Layout not adjust when keyboard opens

Question

Hi i have the following layout in activity.xml file

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:tools="http://schemas.android.com/tools"
android:id="@+id/activity_change_password"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:paddingBottom="0dp"
android:paddingLeft="0dp"
android:paddingRight="0dp"
android:paddingTop="0dp"
android:layout_marginTop="0dp"
tools:context="com.kdpl.motodriver.ChangePassword">
<android.support.v7.widget.Toolbar
    android:id="@+id/toolbar1"
    android:layout_width="fill_parent"
    android:layout_height="58dp"
    android:background="?attr/colorPrimary"
    android:minHeight="?attr/actionBarSize"
    android:titleTextColor="#ffffff">
    <Button
        android:layout_width="25dp"
        android:layout_height="25dp"
        android:background="@drawable/back_arrow" android:onClick="onBackPressed" />
    <TextView
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="@string/change_password_header"
        android:layout_gravity="center"
        android:id="@+id/toolbar_title"
        style="@style/TitleStyle"/>
</android.support.v7.widget.Toolbar>
<android.support.design.widget.TextInputLayout
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:layout_marginTop="30dp"
    android:layout_below="@+id/toolbar1"
    android:id="@+id/txt1">
    <EditText
        android:layout_width="match_parent"
        android:layout_height="50dp"
        android:layout_marginLeft="16dp"
        android:layout_marginRight="16dp"
        android:id="@+id/txtOldPIN"
        android:hint="@string/txt_old_pin"
        android:maxLength="4"
        android:paddingLeft="10dp"
        android:textColor="#ffffff"
        android:inputType="numberPassword"
        android:textColorHint="@color/lightGray"
        android:gravity="center_vertical"/>
</android.support.design.widget.TextInputLayout>
<android.support.design.widget.TextInputLayout
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:layout_marginTop="20dp"
    android:layout_below="@+id/txt1"
    android:id="@+id/txt2">
    <EditText
        android:layout_width="match_parent"
        android:layout_height="50dp"
        android:layout_marginLeft="16dp"
        android:layout_marginRight="16dp"
        android:paddingLeft="10dp"
        android:textColor="#ffffff"
        android:id="@+id/txtNewPin"
        android:inputType="numberPassword"
        android:maxLength="4"
        android:hint="@string/txt_new_pin"
        android:textColorHint="@color/lightGray"
        android:gravity="center_vertical"/>
</android.support.design.widget.TextInputLayout>
<android.support.design.widget.TextInputLayout
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:layout_marginTop="20dp"
    android:layout_below="@+id/txt2"
    android:id="@+id/txt3">
    <EditText
        android:layout_width="match_parent"
        android:layout_height="50dp"
        android:layout_marginLeft="16dp"
        android:layout_marginRight="16dp"
        android:paddingLeft="10dp"
        android:id="@+id/txtConfirmPin"
        android:inputType="numberPassword"
        android:maxLength="4"
        android:textColor="#ffffff"
        android:layout_below="@+id/txt2"
        android:hint="@string/txt_confirm_new_pin"
        android:textColorHint="@color/lightGray"
        android:gravity="center_vertical"/>
</android.support.design.widget.TextInputLayout>
<LinearLayout
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:orientation="vertical"
    android:layout_alignParentBottom="true">
    <Button
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:id="@+id/btnChangePIN"
        android:layout_marginRight="16dp"
        android:layout_marginLeft="16dp"
        android:layout_centerHorizontal="true"
        android:background="@drawable/my_custom_btn_1"
        android:layout_below="@id/txt3"
        style="@style/buttonStyle"
        android:text="@string/txt_change_pin"
        android:enabled="false"/>
    <Button
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:id="@+id/btnCancelPIN"
        android:layout_marginTop="20dp"
        android:layout_marginRight="16dp"
        android:layout_marginLeft="16dp"
        android:layout_centerHorizontal="true"
        android:background="@drawable/my_custom_btn_1"
        android:layout_below="@id/btnChangePIN"
        style="@style/buttonStyle"
        android:text="@string/btn_cancel_text" />
</LinearLayout>

I have added the following line in Manifest.xml

  <activity android:name=".ChangePassword"
        android:configChanges="orientation|keyboardHidden"
        android:screenOrientation="portrait"
        android:windowSoftInputMode="adjustResize"
        />

But the Buttons align parent bottom hides when keyboard open. Layout does not resize itself.

What i am missing ?

Updated View

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:tools="http://schemas.android.com/tools"
android:id="@+id/activity_change_password"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:paddingBottom="0dp"
android:paddingLeft="0dp"
android:paddingRight="0dp"
android:paddingTop="0dp"
android:layout_marginTop="0dp"
tools:context="com.kdpl.motodriver.ChangePassword">
<android.support.v7.widget.Toolbar
    android:id="@+id/toolbar1"
    android:layout_width="fill_parent"
    android:layout_height="58dp"
    android:background="?attr/colorPrimary"
    android:minHeight="?attr/actionBarSize"
    android:titleTextColor="#ffffff">
    <Button
        android:layout_width="25dp"
        android:layout_height="25dp"
        android:background="@drawable/back_arrow" android:onClick="onBackPressed" />
    <TextView
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="@string/change_password_header"
        android:layout_gravity="center"
        android:id="@+id/toolbar_title"
        style="@style/TitleStyle"/>
</android.support.v7.widget.Toolbar>
<ScrollView
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:layout_below="@+id/toolbar1">
    <LinearLayout
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:orientation="vertical">
        <android.support.design.widget.TextInputLayout
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:layout_marginTop="20dp"
            android:layout_below="@+id/toolbar1"
            android:id="@+id/txt1">
            <EditText
                android:layout_width="match_parent"
                android:layout_height="50dp"
                android:layout_marginLeft="16dp"
                android:layout_marginRight="16dp"
                android:id="@+id/txtOldPIN"
                android:hint="@string/txt_old_pin"
                android:maxLength="4"
                android:paddingLeft="10dp"
                android:textColor="#ffffff"
                android:inputType="numberPassword"
                android:textColorHint="@color/lightGray"
                android:gravity="center_vertical"/>
        </android.support.design.widget.TextInputLayout>
        <android.support.design.widget.TextInputLayout
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:layout_marginTop="20dp"
            android:layout_below="@+id/txt1"
            android:id="@+id/txt2">
            <EditText
                android:layout_width="match_parent"
                android:layout_height="50dp"
                android:layout_marginLeft="16dp"
                android:layout_marginRight="16dp"
                android:paddingLeft="10dp"
                android:textColor="#ffffff"
                android:id="@+id/txtNewPin"
                android:inputType="numberPassword"
                android:maxLength="4"
                android:hint="@string/txt_new_pin"
                android:textColorHint="@color/lightGray"
                android:gravity="center_vertical"/>
        </android.support.design.widget.TextInputLayout>
        <android.support.design.widget.TextInputLayout
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:layout_marginTop="20dp"
            android:layout_below="@+id/txt2"
            android:id="@+id/txt3">
            <EditText
                android:layout_width="match_parent"
                android:layout_height="50dp"
                android:layout_marginLeft="16dp"
                android:layout_marginRight="16dp"
                android:paddingLeft="10dp"
                android:id="@+id/txtConfirmPin"
                android:inputType="numberPassword"
                android:maxLength="4"
                android:textColor="#ffffff"
                android:layout_below="@+id/txt2"
                android:hint="@string/txt_confirm_new_pin"
                android:textColorHint="@color/lightGray"
                android:gravity="center_vertical"/>
        </android.support.design.widget.TextInputLayout>
    </LinearLayout>
</ScrollView>
<LinearLayout
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:orientation="vertical"
    android:paddingBottom="10dp"
    android:layout_alignParentBottom="true">
    <Button
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:id="@+id/btnChangePIN"
        android:layout_marginRight="16dp"
        android:layout_marginLeft="16dp"
        android:layout_centerHorizontal="true"
        android:background="@drawable/my_custom_btn_1"
        android:layout_below="@id/txt3"
        style="@style/buttonStyle"
        android:text="@string/txt_change_pin"
        android:enabled="false"/>
    <Button
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:id="@+id/btnCancelPIN"
        android:layout_marginTop="20dp"
        android:layout_marginRight="16dp"
        android:layout_marginLeft="16dp"
        android:layout_centerHorizontal="true"
        android:background="@drawable/my_custom_btn_1"
        android:layout_below="@id/btnChangePIN"
        style="@style/buttonStyle"
        android:text="@string/btn_cancel_text" />
</LinearLayout>

I have updated my view to add scrollview in between toolbar and buttons. I have also added getWindow().setSoftInputMode(WindowManager.LayoutParams.SOFT_INPUT_ADJUST_RESIZE); in my activity as suggested.. It works but not perfectly. Now Buttons overlap the views in scroll view. Attached is image

Along with layout below, also add layout above tag so that your scroll view always remain in between the two specified views — Mohammed Atif, Apr 13 '17 at 09:50

score 1 · Answer 1 · answered Apr 13 '17 at 07:14

1

Add parent layout is Scroll view

   <ScrollView xmlns:android="http://schemas.android.com/apk/res/android"
                android:layout_width="fill_parent"
                android:layout_height="fill_parent" >
   </ScrollView >

answered Apr 13 '17 at 07:14

Nikunj Paradva

15,332
5
54
65

it does not taking full screen if i put parent layout as `scroll view` – Rajeev Kumar Apr 13 '17 at 07:28

score 1 · Answer 2 · answered Apr 13 '17 at 07:16

1

An alternate answer would be to add

android:windowSoftInputMode="adjustResize"

in your root layout

answered Apr 13 '17 at 07:16

Arthur Attout

2,701
2
26
49

score 0 · Answer 3 · answered Apr 13 '17 at 07:17

0

Why not use the CoordinateLayout as the parent layout. If it can work for snacks it must work for the keyboard as well

answered Apr 13 '17 at 07:17

Flash

1,105
14
16

score 0 · Answer 4 · answered Apr 13 '17 at 07:41

0

Add this code in your Activity:

getWindow().setSoftInputMode(WindowManager.LayoutParams.SOFT_INPUT_ADJUST_RESIZE);

answered Apr 13 '17 at 07:41

rafsanahmad007

23,683
6
47
62

score -1 · Answer 5 · answered Apr 13 '17 at 07:15

Please use adjustPan instead of adjustResize as follows :

<activity android:name=".ChangePassword"
        android:configChanges="orientation|keyboardHidden"
        android:screenOrientation="portrait"
        android:windowSoftInputMode="adjustPan" />
