For creating Jasper Report in JavaFX 11 I am using dynamic reports. I am loading report inside Swing Node but Jasper report appears only if I will click on the stack pane area and and all other components visible only if I hover over all those components. Components and report contents not loading instantly rather than it is showing on mouse hovering and report is showing when scrolling over the Stack Pane.
As this was the bug in Java 8 and seems to be resolved but in Java 11 too I am getting the same issue.
Update
Since I am not getting any response and as suggested by kleopatra I have created minimal reproducible code. Please look into this.
JavaFxJasperReportsDemo.java
package demo;
import java.util.ArrayList;
import java.util.List;
import javax.swing.SwingUtilities;
import javafx.application.Application;
import javafx.application.Platform;
import javafx.embed.swing.SwingNode;
import javafx.event.ActionEvent;
import javafx.event.EventHandler;
import javafx.fxml.FXML;
import javafx.fxml.FXMLLoader;
import javafx.scene.Parent;
import javafx.scene.Scene;
import javafx.scene.layout.AnchorPane;
import javafx.scene.layout.StackPane;
import javafx.stage.Stage;
import javafx.stage.WindowEvent;
import net.sf.dynamicreports.jasper.builder.JasperReportBuilder;
import net.sf.dynamicreports.report.builder.DynamicReports;
import net.sf.dynamicreports.report.builder.column.Columns;
import net.sf.dynamicreports.report.builder.component.Components;
import net.sf.dynamicreports.report.builder.datatype.DataTypes;
import net.sf.dynamicreports.report.constant.HorizontalTextAlignment;
import net.sf.dynamicreports.report.exception.DRException;
import net.sf.jasperreports.engine.JasperPrint;
import net.sf.jasperreports.swing.JRViewer;
public class JavaFxJasperReportsDemo extends Application{
@FXML
private StackPane stackPane;
public void start(Stage stage) throws Exception{
try{
System.out.println("Hello");
Parent root = FXMLLoader.load(getClass().getResource("/FXMLJavaFXJasperReportsDemo.fxml"));
Scene scene = new Scene(root);
stage.setScene(scene);
stage.setTitle("Java FX Demo");
stage.show();
stage.setOnCloseRequest(new EventHandler<WindowEvent>() {
public void handle(WindowEvent arg0) {
Platform.exit();
}
});
}
catch (Exception e){
throw e;
}
}
@FXML
public void loadReport(ActionEvent event) {
JasperReportBuilder report = DynamicReports.report();
List<DemoPOJO> lstDemoPOJOs=new ArrayList<DemoPOJO>();
DemoPOJO demoPOJO=new DemoPOJO();
demoPOJO.setName("ABC");
demoPOJO.setCity("Delhi");
lstDemoPOJOs.add(demoPOJO);
demoPOJO = new DemoPOJO();
demoPOJO.setName("XYZ");
demoPOJO.setCity("Agra");
lstDemoPOJOs.add(demoPOJO);
report
.columns(
Columns.columnRowNumberColumn("S No"),
Columns.column("Name", "name", DataTypes.stringType()),
Columns.column("Address", "city", DataTypes.stringType())
).title(
Components.text("Demo Java Fx Jasper Reports").
setHorizontalTextAlignment(HorizontalTextAlignment.CENTER))
.pageFooter(Components.pageXofY())
.setDataSource(lstDemoPOJOs);
try {
JasperPrint jasperPrintReport=report.toJasperPrint();
SwingNode swingNode = new SwingNode();
AnchorPane.setTopAnchor(swingNode,0.0);
AnchorPane.setBottomAnchor(swingNode,0.0);
AnchorPane.setLeftAnchor(swingNode,0.0);
AnchorPane.setRightAnchor(swingNode,0.0);
JRViewer jrViewer= new JRViewer(jasperPrintReport);
SwingUtilities.invokeLater(() ->swingNode.setContent(jrViewer)
);
stackPane.getChildren().add(swingNode);
} catch (DRException e) {
e.printStackTrace();
}
}
public static void main(String[] args){
System.out.println("Hello Main");
try{
launch(args);
}
catch (Exception e){
e.printStackTrace();
}
}
}
DemoPOJO.java
package demo;
public class DemoPOJO {
String name;
String city;
public String getName() {
return name;
}
public void setName(String name) {
this.name = name;
}
public String getCity() {
return city;
}
public void setCity(String city) {
this.city = city;
}
}
FXMLJavaFXJasperReportsDemo.fxml
<?xml version="1.0" encoding="UTF-8"?>
<?import javafx.scene.control.Button?>
<?import javafx.scene.control.Label?>
<?import javafx.scene.layout.AnchorPane?>
<?import javafx.scene.layout.StackPane?>
<AnchorPane maxHeight="-Infinity" maxWidth="-Infinity" minHeight="-Infinity" minWidth="-Infinity" prefHeight="561.0" prefWidth="745.0" xmlns="http://javafx.com/javafx/11.0.1" xmlns:fx="http://javafx.com/fxml/1" fx:controller="demo.JavaFxJasperReportsDemo">
<children>
<Label layoutX="345.0" layoutY="24.0" text="Java FX Demo Application" />
<StackPane fx:id="stackPane" layoutX="14.0" layoutY="120.0" prefHeight="392.0" prefWidth="722.0" />
<Button layoutX="62.0" layoutY="68.0" mnemonicParsing="false" onAction="#loadReport" text="Load Report" />
</children>
</AnchorPane>
Dependencies I am using are:-
<dependency>
<groupId>net.sourceforge.dynamicreports</groupId>
<artifactId>dynamicreports-core</artifactId>
<version>6.1.0</version>
</dependency>
<dependency>
<groupId>org.openjfx</groupId>
<artifactId>javafx-controls</artifactId>
<version>11</version>
</dependency>
<dependency>
<groupId>org.openjfx</groupId>
<artifactId>javafx-fxml</artifactId>
<version>11</version>
</dependency>
<dependency>
<groupId>javax.xml.bind</groupId>
<artifactId>jaxb-api</artifactId>
<version>2.2.11</version>
</dependency>
<dependency>
<groupId>org.openjfx</groupId>
<artifactId>javafx-swing</artifactId>
<version>11-ea+24</version>
</dependency>
Output
After clicking on load report button only one save icon is visible no report is visible.
After clicking on Stack Pane Area now Report is visible.
After hovering over another icon now Print icon is visible.
After hovering over other icons as well they are getting visible one by one.
