Using Visual Studio 2015 Enterprise

I'm trying to change a few values inside the Script Transformation Editor but they are grayed out and I can't modify them.

Here I'm trying to change ScriptLanguage to Microsoft Visual Basic:

enter image description here

Here I would like to change the length of this HashValue column

enter image description here

I've tried restarting visual studio as well as removing the script and adding it back to no avail.

EDIT: I figured out the second one by changing the data type to DT_WSTR

Hadi
  • 36,233
  • 13
  • 65
  • 124
Jonathan Porter
  • 1,365
  • 7
  • 34
  • 62

2 Answers2

1

Script Component Language

The Script Component ScriptLanguage property should generally be editable, UNTIL you have used the 'Edit Script...' dialog (since this builds up the backing project which can't be converted automatically). Try creating a new Script Component and editing this value first, but I was not able to replicate this being disabled at the start with my copy of VS2015.

Data Type Properties

Data type properties are controlled mainly by the selected DataType. In this case, you have a four-byte signed integer (DT_I4), which doesn't have any other settings. Other data types have different properties, i.e.:

  • DT_STR (string) can set Length and CodePage (character set),
  • DT_WSTR (Unicode string) can only set Length,
  • and DT_NUMERIC can set Scale and Precision.
mgajd
  • 11
  • 2
1

First Issue

Note: Once you accessed the script editor window you cannot change the it's language.

But you can change your scripts default language from visual studio options. All you have to do is go to Tools and select Options.... Under the Business Intelligence Designers option, select Integration Services Designer and change the script language to whichever you prefer your default to be.

enter image description here

Second Issue

You cannot change the length column of type Integer:

  • DT_I1 is relative to Sql tinyInt data type (0 to 255)
  • DT_I2 is relative to Sql Smallint data type (-2^15 (-32,768) to 2^15-1 (32,767))
  • DT_I4 is relative to Sql Int data type (-2^31 (-2,147,483,648) to 2^31-1 (2,147,483,647))
  • DT_I8 is relative to Sql Big Int data type (-2^63 (-9,223,372,036,854,775,808) to 2^63-1 (9,223,372,036,854,775,807))

Only length for DT_STR and DT_WSTR can be changed

MSDN articles about SSIS and Sql data types:
