Xcode 8 | iOS 10 simulator "Error returned in reply: Connection invalid"

Question

While I am try to run an app in the iOS 10 simulator using xcode8 I get these alerts frequently. They randomly appear two at a time and it is not apparent what is triggering them.

Below is Image for Error I got.

I tried Following things.

Clean & Rebuild an app
Restart xcode & Simulator
Clear Derived Data & Rebuild application.

score 59 · Accepted Answer · edited Oct 13 '16 at 08:06

59

Even I was getting the same error. Issue in my case was I was working on xcode 7.3 and its simulator was open, later on I closed xcode 7 and opened xcode 8 and tried running app and got the above error.

I guess its happening because of both the simulator were open, it got solved when I closed my older simulator. Seem to be some problem while xcode 8 was trying to establish connection with simulator.

edited Oct 13 '16 at 08:06

Ketan P

4,259
3
30
36

answered Oct 10 '16 at 15:14

1

It will go completely when you have only one version of xcode installed. – Oct 13 '16 at 19:52
Unfortunately some of my project library are in swift 2.2 so I kept both version of xcode.. – Ketan P Oct 14 '16 at 06:00
2

you may need to restart your machine! – Umit Kaya Sep 20 '17 at 05:58

score 28 · Answer 2 · edited Jun 07 '17 at 23:13

28

You just follow these steps to remove this error it's working fine in my side and i hope these steps work to you also just try it.

 i)Remove multiple xcode versions.
ii)Quit all Xcode and simulators.
iii)Only one version you opened.
iv)Go to Xcode  -> Preferences

v)Go to Location vi) Set proper version for command line tools (your Xcode version)

vii)click on Derived Data

viii)Then go to Derived data and delete that folder. see below image

ix) Click on Simulator reset content settings and just quit xcode and simulator and open clear and build the xcode and run it.

edited Jun 07 '17 at 23:13

Charlton Provatas

2,184
25
18

answered May 18 '17 at 10:15

Gangireddy Rami Reddy

949
16
23

For me (Xcode 9b), going through the steps other people listed - setting Command Line tools to the right version, deleting derived data - worked only after restarting my computer. – green_knight Jun 12 '17 at 05:35
For me , I'm using Xcode 9 beta , so the straightforward solution is changed the Command Line Tools to Xcode 9-beta in Xcode 9 beta Preferences . It works for me. – Johnny Jun 15 '17 at 04:05
my problem solved by following steps from 1-6 only.Help me alot. – bittu Feb 07 '18 at 10:54

Kiryl Bielašeŭski · Answer 3 · 2018-06-26T10:25:36.847

Without deleting "Derived data" folder

The same rules as in the past apply to switching between Xcode 8 and Xcode 9:

Quit Xcode, Instruments, Simulator.app, and Console

xcode-select the version you want to work with

Start the version of Xcode you want to use

If these steps don't resolve the problem for you, you can repeat the steps above > but after #2 add "sudo killall -9 com.apple.CoreSimulator.CoreSimulatorService".

from this https://forums.developer.apple.com/thread/79301

score 8 · Answer 4 · edited Jul 04 '17 at 11:40

8

The Same issue I have faced when I have two Xcode version, but the issue was when we are opening the two instances of simulator we will get the same error, the best way to solve this issue is run command

rm -rf ~/Library/Developer/Xcode/DerivedData

to remove the derived data.

edited Jul 04 '17 at 11:40

Forge

6,538
6
44
64

answered Apr 11 '17 at 06:33

Sagar Daundkar

320
3
13

score 8 · Answer 5 · answered Sep 27 '17 at 10:49

8

None of the above worked for me.

Instead of choosing the simulator and hitting "run" i solved it by opening the simulator form "Open Developer Tool" menu first. After that all worked fine.

answered Sep 27 '17 at 10:49

user1244109

2,166
2
26
24

score 6 · Answer 6 · answered Apr 30 '17 at 18:40

6

I had a similar issue, despite not launching a second instance of the simulator, due to using SimPholders and having the XCode Command Line Tools set to a different version of XCode. To resolve this, open up XCode preferences, and under the Locations tab ensure that the Command Line Tools version matches what version of XCode you're currently working in.

answered Apr 30 '17 at 18:40

Ryan

61
2
3

This was the case for me. Can't remember that this was an issue in earlier Xcode versions though. – brainray May 05 '17 at 11:47

score 2 · Answer 7 · answered Oct 25 '16 at 07:36

I had the similar issue shown in below screenshot.

Got it solved by closing Xcode 7 and its simulator.

It seems that when you are working on Xcode 8 and its simulator then Xcode 7 simulator should not remain open.

Below is screenshot of simulator state for Xcode 7 when you're working on Xcode 8.

score 2 · Answer 8 · answered Mar 04 '17 at 11:12

In my case, I was open a project a Xcode 8, and the emulator for this version, then open this project on Xcode 7.3.1, when I create an emulator it shows the alert.

My Solution: Close all version of Xcode => Clear Derived Data => Quit Xcode => Open Xcode => Choose File => Open Recent.

score 1 · Answer 9 · answered Aug 28 '17 at 18:25

I had similar issue, what I did is I closed the simulator and all the Xcode and I went to the terminal and typed to see any Xcode application running then I killed it. I had one Xcode running in the background.

Command to see if Xcode is running,

ps -e | grep -i xcode

Use kill comment to kill any runing Xcode app, I used

kill -9 <pid>

score 1 · Answer 10 · answered Apr 18 '18 at 11:41

1

Force Quit.. Xcode and simulator. This kind of issue happned because maybe you are try to run more than one different version Xcode at same time.

answered Apr 18 '18 at 11:41

Arjun Patel

1,394
14
23

score 0 · Answer 11 · answered Oct 07 '16 at 12:28

I just had this issue when attempting to debug an iOS application from Xamarin, which uses Xcode to run apps in the simulator. I was initially targeting a 9.7" iPad Pro, attempted to change the simulated device to an iPad Air 2 (still on iOS 10), but the simulator didn't respond. After quitting and relaunching the simulator it appeared to load okay, so I changed back to the previous device - not sure whether changing devices actually did anything but I haven't seen the error message in the few times I've run my app since.

score 0 · Answer 12 · answered Aug 18 '17 at 08:46

0

Solved it by closing all xcode and simulator. Don't ask me why. It was happening on the beta version for me

answered Aug 18 '17 at 08:46

user1872384

6,886
11
61
103

score 0 · Answer 13 · answered Sep 18 '17 at 11:37

0

The Same issue I have faced in my case i stopped all applications and restarted my mac and every thing is OK

answered Sep 18 '17 at 11:37

taha

769
6
5

score 0 · Answer 14 · answered Sep 24 '17 at 10:05

0

Simple And fast Remedies..

1.Quit all xCode and reopen the xCode which you need to work...

answered Sep 24 '17 at 10:05

abdul sathar

2,395
2
28
38

score 0 · Answer 15 · answered Nov 10 '17 at 12:28

0

I had this problem too, but I did below process it's working fine.

You have both Xcode 8.x.x and 9 running on your Mac, which causes the problem. Only run one Xcode at a time (Quit another Xcode, don't let another Xcode runing in background!).

answered Nov 10 '17 at 12:28

Venkatesh G

354
1
4
10

score 0 · Answer 16 · answered Apr 07 '18 at 19:57

0

This can occur when you have more than one version of Xcode installed on your computer. Make sure you QUIT (not just close) all versions of Xcode first.

answered Apr 07 '18 at 19:57

score 0 · Answer 17 · answered Aug 17 '18 at 13:13

0

Changing the device seems to have worked for me after doing the other stuff. Didn't have to restart my computer.

answered Aug 17 '18 at 13:13

user3499381

467
1
4
12
