How do I make pandas catagorical stacked bar chart scale to 100%

Question

I am trying to produce a stacked bar chart based on counts of different catagories (the 'Class' column in my dataframe).

My data is also grouped by another catagory (the 'STRAT' column).

I have the actual numbers plotting, but I want to get these as proportions to total 100%. ie. so all the bars are the full height of the chart, like a vertical pie chart, for each 'STRAT' catagory.

Like this:

Below is what I have tried and the result.

Sample is a small part of a large dataset.

import pandas as pd

df_test= pd.read_excel('df.xlsx')

df_test

From    To  Interval (m)    Class   STRAT   Total %S
308     309    1            PAF     CBC     4.15
309     310    1            PAF     CBC     3.76
320     321    1            UC      CBC     0.85
330     331    1            UC      CBC     0.698
342     343    1            NAF     LBB     0.259
376     377    1            NAF     LBB     0.395
412     413    1            UC      LBB     1.19
51      52     1            PAF     UBB     2.27
420     420.5  0.5          UC      UAB     2.85
189     190    1            PAF     LBB     1.52
520     521    1            NAF     UAB     1.45
632     633    1            NAF     UAB     0.0615
644     645    1            NAF     UAB     0.178


df_test.groupby(['STRAT', 'Class']).size().unstack().plot.bar(stacked=True)

This gives me a stacked bar chart but it is not scaled to 100%

I can't find a neat way to put the "Class count/total_counts" calculation into the code to get percentage instead of number.

score 10 · Accepted Answer · edited Jan 04 '23 at 15:13

There is a lot you can do with matplotlib to forcibly scale the y axis so that it normalizes everything to 100% as seen here: 100% Stacked Bar Chart in MatPlotLib

However, your problem can be tackled much more simply.

If this is your dataframe with two key columns, Class and STRAT:

import pandas as pd
import numpy as np
df = pd.DataFrame({'Class': 2*['a', 'b', 'c', 'd'],'STRAT': ['x', 'y', 'x', 'z','y','x','z','w'],'value': np.random.randint(0, int(1e2),8)})

Then you can calculate the %ges easily this way:

df_pct = (df.groupby(['STRAT','Class'])['value'].count()/df.groupby(['STRAT'])['value'].count())

And you can finally plot using exactly the way you have in your code:

df_pct.unstack().plot.bar(stacked=True)
