How to create a 'count.index' to scale the HDDs via terraform for Azure Provider

Question

What are you looking to accomplish?

To scale up or down the quantity of 'Resource VMs' in direct relation with their necessary 'Resource OS_disk'. For example, if we require to provision '5, 10, or 20' VMs we will require also to match the same '5, 10, or 20' OS Disks.

Currently, I know how to use count.index (see bellow code snippet) for the resource VM, but I don't know how to implement it for the resource OS_Disk, meaning that if we require to provision '200 VMs' I can define those '200 VMs' by setting that amount via the parameter count from the resource VM code block (see bellow code snippet), but I can't for the '200' OS_disk (disclaimer, once again because I don't know how to)

Do you have a code example to share?

resource "azurerm_network_interface" "network_card_resource" {
  count                     = 1
  name                      = "network_card_${count.index}"
  location                  = "removed"
  resource_group_name       = removed

  ip_configuration {
    name                          = "internal"
    subnet_id                     = removed.outputs.removed.subnet.removed.main.subnets["removed-XX.XX.XX.XX_XX"].id
    private_ip_address_allocation = "Dynamic"
  }
}

resource "azurerm_windows_virtual_machine" "vm_resource" {
  count                     = 10
  name                      = "vm_name_${count.index}"
  resource_group_name       = removed
  location                  = "removed"
  size                      = "Standard_D4_v3"


  admin_username            = var.admin_username
  admin_password            = var.admin_password
  network_interface_ids     = [
    element(azurerm_network_interface.network_card_resource.*.id, count.index)
  ]

  os_disk {
    count                   = 10
    name                    = "disk_name_${count.index}"
    caching                 = "ReadWrite"
    storage_account_type    = "Standard_LRS"
    resource_group_name     = removed
    disk_size_gb            = 180
  }

The above code failed to build the 10 OS disks via the count.index,

Is there an approach to tackle this?

Answer 1

It is not possible to add 10 OS disk for a particular VM , you can have only 1 OS disk Per VM and other than that you can attach data disks (2 disks for 1 VM VCPU).

So , as a solution you can use for_each instead of count for better functionality of the code and then you can use the below script to create the VM's with additional data disks as per your requirement:

In the below code I am creating 3 VM's with 1 OS disk and 5 Data disk each:

provider "azurerm"{
    features{}
}

data "azurerm_resource_group" "example"{
    name="ansumantest"
}

resource "azurerm_virtual_network" "example" {
  name                = "example-network"
  address_space       = ["10.0.0.0/16"]
  location            = data.azurerm_resource_group.example.location
  resource_group_name = data.azurerm_resource_group.example.name
}


resource "azurerm_subnet" "test_subnet" {
    name = "VM-subnet"
    resource_group_name = data.azurerm_resource_group.example.name
    virtual_network_name = azurerm_virtual_network.example.name
    address_prefixes = ["10.0.0.0/24"]
}

resource "azurerm_public_ip" "myterraformpublicip" {
   for_each = toset(var.instances)
   name                         = "myPublicIP-${each.key}"
   location                     = data.azurerm_resource_group.example.location
   resource_group_name          = data.azurerm_resource_group.example.name
   allocation_method            = "Dynamic"
}

resource "azurerm_network_interface" "myterraformnic" {
    for_each= toset(var.instances)
    name                      = "myNIC-${each.key}"
    location                  = data.azurerm_resource_group.example.location
    resource_group_name       = data.azurerm_resource_group.example.name

    ip_configuration {
      name                          = "myNicConfiguration"
      subnet_id                     = azurerm_subnet.test_subnet.id
      private_ip_address_allocation = "Dynamic"
      public_ip_address_id          = azurerm_public_ip.myterraformpublicip[each.key].id
    }
}
  variable "instances" {
  default = ["vm-test-1", "vm-test-2", "vm-test-3"]
  }
  variable "nb_disks_per_instance" {
  default = 5
  }
locals {
  vm_datadiskdisk_count_map = { for k in toset(var.instances) : k => var.nb_disks_per_instance }
  luns                      = { for k in local.datadisk_lun_map : k.datadisk_name => k.lun }
  datadisk_lun_map = flatten([
    for vm_name, count in local.vm_datadiskdisk_count_map : [
      for i in range(count) : {
        datadisk_name = format("datadisk_%s_disk%02d", vm_name, i)
        lun           = i
      }
    ]
  ])
}

resource "azurerm_windows_virtual_machine" "example" {
  for_each = toset(var.instances)
  name                = "example-machine${each.key}"
  resource_group_name = data.azurerm_resource_group.example.name
  location            = data.azurerm_resource_group.example.location
  size                = "Standard_F2"
  admin_username      = "adminuser"
  admin_password      = "P@$$w0rd1234!"
  network_interface_ids = [azurerm_network_interface.myterraformnic[format("%s", each.key)].id]

   os_disk {
    name                    = "${each.key}-OSDISK"
    caching                 = "ReadWrite"
    storage_account_type    = "Standard_LRS"
    disk_size_gb            = 180
  }

  source_image_reference {
    publisher = "MicrosoftWindowsServer"
    offer     = "WindowsServer"
    sku       = "2016-Datacenter"
    version   = "latest"
  }
}

resource "azurerm_managed_disk" "example" {
  for_each             = toset([for j in local.datadisk_lun_map : j.datadisk_name])
  name                 = each.key
  location             = data.azurerm_resource_group.example.location
  resource_group_name  = data.azurerm_resource_group.example.name
  storage_account_type = "Standard_LRS"
  create_option        = "Empty"
  disk_size_gb         = 10
}

resource "azurerm_virtual_machine_data_disk_attachment" "example" {
  for_each           = toset([for j in local.datadisk_lun_map : j.datadisk_name])
  managed_disk_id    = azurerm_managed_disk.example[each.key].id
  virtual_machine_id = azurerm_windows_virtual_machine.example[element(split("_", each.key), 1)].id
  lun                = lookup(local.luns, each.key)
  caching            = "ReadWrite"
}

Output:

---

Matching the OS Disk with count is not required by providing another count inside the OS_disk Block :

For example, I created 2 VMs using terraform then its by default that 2 OS disk will also be created like below :

resource "azurerm_linux_virtual_machine" "myterraformvm" {
count = 2
name                  = "testpoc0${count.index + 1}"
location              = data.azurerm_resource_group.example.location
resource_group_name   = data.azurerm_resource_group.example.name
 #network_interface_ids = azurerm_network_interface.myterraformnic.*.id
network_interface_ids = [element(azurerm_network_interface.myterraformnic.*.id, count.index + 1)]
size                  = "Standard_DS1_v2"

os_disk {
    ## count == not required here again as this is a child block inside the main VM resource block , so as many VM's will be created OS disk will also be created that many
    name              = "OsDisk${count.index + 1}"
    caching           = "ReadWrite"
    storage_account_type = "Premium_LRS"
}

source_image_reference {
    publisher = "Canonical"
    offer     = "UbuntuServer"
    sku       = "18.04-LTS"
    version   = "latest"
}

computer_name  = "testpoc0${count.index}"
admin_username = "azureuser"
disable_password_authentication = true

admin_ssh_key {
    username       = "azureuser"
    public_key     = file("~/.ssh/id_rsa.pub")
}
}
