How to create a stacked bar plot with column names on the axis from a wide dataframe

Question

The first image is the figure I'm trying to reproduce, and the second image is the data I have. Does anyone have a clean way to do this with pandas or matplotlib?

Answer 1

Just transpose the DataFrame and use df.plot with the stacked flag set to true:

import pandas as pd
from matplotlib import pyplot as plt

df = pd.DataFrame({'squad': [0.6616, 0.1245, 0.0950],
                   'quac': [0.83, 0.065, 0.0176],
                   'quoref': [0.504, 0.340364, 0.1067]})

# Transpose
plot_df = df.T
# plot
ax = plot_df.plot(kind='bar', stacked=True, rot='horizontal')

ax.legend(bbox_to_anchor=(1.05, 1), loc='upper left', borderaxespad=0.)
ax.set_ylabel("% of Questions")

plt.tight_layout()
plt.show()

Answer 2

You can try this:

data = {'squad':[0.661669, 0.127516, 0.095005],
        'quac':[0.930514, 0.065951, 0.017680],
        'quoref': [0.504963, 0.340364, 0.106700]}

df = pd.DataFrame(data)

bars_1 = df.iloc[0]
bars_2 = df.iloc[1]
bars_3 = df.iloc[2]

# Heights of bars_1 + bars_2
bars_1_to_2 = np.add(bars_1, bars_2).tolist()

# The position of the bars on the x-axis
r = [0, 1, 2]

plt.figure(figsize = (7, 7))

plt.bar(r, bars_1, color = 'lightgrey', edgecolor = 'white')
plt.bar(r, bars_2, bottom = bars_1, color = 'darkgrey', edgecolor = 'white')
plt.bar(r, bars_3, bottom = bars_1_to_2, color = 'dimgrey', edgecolor = 'white')

plt.yticks(np.arange(0, 1.1, 0.1))
plt.xticks(ticks = r, labels = df.columns)
plt.ylabel('% of Questions')

plt.show()
