Custom UIImageView is not circle inside custom UITableViewCell

Question

I have custom UITableViewCell done in code, but I have trouble with circular UIImageView with SfSymbol inside. Sometimes it is working well as you can see on the screenshot, but sometimes it has some strange shape. If I don't set any SfSymbol shape is good.

I think that I tried anything, which I can, but still it's not working. This is my custom cell code:

import UIKit

class ListsTableViewCell: UITableViewCell {

    // MARK: - Properties

    let configuration = UIImage.SymbolConfiguration(pointSize: 16, weight: .medium)

    var list: List? {
        didSet {
            guard let list = list else { return }

            iconView.backgroundColor = list.color
            titleLabel.text = list.name
        }
    }

    // MARK: - Layout properties

    var iconView: CircularImageView!
    var titleLabel: UILabel!

    // MARK: - Initialization

    override init(style: UITableViewCell.CellStyle, reuseIdentifier: String?) {
        super.init(style: style, reuseIdentifier: reuseIdentifier)

        iconView = CircularImageView()
        iconView.translatesAutoresizingMaskIntoConstraints = false
        iconView.tintColor = .white
        iconView.contentMode = .center

        titleLabel = UILabel()
        titleLabel.translatesAutoresizingMaskIntoConstraints = false

        contentView.addSubview(iconView)
        contentView.addSubview(titleLabel)

        NSLayoutConstraint.activate([
            iconView.heightAnchor.constraint(equalToConstant: 34),
            iconView.widthAnchor.constraint(equalToConstant: 34),
            iconView.topAnchor.constraint(equalTo: contentView.topAnchor, constant: 10),
            iconView.bottomAnchor.constraint(equalTo: contentView.bottomAnchor, constant: -10),
            iconView.leadingAnchor.constraint(equalTo: contentView.leadingAnchor, constant: 16),
            iconView.centerYAnchor.constraint(equalTo: contentView.centerYAnchor),

            titleLabel.leadingAnchor.constraint(equalTo: iconView.trailingAnchor, constant: 12),
            titleLabel.trailingAnchor.constraint(equalTo: contentView.trailingAnchor, constant: -16),
            titleLabel.centerYAnchor.constraint(equalTo: contentView.centerYAnchor)
        ])
    }

    required init?(coder: NSCoder) {
        fatalError("init(coder:) has not been implemented")
    }
}

This is table view cell for row function:

func tableView(_ tableView: UITableView, cellForRowAt indexPath: IndexPath) -> UITableViewCell {
    let list = listsToDisplay![indexPath.row]

    let tableViewCell = tableView.dequeueReusableCell(withIdentifier: "list", for: indexPath) as! ListsTableViewCell
    tableViewCell.iconView.image = UIImage(systemName: list.icon, withConfiguration: tableViewCell.configuration)
    tableViewCell.list = list
    tableViewCell.accessoryType = .disclosureIndicator

    return tableViewCell
}

And this is custom subclass of UIImageView

import UIKit

class CircularImageView: UIImageView {
    override func layoutSubviews() {
        self.layer.masksToBounds = true
        self.clipsToBounds = true
        self.layer.cornerRadius = self.frame.size.width / 2
    }
}

Are you getting any warnings regarding breaking constraints? — Frankenstein, Jul 31 '20 at 09:51
Yes, I have. Something it's wrong with cell size. It shows me some strange constraint: UIView-Encapsulated-Layout-Height' UITableViewCellContentView:0x7faa33e1d0c0.height == 54.3333 — sirekpiotr, Jul 31 '20 at 09:56
I don't think you need to set the height and width constraints. Why don't you try without it. — Rakesha Shastri, Jul 31 '20 at 10:35
@sirekpiotr - show an image of how it looks when it *"sometimes it has some strange shape"* — DonMag, Jul 31 '20 at 14:03
@DonMag you can see it in the screenshot blue icon with mail image it's not circle, it's something like oval — sirekpiotr, Jul 31 '20 at 18:29

DonMag · Accepted Answer · 2020-07-31T20:20:29.267

Ah - I've seen this before.

I don't know why, but using a SF Symbol in a UIImageView will change the image view's height!!!

You can easily confirm this:

add a view controller in Storyboard
add a UIImageView
set content mode to Center (doesn't really matter)
constrain Width: 60 Height: 60 centerX and centerY
Check the Size Inspector - it will show 60 x 60

Now:

use the drop-down to set the image to "globe"
Check the Size Inspector - it will show 60 x 59

Now:

use the drop-down to set the image to "envelope"
Check the Size Inspector - it will show 60 x 56.5

No apparent constraint conflicts... no apparent reason for this.

As far as I can tell (unless this changes with iOS 14), we need to embed the image view in a UIView ... constrain it centerX & centerY ... set the background color and corner-radius properties of that view to make it round.

Edit -- just as an exercise...

Two horizontal stack views:

Alignment: Fill
Distribution: FillEqually
Spacing: 0
each constrained to Width: 300 and Height: 100
each filled with 3 UIImageViews

Gives us 3 100 x 100 square image views. For the second stack, set each image view to a system image, with UIImage.SymbolConfiguration(pointSize: 60, weight: .regular). Should still give us 3 100 x 100 squares.

Instead, this is the result:

Here's the code to produce that:

class SystemImageTestViewController: UIViewController {

    override func viewDidLoad() {
        super.viewDidLoad()

        let stack1 = UIStackView()
        stack1.axis = .horizontal
        stack1.alignment = .fill
        stack1.distribution = .fillEqually

        let stack2 = UIStackView()
        stack2.axis = .horizontal
        stack2.alignment = .fill
        stack2.distribution = .fillEqually

        // add stack views to the view
        [stack1, stack2].forEach {
            $0.translatesAutoresizingMaskIntoConstraints = false
            view.addSubview($0)
        }

        let g = view.safeAreaLayoutGuide

        NSLayoutConstraint.activate([

            stack1.topAnchor.constraint(equalTo: g.topAnchor, constant: 40.0),
            stack1.widthAnchor.constraint(equalToConstant: 300.0),
            stack1.heightAnchor.constraint(equalToConstant: 100.0),
            stack1.centerXAnchor.constraint(equalTo: g.centerXAnchor),

            stack2.topAnchor.constraint(equalTo: stack1.bottomAnchor, constant: 20.0),
            stack2.widthAnchor.constraint(equalToConstant: 300.0),
            stack2.heightAnchor.constraint(equalToConstant: 100.0),
            stack2.centerXAnchor.constraint(equalTo: g.centerXAnchor),

        ])

        let colors: [UIColor] = [
            UIColor(red: 0.75, green: 0.00, blue: 0.00, alpha: 1.0),
            UIColor(red: 0.00, green: 0.75, blue: 0.00, alpha: 1.0),
            UIColor(red: 0.00, green: 0.00, blue: 1.00, alpha: 1.0),
        ]

        for c in colors {
            let v = UIImageView()
            v.backgroundColor = c
            stack1.addArrangedSubview(v)
        }

        let configuration = UIImage.SymbolConfiguration(pointSize: 60, weight: .regular)

        let names: [String] = [
            "globe",
            "bandage",
            "envelope",
        ]

        for (c, n) in zip(colors, names) {
            let v = UIImageView()
            v.backgroundColor = c
            v.contentMode = .center
            v.tintColor = .white
            let img = UIImage(systemName: n, withConfiguration: configuration)
            v.image = img
            stack2.addArrangedSubview(v)
        }

    }
}

Edit 2 - just for the heck of it...

Implementing a couple classes for a SystemImageView and CircularSystemImageView:

class SystemImageView: UIView {

    override var contentMode: UIView.ContentMode {
        didSet {
            imageView.contentMode = contentMode
        }
    }
    override var tintColor: UIColor! {
        didSet {
            imageView.tintColor = tintColor
        }
    }
    var image: UIImage = UIImage() {
        didSet {
            imageView.image = image
        }
    }
    let imageView = UIImageView()

    override init(frame: CGRect) {
        super.init(frame: frame)
        commonInit()
    }
    required init?(coder: NSCoder) {
        super.init(coder: coder)
        commonInit()
    }
    func commonInit() -> Void {
        clipsToBounds = true
        addSubview(imageView)
        imageView.translatesAutoresizingMaskIntoConstraints = false
        NSLayoutConstraint.activate([
            imageView.topAnchor.constraint(equalTo: topAnchor),
            imageView.leadingAnchor.constraint(equalTo: leadingAnchor),
            imageView.trailingAnchor.constraint(equalTo: trailingAnchor),
            imageView.bottomAnchor.constraint(equalTo: bottomAnchor),
        ])
    }
}

class CircularSystemImageView: SystemImageView {
    override func layoutSubviews() {
        super.layoutSubviews()
        self.layer.masksToBounds = true
        self.clipsToBounds = true
        self.layer.cornerRadius = bounds.size.width * 0.5
    }
}

class SystemImageTestViewController: UIViewController {

    override func viewDidLoad() {
        super.viewDidLoad()

        let stack1 = UIStackView()
        stack1.axis = .horizontal
        stack1.alignment = .fill
        stack1.distribution = .fillEqually

        let stack2 = UIStackView()
        stack2.axis = .horizontal
        stack2.alignment = .fill
        stack2.distribution = .fillEqually

        let stack3 = UIStackView()
        stack3.axis = .horizontal
        stack3.alignment = .fill
        stack3.distribution = .fillEqually

        let stack4 = UIStackView()
        stack4.axis = .horizontal
        stack4.alignment = .fill
        stack4.distribution = .fillEqually

        // add stack views to the view
        [stack1, stack2, stack3, stack4].forEach {
            $0.translatesAutoresizingMaskIntoConstraints = false
            view.addSubview($0)
        }

        let g = view.safeAreaLayoutGuide

        NSLayoutConstraint.activate([

            stack1.topAnchor.constraint(equalTo: g.topAnchor, constant: 40.0),
            stack1.widthAnchor.constraint(equalToConstant: 300.0),
            stack1.heightAnchor.constraint(equalToConstant: 100.0),
            stack1.centerXAnchor.constraint(equalTo: g.centerXAnchor),

            stack2.topAnchor.constraint(equalTo: stack1.bottomAnchor, constant: 20.0),
            stack2.widthAnchor.constraint(equalToConstant: 300.0),
            stack2.heightAnchor.constraint(equalToConstant: 100.0),
            stack2.centerXAnchor.constraint(equalTo: g.centerXAnchor),

            stack3.topAnchor.constraint(equalTo: stack2.bottomAnchor, constant: 20.0),
            stack3.widthAnchor.constraint(equalToConstant: 300.0),
            stack3.heightAnchor.constraint(equalToConstant: 100.0),
            stack3.centerXAnchor.constraint(equalTo: g.centerXAnchor),

            stack4.topAnchor.constraint(equalTo: stack3.bottomAnchor, constant: 20.0),
            stack4.widthAnchor.constraint(equalToConstant: 300.0),
            stack4.heightAnchor.constraint(equalToConstant: 100.0),
            stack4.centerXAnchor.constraint(equalTo: g.centerXAnchor),

        ])

        let colors: [UIColor] = [
            UIColor(red: 0.75, green: 0.00, blue: 0.00, alpha: 1.0),
            UIColor(red: 0.00, green: 0.75, blue: 0.00, alpha: 1.0),
            UIColor(red: 0.00, green: 0.00, blue: 1.00, alpha: 1.0),
        ]

        for c in colors {
            let v = UIImageView()
            v.backgroundColor = c
            stack1.addArrangedSubview(v)
        }

        let configuration = UIImage.SymbolConfiguration(pointSize: 60, weight: .regular)

        let names: [String] = [
            "globe",
            "bandage",
            "envelope",
        ]

        for (c, n) in zip(colors, names) {
            let v = UIImageView()
            v.backgroundColor = c
            v.contentMode = .center
            v.tintColor = .white
            if let img = UIImage(systemName: n, withConfiguration: configuration) {
                v.image = img
            }
            stack2.addArrangedSubview(v)
        }

        for (c, n) in zip(colors, names) {
            let v = SystemImageView()
            v.backgroundColor = c
            v.contentMode = .center
            v.tintColor = .white
            if let img = UIImage(systemName: n, withConfiguration: configuration) {
                v.image = img
            }
            stack3.addArrangedSubview(v)
        }

        for (c, n) in zip(colors, names) {
            let v = CircularSystemImageView()
            v.backgroundColor = c
            v.contentMode = .center
            v.tintColor = .white
            if let img = UIImage(systemName: n, withConfiguration: configuration) {
                v.image = img
            }
            stack4.addArrangedSubview(v)
        }

    }
}

Results:

or, with a little more practical let configuration = UIImage.SymbolConfiguration(pointSize: 40, weight: .regular) to show the sizes are not being determined by the SF Symbol size:

thank you so much, for your great answer, it works :) – sirekpiotr Aug 01 '20 at 06:01 — sirekpiotr, Aug 01 '20 at 06:01

Prakash · Answer 2 · 2020-07-31T10:19:19.307

0

Remove height constraints for an image view. Instead of that use aspect ratio that would help to take position based on height of cell.

edited Jul 31 '20 at 10:19

answered Jul 31 '20 at 10:13

Prakash

812
6
16

Can you explain, how to use aspectRatio in this scenario? – sirekpiotr Jul 31 '20 at 10:15
check updated answer. If you set height constraint for 100 pixel and if your table row height is 80 pixel, then this would happen like this. So use aspect ratio instead of that. – Prakash Jul 31 '20 at 10:21
