How to set a SwiftUI view as a cell to a CollectionView

Question

I found SwiftUI Text views to be extremely easy to create Labels with custom designs. So I wanted to use it as a view to a regular UIKit UICollectionViewCell.

This is my code so far (you can copy and paste inside Xcode 11).

import SwiftUI
import UIKit

struct ContentView: View {
    var body: some View {
        CollectionComponent()
    }
}

#if DEBUG
struct ContentView_Previews: PreviewProvider {
    static var previews: some View {
        ContentView()
    }
}
#endif

struct CollectionComponent : UIViewRepresentable {
    func makeCoordinator() -> CollectionComponent.Coordinator {
        Coordinator(data: [])
    }

    class Coordinator: NSObject, UICollectionViewDataSource, UICollectionViewDelegate {
        var data: [String] = []

        init(data: [String]) {

            for index in (0...1000) {
                self.data.append("\(index)")
            }
        }

        func collectionView(_ collectionView: UICollectionView, numberOfItemsInSection section: Int) -> Int {
            data.count
        }

        func collectionView(_ collectionView: UICollectionView, cellForItemAt indexPath: IndexPath) -> UICollectionViewCell {
            let cell = collectionView.dequeueReusableCell(withReuseIdentifier: "cell", for: indexPath) as! GenericCell
            cell.customView.rootView = AnyView(
                Text(data[indexPath.item]).font(Font.title).border(Color.red)
            )
            return cell
        }
    }


    func makeUIView(context: Context) -> UICollectionView {
        let layout = UICollectionViewFlowLayout()
        layout.estimatedItemSize = UICollectionViewFlowLayout.automaticSize
        layout.scrollDirection = .vertical
        let cv = UICollectionView(frame: .zero, collectionViewLayout: layout)
        cv.dataSource = context.coordinator
        cv.delegate = context.coordinator
        cv.register(GenericCell.self, forCellWithReuseIdentifier: "cell")

        cv.backgroundColor = .white
        layout.minimumInteritemSpacing = 0
        layout.minimumLineSpacing = 0
        return cv
    }
    func updateUIView(_ uiView: UICollectionView, context: Context) {

    }
}


open class GenericCell: UICollectionViewCell {
    public var customView = UIHostingController(rootView: AnyView(Text("")))
    public override init(frame: CGRect) {
        super.init(frame: frame)
        configure()
    }
    public required init?(coder aDecoder: NSCoder) {
        super.init(coder: aDecoder)
        configure()
    }
    private func configure() {
        contentView.addSubview(customView.view)
        customView.view.preservesSuperviewLayoutMargins = false
        customView.view.translatesAutoresizingMaskIntoConstraints = false

        NSLayoutConstraint.activate([
            customView.view.leftAnchor.constraint(equalTo: contentView.layoutMarginsGuide.leftAnchor),
            customView.view.rightAnchor.constraint(equalTo: contentView.layoutMarginsGuide.rightAnchor),
            customView.view.topAnchor.constraint(equalTo: contentView.layoutMarginsGuide.topAnchor),
            customView.view.bottomAnchor.constraint(equalTo: contentView.layoutMarginsGuide.bottomAnchor),
        ])
    }
}

The first screen is good.

But as i scroll past the end of visible screen it looks like

Is there something i am doing wrong with autoresizing my cells? Or is this just more SwiftUI bugs?

[Edit] I have accepted a SwiftUI answer, but If any one can provide me a fix to work with UIKit as asked in this question, I will accept.

instead of using UIcollectionview you could use a list within a list to get the same effect — yawnobleix, Aug 08 '19 at 07:12
Could you possibly give us how you accomplish this using `UICollectionView` and `UICollectionViewCell`? This would help point to the specific issue - which may be that "for now" you cannot do this in `SwiftUI`. For instance, is this an issue related to the auto-layout constraints in either component? Is this related to trying to make a "lazy" or "reusable cell" version of a collection view in SwiftUI, which doesn't exist? Or is this a Dynamic Type issue? In other words (and forgive me with the play on words) - how would you handle this in a `UIKit` only app? — , Sep 21 '19 at 15:22
@dfd If i had to do this with UIKit, it would simply be a collectionView on Storyboard. With a registered cell. There isn't any different (except less code because of using a storyboard) — swift nub, Sep 21 '19 at 16:28

utgoer · Answer 1 · 2020-02-02T22:17:50.833

I made some modifications and It works but I do not think this is the best practice.

import SwiftUI
import UIKit

struct ContentView: View {
    var body: some View {
        CollectionComponent()
    }
}

#if DEBUG
struct ContentView_Previews: PreviewProvider {
    static var previews: some View {
        ContentView()
    }
}
#endif

struct CollectionComponent : UIViewRepresentable {
    func makeCoordinator() -> CollectionComponent.Coordinator {
        Coordinator(data: [])
    }

    class Coordinator: NSObject, UICollectionViewDataSource, UICollectionViewDelegate {
        var data: [String] = []

        init(data: [String]) {

            for index in (0...1000) {
                self.data.append("\(index)")
            }
        }

        func collectionView(_ collectionView: UICollectionView, numberOfItemsInSection section: Int) -> Int {
            data.count
        }
        func collectionView(_ collectionView: UICollectionView, layout collectionViewLayout: UICollectionViewLayout, sizeForItemAt indexPath: IndexPath) -> CGSize {
            return CGSize(width: collectionView.frame.width/2.5, height: collectionView.frame.width/2)
        }

        func collectionView(_ collectionView: UICollectionView, cellForItemAt indexPath: IndexPath) -> UICollectionViewCell {
            let cell = collectionView.dequeueReusableCell(withReuseIdentifier: "cell", for: indexPath) as! GenericCell

            cell.customView?.rootView = Text(data[indexPath.item])

            return cell
        }
    }


    func makeUIView(context: Context) -> UICollectionView {
        let layout = UICollectionViewFlowLayout()
        layout.scrollDirection = .vertical
        let cvs = UICollectionView(frame: .zero, collectionViewLayout: layout)
        cvs.dataSource = context.coordinator
        cvs.delegate = context.coordinator
        cvs.register(GenericCell.self, forCellWithReuseIdentifier: "cell")

        cvs.backgroundColor = .white
        return cvs
    }
    func updateUIView(_ uiView: UICollectionView, context: Context) {

    }
}


public class GenericCell: UICollectionViewCell {

    public var textView = Text("")
    public var customView: UIHostingController<Text>?
    public override init(frame: CGRect) {
        super.init(frame: .zero)


        customView = UIHostingController(rootView: textView)
        customView!.view.translatesAutoresizingMaskIntoConstraints = false
        contentView.addSubview(customView!.view)

        customView!.view.topAnchor.constraint(equalTo: contentView.topAnchor).isActive = true
        customView!.view.leftAnchor.constraint(equalTo: contentView.leftAnchor).isActive = true
        customView!.view.rightAnchor.constraint(equalTo: contentView.rightAnchor).isActive = true
        customView!.view.bottomAnchor.constraint(equalTo: contentView.bottomAnchor).isActive = true
    }
    public required init?(coder aDecoder: NSCoder) {
        fatalError("init(coder:) has not been implemented")
    }
}

John M. · Answer 2 · 2019-10-14T18:17:14.533

-2

Using just SwiftUI, you can put together a view that reflows Text views like you are wanting. The code is on GitHub, but is pretty long, so I won't post it here. You can find my explanation of what is going on in this answer. Here's a demo:

edited Oct 14 '19 at 18:17

answered Sep 27 '19 at 15:05

John M.

8,892
4
31
42

it would be nice if that GitHub is arranged into a project. – swift nub Sep 28 '19 at 02:04
4

Why is everyone posting answer with SwithUi scroll view when the question clearly states that the want to use UIKit component Collection view inside a SwiftUI framework? The correct answer should show to use collection View inside SwiftUi using UIViewRepresentable. Even I want to achieve the same - USE COLLECTION VIEW CUMPOLSORY... – Tejas Oct 01 '19 at 08:02
the effect the poster wanted can be achieved with using just SwiftUi, who says that this approach is wrong? – yawnobleix Oct 01 '19 at 09:14
@yawnobleix Please read the question and title. It says about using UICollectionView – Tejas Oct 02 '19 at 03:20
@Tejas The reason I added this answer (although it only uses SwiftUI) is that the poster upvoted and commented favorably on another SwiftUI answer. He noted that what he wanted was a reflowing layout, which the first SwiftUI answer did not provide. I assume then that he (and possibly others) might have decided to use UICollectionView to wrap SwiftUI views so they could get reflow. If this is the case, then a pure SwiftUI solution, which avoids the clipping issues in his UICollectionView workaround, would be of interest. – John M. Oct 02 '19 at 15:05
@JohnM. My only point is to stick to the requirement when you post the answer. Otherwise, it would be very misleading for a person who is looking for a solution and finds something different. Anyways, Could you please post the solution using CollectionView? – Tejas Oct 03 '19 at 00:54
1

@Tejas you are correct. I am still looking for a UIKit fix. If any one provides it, i will accept it. I have also edited the question above to reflect what i just said here. – swift nub Oct 06 '19 at 12:05

score -2 · Accepted Answer · answered Oct 12 '20 at 13:40

This is a pure SwiftUI solution. It will wrap what ever view you give it and give you the effect you want. Let me know if it works for you.

struct WrappedGridView: View {
    let views: [WrappedGridViewHolder]
    var showsIndicators = false
    var completion:(Int)->Void = {x in}
    var body: some View {
        GeometryReader { geometry in
            ScrollView(showsIndicators: showsIndicators) {
                self.generateContent(in: geometry)
            }
        }
    }

    init(views: [AnyView], showsIndicators: Bool = false, completion: @escaping (Int)->Void = {val in}) {
        self.showsIndicators = showsIndicators
        self.views = views.map { WrappedGridViewHolder(view: $0) }
        self.completion = completion
    }

    private func generateContent(in g: GeometryProxy) -> some View {
        var width = CGFloat.zero
        var height = CGFloat.zero

        return
            ZStack(alignment: .topLeading) {
                    ForEach(views) { item in
                        item
                            .padding(4)
                            .alignmentGuide(.leading) { d in
                                if (abs(width - d.width) > g.size.width) {
                                    width = 0
                                    height -= d.height
                                }
                                let result = width
                                if item == self.views.last {
                                    width = 0
                                } else {
                                    width -= d.width
                                }
                                return result
                            }
                            .alignmentGuide(.top) { d in
                                let result = height
                                if item == self.views.last {
                                    height = 0
                                }
                                return result
                            }
                            .onTapGesture {
                                tapped(value: item)
                            }
                    }
            }
            .background(
                GeometryReader { r in
                    Color
                        .clear
                        .preference(key: SizePreferenceKey.self, value: r.size)
                }
            )
    }

    func tapped(value: WrappedGridViewHolder) {
        guard let index = views.firstIndex(of: value) else { assert(false, "This should never happen"); return }
        completion(index)
    }
}

struct SizePreferenceKey: PreferenceKey {
    typealias Value = CGSize
    static var defaultValue: Value = .zero
    static func reduce(value: inout Value, nextValue: () -> Value) {

    }
}

extension WrappedGridView {
    struct WrappedGridViewHolder: View, Identifiable, Equatable {
        let id = UUID().uuidString
        let view: AnyView
        var body: some View {
            view
        }

        static func == (lhs: WrappedGridViewHolder, rhs: WrappedGridViewHolder) -> Bool { lhs.id == rhs.id }
    }
}

This is not an answer to the question "How to set a SwiftUI view as a cell to a CollectionView" — Andrzej Polis, Nov 19 '20 at 07:57
the poster needed it to work with collectionview because it was getting truncated. I merely showed that collection view wasnt needed. Maybe ask the original poster to change the question? — Just a coder, Nov 19 '20 at 14:11

score -3 · Answer 4 · answered Aug 11 '19 at 16:21

-3

Here is a solution using just purely swifUI, note this doesn't have the benefits which come with CollectionView (ie controlling elements which are off of the screen)

struct doubleList: View {
    var body: some View {
        VStack{
            ForEach(1 ..< 10) {
                index in
                HStack{
                ForEach(1 ..< 10) {
                    index2 in
                    Text(String(index) + String(index2))
                        .frame(width: 35.0)
                    }
                }
            }
        }
    }
}

This will give a result looking like this

answered Aug 11 '19 at 16:21

yawnobleix

1,204
10
21

the problem here is that the structure is rigid. In this case the data in numbers. In the real code, the data is Words. What is needed isn't a rigid 10x10 row/height. What is needed is that when a word reaches the end, it should wrap and go to the next line. I have not found a way to do this yet. (i did give you +1 though) – swift nub Sep 19 '19 at 12:29
1

so you want multiple words of various length to be displayed in a box on the screen? it would be helpful in the future if you include more details in your question – yawnobleix Sep 24 '19 at 13:21
Why is everyone posting answer with SwithUi scroll view when the question clearly states that the want to use UIKit component Collection view inside a SwiftUI framework? The correct answer should show to use collection View inside SwiftUi using UIViewRepresentable. – Tejas Oct 01 '19 at 08:01
