Perf Imprecise Call-Graph Report

Question

Recent Intel processors provide a hardware feature (a.k.a., Precise Event-Based Sampling (PEBS)) to access precise information about the CPU state on some sampled CPU events (e.g., e). Here is an extract from Intel 64 and IA-32 Achitecture's Software Developer's Manual: Volume 3:

18.15.7 Processor Event-Based Sampling (PEBS)

The debug store (DS) mechanism in processors based on Intel NetBurst microarchitecture allow two types of information to be collected for use in debugging and tuning programs: PEBS records and BTS records.

Based on Chapter 17 of the same reference, the DS format for x86-64 architecture is as follows: The BTS Buffer records the last N executed branches (N is dependent on the microarchitecture), while the PEBS Buffer records the following registers: IIUC, a counter is set and each event (e) occurrence increments its value. When the counter overflows, an entry is added to both of these buffers. Finally, when these buffers reach a certain size (BTS Absolute Maximum and PEBS Absolute Maximum), an interrupt is generated and the contents of the two buffers are dumped to disk. This will happen, periodically. It seems that the --call-graph dwarf backtrace data is also extracted in the same handler, Right?

1) Does this mean that LBR and PEBS (--call-graph --lbr) state, perfectly, match together?

2) How about the --call-graph dwarf output, which is not part of PEBS (as seems obvious in the above reference)? (Some RIP/RSPs do not match the backtrace)

Precisely, here is an LKML Thread, where Milian Wolff shows that the second question is, NO. But I do not fully understand the reason?

The answer to the first question is also, NO (expressed by Andi Kleen in the latter messages of the thread), which I do not understand at all.

3) Does this mean that the whole DWARF call-graph information is completely corrupted?

The above thread does not show this, and in my experiments I do not see any RIP not matching the backtrace. In other words, can I trust the majority of the backtraces?

I do not prefer the LBR method which may, itself, be imprecise. It is also limited in the size of the backtrace. Although, here is a patch to overcome the size issue. But this is recent and may be bogus.

---

UPDATE:

• How is it possible to force Perf to store only a single record in PEBS Buffer? Is it only possible to force this configuration, indirectly, e.g., when call-graph information is required for a PEBS event?

Answer 1

1. The section of the manual you quoted talks about BTS, not LBR: they are not the same thing. Later in that same thread you quoted Andi Kleen seems to indicate that the LBR snap time is actually the moment of the PMI (the interrupt that runs the handler) and not the PEBS moment. So I think all three stack approaches have the same problem.

2. DWARF stack captures definitely do not correspond exactly to the PEBS entry. The PEBS event is recorded by the hardware at runtime, and then only some time later is the CPU interrupted, at which point the stack is unwound. If the PEBS buffer is configured to hold only a single entry, these two things should at least be close and if you are lucky, the PEBS IP will be in the same function that is still at the top of the stack when the handler runs. In that case, the stack is basically correct. Since perf shows you the actual PEBS IP at the top, plus the frames below that from the capture, this ends up working in that case.

3. If you aren't lucky, the function will have changed between the PEBS capture and the handler running. In this case you get a franken-stack that doesn't make sense: the top function may not be callable from the second-from-the-top function (or something). It is not totally corrupted: it's just that everything except the top frame comes from a point after the PEBS stack was captured, and the top frame comes from PEBS, or something like that. This applies also to --call-graph fp, for the same reasons.

Most likely you never saw an invalid IP because perf shows the IP from the PEBS sample (that's the theme of that whole thread). I think if you look into the raw sample, you can see both the PEBS IP, and the handler IP, and you can see they usually won't match.

Overall, you can trust the backtraces for "time" or "cycle" profiling since they are in some sense an accurate sampling representation of execution time: it's just that they don't correspond to the PEBS moment but some time later (but why is that later time any worse than the PEBS time). Basically for this type of profiling you don't really need PEBS at all.

If you are using a different type of event, and you want fine-grained accounting of where the event took place, that's what PEBS is for. You often don't need a stack trace: just the top frame is enough. If you want stack traces, use them, but know they come from a moment in time a bit later, or use --lbr (if that works).
