Predicting and Plotting Survival Curve with the CoxPH

Question

I am trying to predict and plot the (estimated) survival curve for a new observation in R. Using the "survival" library and the "lung" data set, I first fit a cox proportional hazards model to the data. Then, I tried to predict and plot the survival curve for a hypothetical new observation (I entered the details for this hypothetical new observation in the "list" command). However, this is not working.

I have attached my code below:

#load library
library(survival)
data(lung)

#create survival object
s <- with(lung,Surv(time,status))

#create model
modelA  <- coxph(s ~ as.factor(sex)+age+ph.ecog+wt.loss+ph.karno,data=lung, model=TRUE)
summary(modelA)

#plot
plot(survfit(modelA), ylab="Probability of Survival",
     xlab="Time", col=c("red", "black", "black"))

#predict for a hypothetical NEW observation (here is where the error is)
lines(predict(modelA, newdata=list(sex=1,
                                  age = 56,
                                  ph.ecog = 1,
                                  ph.karno = 50,
                                  wt.loss = 11),
               type="quantile",
               p=seq(.01,.99,by=.01)),
       seq(.99,.01,by=-.01),
       col="blue")
## Error in match.arg(type) :
##  'arg' should be one of “lp”, “risk”, “expected”, “terms”, “survival”

Does anyone know what I am doing wrong? Thanks

Answer 1

This is what the survfit function is for. In your example, you plot the survfit for the model, but you can feed a newdata argument into this function and it will produce the estimated survival for these data.

If we reproduce your example:

library(survival)

s <- with(lung, Surv(time, status))

modelA  <- coxph(s ~ as.factor(sex) + age + ph.ecog + wt.loss + ph.karno,
                 data = lung, model = TRUE)

plot(survfit(modelA), ylab = "Probability of Survival",
     xlab = "Time", col = c("red", "black", "black"))

Then we can create a survival curve given your specified covariates like this:

est <- survfit(modelA, newdata = data.frame(sex      = 1,
                                            age      = 56,
                                            ph.ecog  = 1,
                                            ph.karno = 50,
                                            wt.loss  = 11))

Now est is an S3 object with members that include time and survival, so we can plot a blue line tracking the estimated survival of individuals with the given covariates like this:

lines(est$time, est$surv, col = 'blue', type = 's')

Or plot it on its own with a 95% confidence interval:

plot(est, ylab = "Probability of Survival",
     xlab = "Time", col = c("red", "black", "black"))

^{Created on 2022-05-26 by the reprex package (v2.0.1)}

Answer 2

See the description of the predict() function (you can open it in R help by running ?predict.coxph, or here for example):

type - the type of predicted value. Choices are the linear predictor ("lp"), the risk score exp(lp) ("risk"), the expected number of events given the covariates and follow-up time ("expected"), and the terms of the linear predictor ("terms"). The survival probability for a subject is equal to exp(-expected).

You can see that your type="quantile" does not match expected input. If you call predict() without the type argument, in your case it will default to using lp (linear predictor).
