I have some signals (preprocessed trials of sEMG signal, to be precise), each one stored in one vector. My goal is to detect and remove any possible signal outlier from these set of signals.

Moreover, I don't know a priori any model that represent a precise trend for this set. I can only calculate it by myself based on the trials I've got.

Consider now an example of 6 trials (see image below):

enter image description here

I would the trial in orange to be marked as outliers.

Until now I've worked with Matlab in order to reach my goal, using the median of all trials plus or minus the mean absolute deviation: basically, I calculate the median between the signals point by point using the Matlab function median and then the mean absolute deviation using the matlab function mad. In this case a signal is considered outlier if more than, say 50%, of the signal is out of the, call it safe zone, formed by the median plus or minus on or two times the mean absolute deviation (see image below).

enter image description here

Do you know best method to resolve such task?

EDIT:

A further implementation of the same topic above is to use the Matlab function alignsignals to align the 6 trials in order to improve the precision of the above method (example in the image below):

enter image description here

dbovo89
  • 71
  • 3
  • You could be interested by the "Gaussian process". So you can determine the confidence interval for each point on X. IMPORTANT: Your variable need to be normally distributed. – obchardon Jan 19 '17 at 09:41

1 Answers1

0

I don't know the exact method but I may have some suggestions as a starting point:

1 - The outliers seem to have a significantly larger area below them. you may use the integral of the signal to order them.

2 - If you fft them. What I expect is that the outliers will have peaks at different frequencies than inliers, then you can separate them.

3 - You can take correlation coefficients between signal pairs. On average, outliers will have smaller correlation coefficients.

Alper Kucukkomurler
  • 1,706
  • 2
  • 13
  • 19
