install Lattice Diamond 3.10 on my computer with Manjaro 17.1 and everything works correctly just because of a problem. The programming tool does not work, when I try to execute it I get a window with a message:

"can not load library: /usr/local/diamond/3.10_x64/bin/lin64/toolapps/libdvmapp.so: (libusb-0.1.so.4: the shared object file can not be opened: the file does not exist or the directory)"

already downloaded and I put the library in the corresponding directory but still does not let me run it

Any suggestions to solve it, I would appreciate it very much Thank you

1

Virb
  • 1,639
  • 1
  • 16
  • 25
Cristian Piste
  • 23
  • 7

2 Answers2

0

I had to install the following libraries:

libusb 1.0.21-2 libgusb 0.2.11-1 libusb-compat 0.1.5-1 libusbmuxd 1.0.10+13dc724e70-1

And the programming tool works

Cristian Piste
  • 23
  • 7
  • If you'd read the [software documentation](http://www.latticesemi.com/-/media/LatticeSemi/Documents/InstallationGuides/Diamond/Diamond38_Installation_Guide_for_Linux.ashx?document_id=51751&sa=U&ved=0ahUKEwiGv9jZhZnaAhXFKlAKHTe_BC0QFggLMAA&usg=AOvVaw2CS1c6tU20PkJgYtlmT8SN), you'd found a list of library dependencies... – JHBonarius Apr 01 '18 at 12:19
0

I already had all of the dependencies listed by Cristian in place. I had to install libusb-dev and it worked.

sudo apt install libusb-dev
