Trouble setting Pandas plot X-axis

Question

I have the following dataframe:

            A                B
0    0.020336         0.017300
1    0.068807         0.042916
2    0.543051         0.261117
3    2.643319         1.208245
4    5.295754         2.425145
5   26.091538        11.936791
6   52.407236        23.968562
7  261.233778       119.663701
8  522.850657       239.565097
9  829.366556       378.151528

I would like to plot in on an XY chart where the X axis ticks are the index values and the Y axis ticks represent the range [0, 900]. The data in the columns would be plotted accordingly. When I currently plot using:

df.plot(lw=2, colormap='jet', marker='.', markersize=8)
plt.show()

I get the following:

The Y axis is fine, but the X axis appears to be showing a scaled range of the index values.

How can I make the X axis the actual values of the dataframe index? (the curves should start to appear parabolic this way).

Edit:

This would be the desired output, but with the correct number of ticks:

The X axis values are already there... in scientific notation. Would you rather have the actual standard form? — J. Linne, Apr 17 '20 at 21:19
@J.Linne That notation alters the graphs true representation (and scale). I wish for the 10 ticks of the X axis to be represented by the 10 actual values. This graph should have a curve that appears parabolic. For example, the lower numbers are all "bunched" up at the beginning, I want them evenly spread out with each getting their own respective X-tick. — pstatix, Apr 17 '20 at 21:21
Your dependence seems to be linear and the plot has correct scientific format. E.g. 1.6e7=16000000. For linear relationship: If you double the x-value your y-value doubles. Maybe you want a logarithmic scaling on the x-axis? — MachineLearner, Apr 17 '20 at 21:23
https://matplotlib.org/3.1.1/api/_as_gen/matplotlib.pyplot.xticks.html ? — J. Linne, Apr 17 '20 at 21:26
Does this answer your question? [Python Pandas: How to set Dataframe Column value as X-axis labels](https://stackoverflow.com/questions/38683709/python-pandas-how-to-set-dataframe-column-value-as-x-axis-labels). You would do `df.plot(..., xticks=df.index)`. — mcskinner, Apr 17 '20 at 21:26
@MachineLearner Not sure if I want any type of scaling on the axis. I just want the x ticks for a 1-to-1 relationship with the index of the dataframe. Notice how there are roughly 7 points clustered on the left of the graph? I would like each point to be represented by a single tick of 10 ticks along the X axis. — pstatix, Apr 17 '20 at 21:34
@mcskinner That works, however scaling is still in scientific notation. — pstatix, Apr 17 '20 at 21:35
This [Q&A on formatting the axis ticks](https://stackoverflow.com/questions/44496383/format-x-axis-on-chart-created-with-pandas-plot-method) should help. — mcskinner, Apr 17 '20 at 21:36
Your index is the first colum or do you want 0, 1, 2, ... as index? — MachineLearner, Apr 17 '20 at 21:37
@MachineLearner I want the x axis to be 100, 1000, 10000, etc. But not scaled, such that the lower values are close together (as shown), I want them spread out just across the 10 ticks representing the 10 values. — pstatix, Apr 17 '20 at 21:39

mcskinner · Answer 1 · 2020-04-17T22:22:40.313

0

# Save the index to use for labels.
x_values = df.index

# Reset the index to [0, N).
df = df.reset_index(drop=True)

# Plot the re-indexed data.
ax = df.plot(lw=2, colormap='jet', marker='.', markersize=8)

# Use the saved labels.
ax.set_xticklabels(x_values)

edited Apr 17 '20 at 22:22

answered Apr 17 '20 at 22:06

mcskinner

2,620
1
11
21

The graph now plots correctly, but my labels don't match yours, doing exactly what you've written here. I only get about 5 ticks. – pstatix Apr 17 '20 at 22:11
Can you print `df` for me and paste the formatted text in your question? I can help work with the sample data. – mcskinner Apr 17 '20 at 22:12
The dataframe is pasted in the OP now. – pstatix Apr 17 '20 at 22:14
Managed to get it working, had to set `xticks` in the `plot()` call. – pstatix Apr 17 '20 at 22:17
My mistake, I forgot to assign `ax = df.plot(...)`. Can you check if this solution works for you? – mcskinner Apr 17 '20 at 22:22

score 0 · Answer 2 · edited Jan 05 '22 at 14:35

0

df.columns = ['xaxis', 'A', 'B']
numbers = np.arange(0, 900)
df.plot(x='xaxis', y=numbers, colormap='jet')
plt.show()

edited Jan 05 '22 at 14:35

Neuron

5,141
5
38
59

answered Apr 17 '20 at 22:19

Sammiti Yadav

78
1
6

While this code may solve the question, [including an explanation](https://meta.stackoverflow.com/questions/392712/explaining-entirely-code-based-answers) of how and why this solves the problem would really help to improve the quality of your post, and probably result in more up-votes. Remember that you are answering the question for readers in the future, not just the person asking now. Please [edit](https://stackoverflow.com/posts/70583748/edit) your answer to add explanations and give an indication of what limitations and assumptions apply. – mischva11 Jan 06 '22 at 09:48
