i have a requirement is need to provide the HTML report for the Jmeter Test. We are able to configured the Dashboard report [http://jmeter.apache.org/usermanual/generating-dashboard.html],But in that report we are not able to get the 90% response time.

So other than Dashboard report, JmeterANT any other Html Report is available to configure.

If any one know about Kibana Dashboard for HTML Report, let me know for configuration.

Kavinkumar Muthu
  • 99
  • 1
  • 5
  • 14
  • Any one can tell me about how to start the influx DB.Here is the http://www.testautomationguru.com/jmeter-real-time-results-influxdb-grafana/ document i am refer to configure.But unable to the start the server. May i know where is need to start the server and how to execute the below commands 'influxd -config /path/to/config/file' as well. – Kavinkumar Muthu Mar 02 '17 at 10:36

1 Answers1

0

Actually looking into your link I can see the following:

Percentiles used by Summary table and Percentile graphs can be adjusted to different values by using the 3 properties:

  • aggregate_rpt_pct1 : Defaults to 90

  • aggregate_rpt_pct2 : Defaults to 95

  • aggregate_rpt_pct3 : Defaults to 99

So you should be able to see at least 3 above or amend the values according to your needs.

Apart from listed I'm aware of 2 more approaches:

  1. You can configure a Grafana Dashboard like below:

    JMeter Grafana Dashboard

    and feed it data from JMeter using Backend Listener.

  2. You can use a 3rd-party analysis service like BM.Sense which can report a lot of centiles including 90%

    Blazemeter Sense Percentiles Composite Timeline

Dmitri T
  • 159,985
  • 5
  • 83
  • 133
  • Dmitry Could please tell me the configuration part for the Grafana Dashboard? And I think BM.Sense is the commercial tool, But my client looking for the open source tool any other open source tool is available for HTML Report? – Kavinkumar Muthu Mar 02 '17 at 05:43
  • BM.Sense is [free up to certain extent](https://sense.blazemeter.com/pricing/). With regards to Grafana - don't expect anyone will be doing your job, you have direction, you have documentation - go ahead. – Dmitri T Mar 02 '17 at 05:58
  • Any one can tell me about how to start the influx DB.Here is the http://www.testautomationguru.com/jmeter-real-time-results-influxdb-grafana/ document i am refer to configure.But unable to the start the server. May i know where is need to start the server and how to execute the below commands 'influxd -config /path/to/config/file' as well. – Kavinkumar Muthu Mar 02 '17 at 10:37
