label y axis with a different column in ggplot2

Question

Using ggplot2, I want to create a plot with a variable as my y-axis, but a different variable for the y-axis label

Take this sample data:

df <- data_frame(
  YearMonth = c("2018-01", "2018-01", "2018-02", "2018-02", "2018-03", "2018-03", "2018-04", "2018-04", "2018-05", "2018-05", "2018-06", "2018-06", "2019-01", "2019-01", "2019-02", "2019-02", "2019-03", "2019-03", "2019-04", "2019-04", "2019-05", "2019-05", "2019-06", "2019-06"),
  Year = c("2018", "2018", "2018", "2018", "2018", "2018", "2018", "2018", "2018", "2018", "2018", "2018", "2019", "2019", "2019", "2019", "2019", "2019", "2019", "2019", "2019", "2019", "2019", "2019"),
  Day = c("1","2","1","2","1","2","1","2","1","2","1","2","1","2","1","2","1","2","1","2","1","2","1","2"),
  Total = c(11, 43, 12, 81, 90, 74, 8, 3, 7, 14, 50, 99, 67, 45, 31, 23, 46, 53, 4, 90, 34, 46, 98, 2),
)

I can create a tile plot, with "year-month" as my y-axis, "Day" as my x-axis, & "Total" my "fill" value

library(ggplot2)

df %>%
  ggplot(aes(x = Day,
             y = YearMonth)) +
  geom_tile(aes(fill = Total),
            colour = "white",
            size = 0.2,
            na.rm = FALSE) +
  coord_equal(ratio = 1) +
  scale_fill_gradient2(low = "#F1EDDE",
                       high = "#C72B26",
                       midpoint = 10)

which produces the below:

However, I don't want "Year-Month" as my y-axis label. I want to use "Year" - which would produce just two labels (2018 & 2019) along the left hand, vertical axis

I have consulted similar topics with no such success. I have attempted to use annotate, specified "year" in scale_y_discrete, & a secondary axis, but have not been able to achieve the desired result. I would be grateful for any instruction on how to achieve this

Do you want only 4 tiles or do you want the plot as it is and change only the y tick labels? — Roman, Dec 09 '20 at 10:36

score 1 · Accepted Answer · answered Dec 09 '20 at 10:36

You can feed explicit breaks and labels to the scale, or provide a function that gets you the result you want. One example of each in the code below. I've assumed you wanted to label the januaries.

library(tidyverse)
#> Warning: package 'tibble' was built under R version 4.0.3
#> Warning: package 'tidyr' was built under R version 4.0.3
#> Warning: package 'dplyr' was built under R version 4.0.3

df <- data.frame(
  YearMonth = c("2018-01", "2018-01", "2018-02", "2018-02", "2018-03", "2018-03", "2018-04", "2018-04", "2018-05", "2018-05", "2018-06", "2018-06", "2019-01", "2019-01", "2019-02", "2019-02", "2019-03", "2019-03", "2019-04", "2019-04", "2019-05", "2019-05", "2019-06", "2019-06"),
  Year = c("2018", "2018", "2018", "2018", "2018", "2018", "2018", "2018", "2018", "2018", "2018", "2018", "2019", "2019", "2019", "2019", "2019", "2019", "2019", "2019", "2019", "2019", "2019", "2019"),
  Day = c("1","2","1","2","1","2","1","2","1","2","1","2","1","2","1","2","1","2","1","2","1","2","1","2"),
  Total = c(11, 43, 12, 81, 90, 74, 8, 3, 7, 14, 50, 99, 67, 45, 31, 23, 46, 53, 4, 90, 34, 46, 98, 2)
)

df %>%
  ggplot(aes(x = Day,
             y = YearMonth)) +
  geom_tile(aes(fill = Total),
            colour = "white",
            size = 0.2,
            na.rm = FALSE) +
  coord_equal(ratio = 1) +
  scale_fill_gradient2(low = "#F1EDDE",
                       high = "#C72B26",
                       midpoint = 10) +
  scale_y_discrete(
    breaks = c("2018-01", "2019-01"),
    labels = c("2018", "2019")
  )


df %>%
  ggplot(aes(x = Day,
             y = YearMonth)) +
  geom_tile(aes(fill = Total),
            colour = "white",
            size = 0.2,
            na.rm = FALSE) +
  coord_equal(ratio = 1) +
  scale_fill_gradient2(low = "#F1EDDE",
                       high = "#C72B26",
                       midpoint = 10) +
  scale_y_discrete(
    breaks = function(x) { x[grepl("-01$", x)] },
    labels = function(x) {data.table::tstrsplit(x, "-")[[1]]}
  )

^{Created on 2020-12-09 by the reprex package (v0.3.0)}

Roman · Answer 2 · 2020-12-09T10:47:19.627

You can try

df %>%
  mutate(YearMonth = str_split(YearMonth, "-") %>% map_chr(2) %>% as.numeric) %>%
  mutate(Year = factor(Year, levels = rev(unique(as.numeric(Year))))) %>%
  ggplot(aes(x = Day,
             y = YearMonth)) +
  geom_tile(aes(fill = Total),
            colour = "white",
            size = 0.2,
            na.rm = FALSE) +
  scale_fill_gradient2(low = "#F1EDDE",
                       high = "#C72B26",
                       midpoint = 10) +
  coord_equal() +
  facet_wrap(~Year,ncol=1, strip.position = "left") +
  ylab("") +
  theme_bw(base_size = 16) +
  theme(axis.text.y = element_blank(),
        axis.ticks.y = element_blank())

this is a nice way of visualising it - teunbrand had the answer I was looking for, but thank you for responding — perkot, Dec 09 '20 at 10:46
