Using CoDeSys, I have a drop down list for a visualization that uses an enumeration of values for the options in the list. The enumeration comes from a separate library and for my particular application I would like to use only a subset of the enumerated values in the drop-down. So in order to accomplish this, I have a text list containing only two values, 5 and 7. Text list for drop-down elements

This seems easy enough but when I go to run this particular drop-down I see the two values correctly but I also see numbers up to 12 for the missing IDs. 12 is weird since the enumeration has 22 enumerated values.

enter image description here enter image description here

Is it possible to have only the two values show in the drop-down without making the ID's 0 and 1? I would really like to use the library enumeration.

Michael LeVan
  • 528
  • 2
  • 8
  • 21

1 Answers1

2

It turns out there is a checkbox that must be checked called "Filter Missing Textentries" so that the drop-down list to only contains the values given in the text list. Once that box is checked it will remove the random numbered values.

enter image description here
