SET');
SetCompletion .insertText = new vscode.SnippetString('SET ${1|FOO,BAR,BAS|};');

SetCompletion.command = { command: 'editor.action.triggerSuggest', title: 'Re-trigger completions...' };

that command property would help you avoid having to manually re-trigger the suggestions for FOO/BAR/BAS. But it doesn't work. I am convinced that the command runs after the snippet is inserted but before it is completed.

You can see this if you use other commands like

SetCompletion.command = { command: 'leaveSnippet', title: '...' };

In this case, you won't even get the choice presented because the leaveSnippet command has already run!

So it seems the simplest is this:

const SetFooCompletion = new vscode.CompletionItem('SET FOO');
SetFooCompletion.insertText = new vscode.SnippetString('SET FOO ${1|ON,OFF|};');

const SetBarCompletion = new vscode.CompletionItem('SET BAR');
SetBarCompletion.insertText = new vscode.SnippetString('SET BAR ${1|1,2,3|};');

const SetBasCompletion = new vscode.CompletionItem('SET BAS');
SetBasCompletion.insertText = new vscode.SnippetString('SET BAS ${1|RED,BLUE|};');

You would have to make a bunch of SET xxx CompletionItems but there would be no manually triggering of suggestions to complete.

---

As an interesting aside (and more proof that the command is running before the snippet choice and thus of no use is code like this:

const SetCompletion = new vscode.CompletionItem('SET');
SetCompletion.insertText = new vscode.SnippetString('${TM_FILENAME_BASE/(.*)/${1:/upcase}/}');

SetCompletion.command = { command: 'folder-operations.setCompletionCommand', title: 'Re-trigger completions...' };

With the command defined as

const setCompletionHandler = vscode.commands.registerCommand('folder-operations.setCompletionCommand', async () => {
  await vscode.commands.executeCommand('editor.action.triggerSuggest');
  await vscode.commands.executeCommand('acceptSelectedSuggestion');
});
context.subscriptions.push(setCompletionHandler);

If you run that in a FOO.<some extension> or BAR.<ext> or BAS.<ext> it will work as expected. The snippet fileNameBase is resolved before the command is run - the command just selects the top choice.
