I have a requirement to show the value of bar at the end of bar as shown in the below imgae: Chart Image which is showing bar value at the end enter image description here

It might be done by Custom XMl, but in which attribute we need to modify? Any help is appreciated. Thanks in advance.

Naresh
  • 16,698
  • 6
  • 112
  • 113
Karishma Sahu
  • 39
  • 1
  • 3

4 Answers4

2

Select the series, and search for Label, Set Show=Yes, Position=Outside Bar Edge

Uday Shankar
  • 438
  • 1
  • 3
  • 16
1

On Apex 5.1.1, you should

  • navigate to Series
  • go to Label property
  • set "Show = yes"
  • set "Position = outside bar edge"

The result looks like the one you described.

You didn't specify which Apex version you use. "Custom XML" sounds like 4.x. If that's so, sorry - don't have it any more and can't test it.

Littlefoot
  • 131,892
  • 15
  • 35
  • 57
  • Thanks for you response. I am using Apex 5.0.1, I searched in label property, but couldn't find Position option there. Is there any other way to do that? – Karishma Sahu Mar 07 '18 at 10:43
0

The default setting is to display the values. Make sure the "values" ​​option is checked in the chart attributes (image below). enter image description here Example: https://apex.oracle.com/pls/apex/f?p=145797:10

If you need to edit the graph xml you can use this documentation: http://6.anychart.com/products/anychart/docs/users-guide/index.html

Go to: Labels and Tootips >>> Data Labels Formatting

romeuBraga
  • 2,135
  • 1
  • 8
  • 20
0

(APEX 5.1) Or if you are using stacked bar chart use the following javascript to add total to bar:

Chart -> attributes -> JavaScript Initialization Code:

function( options ){

// Set the stackLabel attribute, to display the stack total above the given stack category
options.stackLabel = "on";
return options;

}
