CSS Grid: Is it possible to apply color to grid gaps?

Question

Is there a way to style more than just the width of the grid gaps within the CSS grid layout module? I can't find anything about it in the documentation, however one would tend to think that it would be possible as grid gaps tend to be colored in many designs. If it is not possible, is there a workaround?

Also, please post working code, so we can reproduce the problem. — Michael Benjamin, Aug 25 '17 at 15:50
@Michael_B There's no problem to reproduce; that's not what I asked. I'm trying to work out the solution before I jump in and code myself into a corner. I edited the question to include a screenshot of the layout. — Taishi, Aug 25 '17 at 17:08
Michael_B is asking for the existing HTML and CSS used to create your layout. If it's just a flat grid with all the bare necessities, though, your question should be fairly self-explanatory. — BoltClock, Aug 25 '17 at 17:33
Unfortunately no, but a decent workaround I've found is to set the `background-color` of the elements inside the grid and space them using those elements' `padding-bottom` or `padding-right` — BallpointBen, Oct 09 '20 at 20:48

score 23 · Accepted Answer · answered Dec 20 '17 at 21:39

23

Sadly, there is currently no way in the CSS Grid spec to style grid-gap. I came up with a solution that works well though that involves just html and css: show border grid lines only between elements

answered Dec 20 '17 at 21:39

eriklharper

2,882
5
25
28

Jan Fässler · Answer 2 · 2018-03-15T21:57:18.813

Instead to use the solution above I recommend to use border with pseudo-classes because if you have an irregular amount of "table cells" you will end up with an ugly color filled cell at the end of the "table".

If you want to use borders between the "table cells" and you have not always the same amount of cells you can do something like this (this example would also work with flexbox):

.wrapper {
  display: grid;
  grid-template-columns: repeat(2, auto);
  /* with flexbox:
  display: flex;
  flex-wrap: wrap;
  */
}

/* Add border bottom to all items */
.item {
  padding: 10px;
  border-bottom: 1px solid black;
  /* with flexbox:
  width: calc(50% - 21px);
  */
}

/* Remove border bottom from last item & from second last if its odd */
.item:last-child, .item:nth-last-child(2):nth-child(odd) {
  border-bottom: none;
}

/* Add right border to every second item */
.item:nth-child(odd) {
  border-right: 1px solid black;
}

<div class="wrapper">
  <div class="item">BOX 1</div>
  <div class="item">BOX 2</div>
  <div class="item">BOX 3</div>
  <div class="item">BOX 4</div>
  <div class="item">BOX 5</div>
</div>

This strategy does not work when a grid element has a defined width, e.g. `
BOX 4
` (though I'm not sure if it's valid according to specific to have grid elements with a defined width). — Abdull, May 02 '22 at 09:35

BoltClock · Answer 3 · 2017-08-25T17:57:26.093

For instance: if one has a 5x5 grid of squares, is the only way to get colored grid lines to fill the grid with 25 elements and apply borders to those same elements?

You could do that, but grid borders do not collapse the same way that table borders can with the border-collapse property, and unlike grid gaps they'll be applied to the perimeter of your grid along with the inner borders, which may not be desired. Plus, if you have a grid-gap declaration, the gaps will separate your grid item borders much like border-collapse: separate does with table borders.

grid-gap is the idiomatic approach for spacing grid items, but it's not ideal since grid gaps are just that: empty space, not physical boxes. To that end, the only way to color these gaps is to apply a background color to the grid container.

It seems to me that a way to style grid lines, just as one can do with text column dividers, would be a good addition. The solution I've gone with is simply filling the grid full of auto-placing empty divs with right and bottom borders. Visually it's a perfect solution, however looking at the html and seeing 22 empty divs is irksome. — Taishi, Aug 25 '17 at 19:14

score 10 · Answer 4 · answered Jan 16 '19 at 19:32

I added the border color as a background-color to the grid and added a background color to all grid-items.

.grid {
  width: 1000px;
  display: grid;
  background: #D7D7D7;
  grid-template-columns: repeat(5, 1fr);
  grid-auto-rows: 200px;
  grid-gap: 1px;
}

.grid-item {
  background: white;
}

<!DOCTYPE html>
<html lang="en">

<head>
  <meta charset="UTF-8">
  <title>Document</title>
</head>

<body>
  <div class="grid">
    <div class="grid-item"></div>
    <div class="grid-item"></div>
    <div class="grid-item"></div>
    <div class="grid-item"></div>
    <div class="grid-item"></div>
    <div class="grid-item"></div>
    <div class="grid-item"></div>
    <div class="grid-item"></div>
    <div class="grid-item"></div>
    <div class="grid-item"></div>
    <div class="grid-item"></div>
    <div class="grid-item"></div>
    <div class="grid-item"></div>
    <div class="grid-item"></div>
    <div class="grid-item"></div>
  </div>
</body>

</html>

This works for me.

score 2 · Answer 5 · answered Feb 11 '20 at 07:58

It's not possible, but simply by setting a border in cascade: this affects text and divs positions.

.grids {
  display: grid;
  grid-template-columns: repeat(4, 1fr);
  grid-template-rows: repeat(3, 1fr);
  background: #222;
  height: 326px;
  width: 455px;
  color: white
}

.grids > div {
  border: 4px red solid
}

<div class="grids">

  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>

</div>

By using outline, the positions is unchanged:

.grids {
  display: grid;
  grid-template-columns: repeat(4, 1fr);
  grid-template-rows: repeat(3, 1fr);
  background: #222;
  height: 326px;
  width: 455px;
  color: white
}

.grids > div {
  outline: 4px red solid;
}

<div class="grids">

  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>
  <div>f</div>

</div>

score 1 · Answer 6 · answered Jul 23 '21 at 11:15

There is a workaround way: use pseudo :after or :before in each column to apply background color to grid gap.

.grid-column::after {
          position: absolute;
          right: -20px; // grid-gap
          top: 0;
          height: 102px; // grid row height
          width: 20px; // grid-gap
          display: block;
          content: '';
          background-color: black !important;
}

Max · Answer 7 · 2022-10-04T19:01:24.027

If you don't know in advance how many columns will fit in your container, this is how I would do it (works for any number of columns and of any size. Also, this method do not style empty items):

.grid {
  display: grid;
  grid-template-columns: repeat(auto-fit, minmax(80px, auto));
  grid-auto-rows: minmax(80px, auto);
  border-top: 1px solid #000;
  border-left: 1px solid #000;
}

.grid-item {
  border-bottom: 1px solid #000;
  border-right: 1px solid #000;
}

 /* not required */
.grid-item {
  display: flex;
  align-items: center;
  justify-content: center;
  background:#f5f5f5;
}

<div class="grid">
  <div class="grid-item">Item 1</div>
  <div class="grid-item">Item 2</div>
  <div class="grid-item">Item 3</div>
  <div class="grid-item">Item 4</div>
  <div class="grid-item">Item 5</div>
  <div class="grid-item">Item 6</div>
  <div class="grid-item">Item 7</div>
  <div class="grid-item">Item 8</div>
  <div class="grid-item">Item 9</div>
  <div class="grid-item">Item 10</div>
  <div class="grid-item">Item 11</div>
<div>

Bob van den Berg · Answer 8 · 2020-11-23T16:01:47.437

You can also choose to leave out the grid gaps and use the border on the underlying div like so:

CSS:

.grid {
  display: inline-grid;
  border: red solid;
  width: 200px;
  height: 100%;
  grid-template-columns: 1fr 1fr 1fr;
  grid-template-rows: 1fr 1fr 1fr;
}
.grid div {
  border: red solid;
}

and the HTML:

<div className="grid">
  <div>text</div>
  <div>text</div>
  <div>text</div>
  <div>text</div>
  <div>text</div>
  <div>text</div>
  <div>text</div>
  <div>text</div>
</div>

I believe this achieves what you wanted to achieve:

score -2 · Answer 9 · answered Sep 10 '19 at 11:06

Setting background-color on grid will color your gaps. For example:

    section {
            display: grid;
            grid-gap: 15px;
            grid-template-columns: 1fr 1fr 1fr;
            grid-template-rows: 1fr 1fr 1fr;
            background-color: red;
        }
