I am trying to use the simple .plot() function from xarray on a netCDF file from the atmospheric composition analysis group.

Say I want to plot the PM2.5 concentration from North America in 2000 available here.

When I try to plot the dataset I get an empty figure even though the data exists as shown by the legend bar.

import xarray as xr
import netCDF4 as nc
import matplotlib.pyplot as plt

path_to_nc="my/path/file.nc"

ds=xr.open_dataset(path_to_nc)
print(ds)
>>>

<xarray.Dataset>
Dimensions:  (LAT: 4550, LON: 9300)
Coordinates:
  * LON      (LON) float64 -138.0 -138.0 -138.0 -138.0 ... -45.03 -45.01 -45.01
  * LAT      (LAT) float64 68.0 67.99 67.97 67.96 ... 22.53 22.52 22.51 22.5
Data variables:
    PM25     (LAT, LON) float32 ...

The file does have values (not just nan).

# Range of values:
ds=ds['PM25']
print(ds)
>>>

<xarray.DataArray 'PM25' (LAT: 4550, LON: 9300)>
array([[1.6, 1.6, 1.6, ..., 1.2, 1.2, 1.2],
       [1.6, 1.6, 1.6, ..., 1.2, 1.2, 1.2],
       [1.6, 1.6, 1.6, ..., 1.2, 1.2, 1.2],
       ...,
       [nan, nan, nan, ..., nan, nan, nan],
       [nan, nan, nan, ..., nan, nan, nan],
       [nan, nan, nan, ..., nan, nan, nan]], dtype=float32)
Coordinates:
  * LON      (LON) float64 -138.0 -138.0 -138.0 -138.0 ... -45.03 -45.01 -45.01
  * LAT      (LAT) float64 68.0 67.99 67.97 67.96 ... 22.53 22.52 22.51 22.5
Attributes:
    standard_name:  PM25
    units:          ug/m3

But if I try to plot the values then I get an empty ax.

ds.plot()

Output

forgef
  • 41
  • 1
  • 5

2 Answers2

4

The problem is that you are trying to plot too many data all together. If you just select a subset of them it works:

#select data
dssel=ds.where((-125 < ds.LON) & (ds.LON < -115)
         & (49 < ds.LAT) & (ds.LAT < 55), drop=True)
#plot PM2.5
plt.figure()
dssel.PM25.plot()

Here the result: enter image description here

Interestingly if you plot the data using matplotlib directly it is much faster and I'm able to plot the entire dataset (on my 4 years old and not particularly fast laptop it takes about 20 seconds). I used netCDF4 library to load the PM2.5 dataset in this case.

from netCDF4 import Dataset
nc_fid = Dataset(fpath, 'r')

lats = nc_fid.variables['LAT'][:]  # extract/copy the data
lons = nc_fid.variables['LON'][:]
PM25 = nc_fid.variables['PM25'][:]

fig, axs = plt.subplots(figsize=(15, 10), nrows=2,ncols=1,gridspec_kw={'height_ratios': [20,1.5]},constrained_layout=True)
pcm=axs[0].pcolormesh(lons,lats,PM25,cmap='viridis')
cbar=fig.colorbar(pcm,cax=axs[1], extend='both', orientation='horizontal')
cbar.set_label('PM 2.5 [$\mu$g m$^{-3}]$')

enter image description here

baccandr
  • 1,090
  • 8
  • 15
3

I discovered that the initial problem is related to function pcolormesh() embedded as default plotting option in xarray (ds.plot() == ds.plot.pcolormesh()). If one uses ds.plot.imshow() the figures comes up faster and correctly, without needing to select a subset of the data (more info here: http://xarray.pydata.org/en/stable/plotting.html)

Lionel Arteaga
  • 41
  • 6
  • After going through several solutions, this works for me. Thank you. By using the .imshow, the image came out faster and the ram consumption is also lower. I have also tried the slicing as suggested by the accepted answer, and it is not working for me. – jona Apr 28 '21 at 19:12
