Spring Cloud Data Flow Grafana (Prometheus) not showing stream data

Question

Installed Spring Cloud Dataflow on Kubernetes (running on DockerDesktop).

Configured Grafana and Prometheus as the per the install guide https://dataflow.spring.io/docs/installation/kubernetes/kubectl/

Created and deployed a simple Stream with time (source) and log (sink) from starter apps .

On selecting Stream dashboard icon in UI, navigates to grafana dashboard but DON'T see the stream and related metrics.

Am I missing any configuration here?

Don't see any action in Prometheus proxy log since it started scdf-server config map

kind: ConfigMap
apiVersion: v1
metadata:
  name: scdf-server
  namespace: default
  selfLink: /api/v1/namespaces/default/configmaps/scdf-server
  uid: ce23d5a3-1cb9-4580-ba1a-bf51b09850dc
  resourceVersion: '53607'
  creationTimestamp: '2020-04-29T01:28:36Z'
  labels:
    app: scdf-server
data:
  application.yaml: |-
    spring:
      cloud:
        dataflow:
          applicationProperties:
            stream:
              management:
                metrics:
                  export:
                    prometheus:
                      enabled: true
                      rsocket:
                        enabled: true
                        host: prometheus-proxy
                        port: 7001
            task:
              management:
                metrics:
                  export:
                    prometheus:
                      enabled: true
                      rsocket:
                        enabled: true
                        host: prometheus-proxy
                        port: 7001
          grafana-info:
            url: 'http://localhost:3000'
          task:
            platform:
              kubernetes:
                accounts:
                  default:
                    limits:
                      memory: 1024Mi
      datasource:
        url: jdbc:mysql://${MYSQL_SERVICE_HOST}:${MYSQL_SERVICE_PORT}/mysql
        username: root
        password: ${mysql-root-password}
        driverClassName: org.mariadb.jdbc.Driver
        testOnBorrow: true
        validationQuery: "SELECT 1"

[Following fixed the Issue]

I updated the stream definition set below in Applications.Properties it started working fine.

management.metrics.export.prometheus.rsocket.host=prometheus-proxy

Looking at the pod-list (and no errors), it looks like everything is up and running correctly. Especially, if you didn't have to change anything in the stock deployment YAMLs, it should all come together seamlessly. Perhaps you can update the post with the SCDF version in use, and we can review the set up on our side, too. — Sabby Anandan, Apr 29 '20 at 22:47
Thank you, Sabby. I found the issue, it started working after I updated the stream definition and in the Applications.Properties set management.metrics.export.prometheus.rsocket.host=prometheus-proxy — techpro, Apr 29 '20 at 22:58
Name: spring-cloud-dataflow-server Version: 2.5.0.BUILD-SNAPSHOT — techpro, Apr 29 '20 at 23:08

score 2 · Answer 1 · edited Jun 20 '20 at 09:12

2

This metrics collection flow diagram from https://github.com/spring-cloud/spring-cloud-dataflow-samples/tree/master/monitoring-samples helped to spot the issue quick. Thanks

edited Jun 20 '20 at 09:12

Community

1
1

answered Apr 29 '20 at 23:14

techpro

71
1
9

1

for future readers who come across this question, can you explain what exactly the issue was and what its solution was, which you found in that link you posted? – RyanQuey Sep 21 '21 at 03:37
