Difficulty fitting piecewise linear data in R

Question

I have the following data (cost of a product vs. time) that looks like the following:

annum <- c(1903, 1904, 1905, 1906, 1907, 1908, 1909, 1910, 1911, 1912, 1913,
    1914, 1915, 1916, 1917, 1918, 1919)
cost <- c(0.0000,  18.6140,  92.1278, 101.9393, 112.0808, 122.5521,
    133.3532, 144.4843, 244.5052, 275.6068, 295.2592, 317.3145,
    339.6527, 362.3537, 377.7775, 402.8443, 437.5539)

mydata <- as.data.frame(cbind(annum, cost))

g <- ggplot(mydata, aes(x = annum, y = cost))
g <- g + geom_point()
g <- g + scale_y_continuous(labels=scales::dollar_format())
g

This is the resulting plot of this data using this code The plot shows something that looks piecewise linear to me; there's a step from 1904 to 1905; then a clear line from 1905 to 1910; then a step; and then another line from 1911 to the end. (The first point (1903, 0) is fictitious.)

I've tried to use the segmented package to model this, but instead of picking something like 1904.5 and 1910.5 as breakpoints, it finds two points between 1911 and 1912.

I've tried some other techniques (e.g., "brute force" from "The R Book," and direct fitting), but I clearly don't understand this as much as I need to. Any help would be very much appreciated.

Ideally, I would end up with an equation for each segment and a single plot showing the piecewise fit and a confidence interval for the fit.

Answer 1

One can use package struccchange for this. Here a simplified code version:

library("strucchange")

startyear <- startyear
cost <- c(0.0000,  18.6140,  92.1278, 101.9393, 112.0808, 122.5521,
          133.3532, 144.4843, 244.5052, 275.6068, 295.2592, 317.3145,
          339.6527, 362.3537, 377.7775, 402.8443, 437.5539)

ts <- ts(cost, start=1903)
plot(ts)

## for small data sets you might consider to reduce segment length
bp <- breakpoints(ts ~ time(ts), data=ts, h = 5)

## BIC selection of breakpoints
plot(bp)
breakdates(bp)
fm1 <- lm(ts ~ time(ts) * breakfactor(bp), data=ts)
coef(fm1)

plot(ts, type="p")
lines(ts(fitted(fm1),  start = startyear),  col = 4)
lines(bp)
confint(bp)

lines(confint(bp))

More can be found in the package vignette or one of the related publications, e.g. https://doi.org/10.18637/jss.v007.i02 So it is for example possible to make significance tests, to estimate confidence intervals or to include covariates.

A segment length of 2 is not possible, because residual variance cannot be estimated. Similarly confidence intervals can only be estiated if segments are long enough. Therefore, only one breakpoint is shown below, while the excellent answer of @Rui Barradas omits confidence intervals but shows two breakpoints.

Her an example without the first two points and an additional assumption to estimate the confidence interval in case of a small segment:

library("strucchange")

startyear <- 1905
cost <- c(92.1278, 101.9393, 112.0808, 122.5521,
          133.3532, 144.4843, 244.5052, 275.6068, 295.2592, 317.3145,
          339.6527, 362.3537, 377.7775, 402.8443, 437.5539)

ts <- ts(cost, start=startyear)
bp <- breakpoints(ts ~ time(ts), data=ts, h = 5)
fm1 <- lm(ts ~ time(ts) * breakfactor(bp), data=ts)
plot(ts, type="p")
lines(ts(fitted(fm1),  start = startyear),  col = 4)
lines(confint(bp, het.err=FALSE))

Edit:

• bugs of the original version corrected
• coefficients and confidence interval added
• images added
• example with omitted first 2 values added

Answer 2

Here is another solution with package strucchange but without creating a time series first.

library(strucchange)

# first get a segment size as a fraction
# of the number of observations
n <- nrow(mydata)
segmts <- 3
h <- (segmts + 1)/n

# now estimate the breakpoints
b <- breakpoints(cost ~ annum, h = h, breaks = (segmts - 1L), data = mydata)
bp <- mydata[b$breakpoints, "annum"]

# create a grouping variable for `ggplot`
# each group is a segment
bp <- c(bp, Inf)
mydata$grp <- findInterval(mydata$annum, bp, left.open = TRUE)

# plot the linear regressions
g + geom_smooth(
  mapping = aes(group = grp),
  method = "lm",
  formula = y ~ x,
  se = FALSE
)

---

If the first data points are removed, there will be only two segments but the code above will still work.

mydata <- mydata[-(1:2), ]
n <- nrow(mydata)
segmts <- 2
h <- (segmts + 1)/n
b <- breakpoints(cost ~ annum, h = h, breaks = segmts - 1L, data = mydata)
bp <- mydata[b$breakpoints, "annum"]
bp <- c(bp, Inf)
mydata$grp <- findInterval(mydata$annum, bp, left.open = TRUE)
mydata$grp <- factor(mydata$grp)

g + geom_smooth(
  mapping = aes(group = grp),
  method = "lm",
  formula = y ~ x,
  se = FALSE
)

Answer 3

Confidence intervals for change point problems is a hard problem for frequentist methods, such as strucchange. Often, you simply get confidence intervals for each segment, i.e., hard breaks between segments rather than smooth transitions.

It's more straightforward using Bayesian methods. Here is a solution using the mcp package. Just to show off, we plot both the fitted interval and (dashed red lines) and the prediction interval (dashed green lines). The gray lines are random draws from the posterior distribution and the densities on the x-axis are the posteriors for the change point locations.

data = data.frame(
  annum = 1903:1919,
  cost = c(0.0000,  18.6140,  92.1278, 101.9393, 112.0808, 122.5521,
          133.3532, 144.4843, 244.5052, 275.6068, 295.2592, 317.3145,
          339.6527, 362.3537, 377.7775, 402.8443, 437.5539)
)

# Model as three disjoined slopes
model = list(
  cost ~ 1 + annum,
  ~ 1 + annum,
  ~ 1 + annum
)

library(mcp)
fit = mcp(model, data)
plot(fit, q_fit = TRUE, q_predict = TRUE)

If you're interested in the parameter estimates for the change points and the segments, just call summary(fit):

        name    mean  lower    upper Rhat n.eff
     annum_1   -0.11   -0.2 -6.6e-04  2.5    25
     annum_2   10.36    7.4  1.3e+01  1.0   609
     annum_3   22.74   21.2  2.4e+01  1.0   264
        cp_1 1904.50 1904.0  1.9e+03  2.5    24
        cp_2 1910.46 1910.0  1.9e+03  1.0   778
 Intercept_1  221.39   10.8  3.9e+02  1.0   948
 Intercept_2   86.77   75.0  9.8e+01  1.0  1297
 Intercept_3  236.03  221.7  2.5e+02  1.0   237
     sigma_1    5.97    3.6  8.9e+00  1.0  1709
