0

I could push the data from MSSql Server to Topics on Confluent Cloud,but not from topics to BigQuery, it throws an error "Bad records in the last hour - 65"

I could able to connect the topics to bigQuery but not able to ingest the data.

MSSQL and BigQuery table format are the same first(string) last(string) raj ram

Do I need to add any other columns to ingest data such as timestamp, offset,etc.?

OneCricketeer
  • 179,855
  • 19
  • 132
  • 245
Raj
  • 585
  • 4
  • 16
  • 28

1 Answers1

2

If there are messages that can't be sent to the target they'll get written to a Dead Letter Queue with details of the problem.

From the Connectors screen you can see the ID of your connector

enter image description here

Use that id to locate a topic with the same name and a dlq- prefix.

enter image description here

You can then browse the topic and use the header information to determine the cause of the problem

enter image description here

If you prefer you can use kafkacat to view the headers:

$ docker run --rm edenhill/kafkacat:1.5.0 \
         -X security.protocol=SASL_SSL -X sasl.mechanisms=PLAIN \
         -X ssl.ca.location=./etc/ssl/cert.pem -X api.version.request=true \
         -b ${CCLOUD_BROKER_HOST} \
         -X sasl.username="${CCLOUD_API_KEY}" \
         -X sasl.password="${CCLOUD_API_SECRET}" \
         -t dlq-lcc-emj3x \
         -C -c1 -o beginning \
         -f 'Topic %t[%p], offset: %o, Headers: %h'

Topic dlq-lcc-emj3x[0], offset: 12006, Headers: __connect.errors.topic=mysql-01-asgard.demo.transactions,__connect.errors.partition=5,__connect.errors.offset=90,__connect.errors.connector.name=lcc-emj3x,__connect.errors.task.id=0,__connect.errors.stage=VALUE_CONVERTER,__connect.errors.class.name=org.apache.kafka.connect.json.JsonConverter,__connect.errors.exception.class.name=org.apache.kafka.connect.errors.DataException,__connect.errors.exception.message=Converting byte[] to Kafka Connect data failed due to serialization error: ,__connect.errors.exception.stacktrace=org.apache.kafka.connect.errors.DataException: Converting byte[] to Kafka Connect data failed due to serialization error:
        at org.apache.kafka.connect.json.JsonConverter.toConnectData(JsonConverter.java:344)
        at org.apache.kafka.connect.runtime.WorkerSinkTask.lambda$convertAndTransformRecord$1(WorkerSinkTask.java:487)
        at org.apache.kafka.connect.runtime.errors.RetryWithToleranceOperator.execAndRetry(RetryWithToleranceOperator.java:128)
        at org.apache.kafka.connect.runtime.errors.RetryWithToleranceOperator.execAndHandleError(RetryWithToleranceOperator.java:162)
        at org.apache.kafka.connect.runtime.errors.RetryWithToleranceOperator.execute(RetryWithToleranceOperator.java:104)
        at org.apache.kafka.connect.runtime.WorkerSinkTask.convertAndTransformRecord(WorkerSinkTask.java:487)
        at org.apache.kafka.connect.runtime.WorkerSinkTask.convertMessages(WorkerSinkTask.java:464)
        at org.apache.kafka.connect.runtime.WorkerSinkTask.poll(WorkerSinkTask.java:320)
        at org.apache.kafka.connect.runtime.WorkerSinkTask.iteration(WorkerSinkTask.java:224)
        at org.apache.kafka.connect.runtime.WorkerSinkTask.execute(WorkerSinkTask.java:192)
        at org.apache.kafka.connect.runtime.WorkerTask.doRun(WorkerTask.java:177)
        at org.apache.kafka.connect.runtime.WorkerTask.run(WorkerTask.java:227)
        at java.base/java.util.concurrent.Executors$RunnableAdapter.call(Executors.java:515)
        at java.base/java.util.concurrent.FutureTask.run(FutureTask.java:264)
        at java.base/java.util.concurrent.ThreadPoolExecutor.runWorker(ThreadPoolExecutor.java:1128)
        at java.base/java.util.concurrent.ThreadPoolExecutor$Worker.run(ThreadPoolExecutor.java:628)
        at java.base/java.lang.Thread.run(Thread.java:834)
Caused by: org.apache.kafka.common.errors.SerializationException: com.fasterxml.jackson.core.JsonParseException: Illegal character ((CTRL-CHAR, code 0)): only regular white space (\r, \n, \t) is allowed between tokens
 at [Source: (byte[])"

From there on in it's just a case of understanding the error. A lot of the time it's down to serialisation issues, which you can learn more about here.

Robin Moffatt
  • 30,382
  • 3
  • 65
  • 92
  • Hi @Robin Moffatt, thanks for the above answer. I'm able to push the messages to the BigQuery table which has no primary keys. But, when I try for tables with primary keys from the source table, the Json messages in Confluent creates additional fields (key.xxx) and the messages are not able to push to BQ tables. How do I resolve this? – Raj Dec 16 '19 at 23:51
  • "the messages are not able to push to BQ tables" -> do you get an error e.g. on the dead letter queue? – Robin Moffatt Dec 17 '19 at 09:51
  • 1
    I have just deleted the sink connector and re-configured it ,and strangely it worked. Thank you. – Raj Dec 18 '19 at 04:30
