I am trying to create two plots in Gnuplot side by side using multiplot. The problem is that how can I add inset to each one.

Hossein Tahmasbi
  • 15
  • 1
  • 1
  • 7

1 Answers1

3

I wanted to point your attention to the gnuplot demo page (gnuplot demo page), however, I couldn't find an example of such insets in multiplots right away.

Simply use set multiplot layout 1,2 and continue plotting but with different sizes and offsets. See example below:

Code:

### multiplot with insets
reset session

set multiplot layout 1,2
    plot x**2
    plot x**3

    set size 0.3,0.3
    set origin 0.1,0.6
    set ytics 0.5
    plot sin(x)

    set size 0.3,0.3
    set origin 0.6,0.6
    plot cos(x)
unset multiplot
### end of code

Result:

enter image description here

theozh
  • 22,244
  • 5
  • 28
  • 72
  • Perhaps the following might also be of interest... https://stackoverflow.com/q/65640035/7295599 – theozh Feb 09 '21 at 14:35
