Correlation Heatmap in Plotly

Question

I have created a lower triangular correlation heatmap using Seaborn that I loved. Now trying to create the same using Plotly. Unfortunately, not being able to fine tune it like I did with Seaborn.

names = ['U', 'V', 'W', 'X', 'Y', 'Z']
r = pd.DataFrame(index = names, columns = names)
r['U'] = np.array([1.0,   0.53,    0.26,  0.63, 0.52, 0.65] )
r['V'] = np.array([0.53,   1.0,   -0.17, 0.83, 1, 0.85])
r['W'] = np.array([0.26,  -0.17,    1.0,  0.04, -0.15, 0.09])
r['X'] = np.array([0.63, 0.83, 0.04, 1, 0.83, 0.80])
r['Y'] = np.array([0.52, 1, -0.15, 0.83, 1, 0.86])
r['Z'] = np.array([0.65, 0.85, 0.09, 0.80, 0.86, 1.0])

print(r)

import seaborn as sns

# sns.set_theme(style="white")

mask = np.triu(np.ones_like(r, dtype=bool))

# Set up the matplotlib figure
f, ax = plt.subplots(figsize=(11, 9))

# Generate a custom diverging colormap
cmap = sns.diverging_palette(230, 20, n=256, as_cmap=True)

# Draw the heatmap with the mask and correct aspect ratio
sns.heatmap(r,
            mask=mask,
            cmap=cmap,
            vmax=1,
            vmin = -.25,
            center=0,
            square=True,
            linewidths=.5,
            annot = True,
            fmt='.2f',
            annot_kws={'size': 10},
            cbar_kws={"shrink": .75})

plt.title('Asset Correlation Matrix')
plt.tight_layout()
ax.tick_params(axis = 'x', labelsize = 8)
ax.set_ylim(len(corr)+1, -1)
# plt.savefig('corrTax.png', dpi = 600)

plt.show()

I am trying to create this using Plotly. Here is what I have able to do so far.

mask = np.triu(np.ones_like(r, dtype=bool))
rLT = r.mask(mask)

heat = go.Heatmap(
    z = rLT,
    x = rLT.columns.values,
    y = rLT.columns.values,
    zmin = - 0.25, # Sets the lower bound of the color domain
    zmax = 1,
    xgap = 1, # Sets the horizontal gap (in pixels) between bricks
    ygap = 1,
    colorscale = 'RdBu'
)

title = 'Asset Correlation Matrix'

layout = go.Layout(
    title_text=title,
    title_x=0.5,
    width=600,
    height=600,
    xaxis_showgrid=False,
    yaxis_showgrid=False,
    yaxis_autorange='reversed'
)

fig=go.Figure(data=[heat], layout=layout)
fig.show()

Seaborn colormap that I was create, I want to create something similar in Plotly. How can I do that?
I was able to control the axis label sizes.
Would love to put values into each box (annot option in seaborn), with rounding option

score 2 · Answer 1 · answered May 20 '21 at 19:45

Deb. Here it goes the answer for the first of your questions.

Seaborn colormap that I was create, I want to create something similar in Plotly. How can I do that?

You can use of the built-in colorscales in Plotly, which can be set via the parameter colorscale in the Heatmap constructor. Also, you can set Plotly's theme to get rid of the ugly background

import plotly.io as pio
import plotly.express as px
import plotly.graph_objects as go

pio.templates.default = "plotly_white"

go.Heatmap(
    z=corr.mask(mask),
    x=corr.columns,
    y=corr.columns,
    colorscale=px.colors.diverging.RdBu,
    zmin=-1,
    zmax=1
)

Thank you. Is it possible to put the numbers inside boxes? – deb May 23 '21 at 12:51 — deb, May 23 '21 at 12:51

score 1 · Answer 2 · edited Jan 15 '22 at 15:58

You can use plotly function create_annotated_heatmap from plotly.figure_factory instead of the normal plotly heatmap. This function accepts numpy array instead of the dataframe directly. Official Reference Here is my solution

import plotly.figure_factory as ff

corr = df.iloc.corr()
mask = np.triu(np.ones_like(corr, dtype=bool))
df_mask = corr.mask(mask)

fig = ff.create_annotated_heatmap(z=df_mask.to_numpy(),
                                  x=df_mask.columns.tolist(),
                                  y=df_mask.columns.tolist(),
                                  colorscale=px.colors.diverging.RdBu,
                                  hoverinfo="none", #Shows hoverinfo for null values
                                  showscale=True, ygap=1, xgap=1
                                 )

fig.update_xaxes(side="bottom")

fig.update_layout(
    title_text='Heatmap',
    title_x=0.5,
    width=1000,
    height=1000,
    xaxis_showgrid=False,
    yaxis_showgrid=False,
    xaxis_zeroline=False,
    yaxis_zeroline=False,
    yaxis_autorange='reversed',
    template='plotly_white'
)

# NaN values are not handled automatically and are displayed in the figure
# So we need to get rid of the text manually
for i in range(len(fig.layout.annotations)):
    if fig.layout.annotations[i].text == 'nan':
        fig.layout.annotations[i].text = ""

fig.show()

You can use zmin and zmax as speciifed by @ottovon

Basic heatmap can also be used but annotations need to be done manually by specifying some function, I presume.

For rounding up annotation refer to this Plotly: How to round display text in annotated heatmap but keep full format on hover? thread.

Also, you can refer the Official Docs for the sizing of the xticks and the same can be done for yticks. I have not practically implemented them but they should work fine.

Marcos Galvão · Answer 3 · 2022-12-17T23:42:10.893

1

Easiest way I've found to remove top triangle in view

# Correlation
df_corr = data.corr().round(1)
# Mask to matrix
mask = np.zeros_like(df_corr, dtype=bool)
mask[np.triu_indices_from(mask)] = True
# Viz
df_corr_viz = df_corr.mask(mask).dropna(how='all').dropna('columns', how='all')
fig = px.imshow(df_corr_viz, text_auto=True)
fig.show()

edited Dec 17 '22 at 23:42

answered Dec 17 '22 at 23:33

Marcos Galvão

21
3

score 0 · Answer 4 · edited Apr 09 '23 at 23:21

0

import plotly.express as px
import pandas as pd

df = **some kinda of pandas data frame**


px.imshow(df.corr())

edited Apr 09 '23 at 23:21

cottontail

10,268
18
50
51

answered Apr 05 '23 at 02:33

Ian Daniel

1
