Remove up button from action bar when navigating using BottomNavigationView with Android Navigation UI library

Question

I've created a small app that has three fragments for top-level navigation through a BottomNavigationView. If you launch the app and click on a navigation button on the bottom nav, you are presented with an up button in the action bar. Here is the code for the activity:

class MainActivity : AppCompatActivity() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.main_activity)

        setSupportActionBar(toolbar)

        val navController = navHostFragment.findNavController()
        setupActionBarWithNavController(this, navController)
        setupWithNavController(bottomNav, navController)
    }

    override fun onSupportNavigateUp(): Boolean
            = findNavController(navHostFragment).navigateUp()

}

Here is a screenshot of the result. The app is launched on the home screen and all I've done is simply click the profile button from the BottomNavigationView.

I've tried listening to the BottomNavigationView's item selections and navigating manually using different NavOptions to no avail. Is there anything we can do to avoid showing an up button in the action bar while the user is navigating with a BottomNavigationView?

score 51 · Accepted Answer · edited Feb 01 '20 at 11:18

51

Starting with 1.0.0-alpha07 you can use AppBarConfiguration to configure that behaviour.

AppBarConfiguration has a Builder constructor so you can create a new Builder with a specific set of top level destinations, referenced by their id (this id is the one you set on your navigation layout).

Create new AppBarConfiguration:

val appBarConfiguration = AppBarConfiguration
            .Builder(
                    R.id.navigationHomeFragment,
                    R.id.navigationListFragment,
                    R.id.navigationProfileFragment)
            .build()

Then, instead of setupActionBarWithNavController(this, navController) you need to call setupActionBarWithNavController(this, navController, appBarConfiguration)

This is the right way to handle top navigation behaviours.

edited Feb 01 '20 at 11:18

k4dima

6,070
5
41
39

answered Nov 25 '18 at 01:11

Javier Cancio

1,418
12
18

3

Uh, okay this component is like magic now I don't know wtf is going on :) – Daniel Wilson Apr 11 '19 at 14:54
Great solution (Y) – Anmol May 30 '19 at 10:49
Saved the day :) Thanks – Rinav Aug 20 '19 at 14:05
2

Thanks. But starting with 1.0.0 I had to call setupWithNavController( navController, appBarConfiguration) to make it work – Dawit Abraham Sep 19 '19 at 22:18
thank you , great solution to hide Up Navigation for some fragments – widjajayd May 30 '20 at 03:17

Julio Lemus · Answer 2 · 2018-10-26T19:54:16.473

I had the same problem and I found a way to get the current fragment with the NavController.addOnNavigatedListener, so I applied the following logic within my Activity and for now it works for me

override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    setContentView(R.layout.activity_home)
    val navHost = supportFragmentManager
            .findFragmentById(R.id.navHostFragment) as NavHostFragment

    navHost.navController.addOnNavigatedListener { _, destination ->
        val showButton = showUpButton(destination.id)
        //Here occurs the magic
        supportActionBar?.setDisplayShowHomeEnabled(showButton)
        supportActionBar?.setDisplayHomeAsUpEnabled(showButton)
    }
}

//Check according to your convenience which fragment id
//should show or hide the "Up Button"
private fun showUpButton(id: Int): Boolean {
    return id != R.id.your_home_fragment && id != R.id.your_list_fragment
            && id != R.id.your_profile_fragment
}

And this is my project...

I do not know if it is the best option but if someone has any better suggestion, it will be welcome

score 5 · Answer 3 · edited Jul 25 '19 at 11:40

5

Use this instead of setupWithNavController:

navController.addOnNavigatedListener(new NavController.OnNavigatedListener() {
     @Override
     public void onNavigated(@NonNull NavController controller, @NonNull NavDestination destination) {
         toolbar.setTitle(destination.getLabel());
     }
});

Or the equivalent in Kotlin.

The only thing setupWithNavController does is add a listener to change the toolbar title, and creates the up button. If you don't want the up button, just add a listener which changes the toolbar title only.

edited Jul 25 '19 at 11:40

JJD

50,076
60
203
339

answered Sep 20 '18 at 18:43

Bob bobbington

1,225
13
12

Thanks Bob, this solved my problem. People like you are why I love Stackoverflow. – szaske Nov 06 '18 at 00:19
keep in mind that the `addOnNavigatedListener` has been changed to `addOnDestinationChangedListener` in new version of navigation component – Hossein Farrokhi Jul 17 '22 at 10:41

vitiello.antonio · Answer 4 · 2020-05-03T13:52:53.693

You could set the navigation icon to null, or change the icon only for some destinations eg:

1) In Kotlin:

navController.addOnDestinationChangedListener { _, destination, _ ->
            toolbar.title = destination.label
            toolbar.navigationIcon = null
}

2) In Java:

hostFragment.getNavController().addOnDestinationChangedListener(new OnDestinationChangedListener() {
    public final void onDestinationChanged(@NotNull NavController controller, @NotNull NavDestination destination, @Nullable Bundle arguments) {
        toolbar.setTitle(destination.getLabel());
        toolbar.setNavigationIcon(null);
    }
});

score 1 · Answer 5 · edited Jul 25 '19 at 11:39

1

If you are using NavigationUI.setupWithNavController check out onNavDestinationSelected.

Inside your bottom navigation view menu.xml, add android:menuCategory="secondary" to the corresponding MenuItem:

<?xml version="1.0" encoding="utf-8"?>
<menu xmlns:android="http://schemas.android.com/apk/res/android">

  <item
    android:id="@+id/profileFragment"
    android:icon="@drawable/bottom_nav_icon_profile"
    android:menuCategory="secondary"
    android:title="@string/profile" />

edited Jul 25 '19 at 11:39

JJD

50,076
60
203
339

answered Jun 12 '19 at 14:10

CHAN

1,518
18
16

Applying the `android:menuCategory="secondary"` attribute to the items in the bottom navigation *menu.xml* does **not hide** the up-button in my case. I was able to hide it by applying the `AppBarConfiguration` as [suggested by Javier Cancio](https://stackoverflow.com/a/53463839/356895). - Setting `secondary` however has the effect that when BACK is pressed the navigation returns to the **previous** bottom navigation element (having 3 or more). Without `secondary` always the **primary** element will be navigated to. Is there anything I am missing with your answer? – JJD Jul 25 '19 at 12:07

score 0 · Answer 6 · answered Oct 21 '20 at 17:41

In Java this works for me:

@Override
protected void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    setContentView(R.layout.activity_main);

    Toolbar toolbar = findViewById(R.id.toolbar);
    setSupportActionBar(toolbar);

    navController = Navigation.findNavController(this, R.id.nav_host_fragment);
    AppBarConfiguration appBarConfiguration = new AppBarConfiguration
            .Builder(navController.getGraph())
            .build();
    NavigationUI.setupWithNavController(toolbar, navController, appBarConfiguration);

    navController.addOnDestinationChangedListener((controller, destination, arguments) -> {
        toolbar.setTitle(destination.getLabel());
        toolbar.setNavigationIcon(null);
    });
