I am using eclipse brit plugin to generate a line chart. Basically i want to create a report to present a mobile battery usage in given time range. Here is sample data where observationtime is dynamic based on user selected range:

I want to draw a line chart of per device but unable to find any configuration to draw different charts per device on same report page. Can someone help me on this ?

------------------------Update configuration and result-----------------

enter image description here

enter image description here

------------ after using list ----------- enter image description here

2 Answers2

0

I the "Select Data" tab of your chart, select the time for the Category (X) Axis, The battery usage for the Value (Y) Axis an the device name for "Optional Y Series Grouping" (on the right side of the chart).

Simulant
  • 19,190
  • 8
  • 63
  • 98
  • Thanks you for sharing this info. I already have same changes but still when i run a report it showing all the devices on same line chart. Can you please tell me where i made mistake in report configuration. –  Sep 07 '16 at 07:56
  • oh you want one chart per device, not one Line per Device inside the same chart. I am not sure if this is possible in a dynamic way. You have to add one chart Item for every device to your report and just transfer the data of one device to display in the chart. – Simulant Sep 07 '16 at 11:41
  • I have a little luck as i have created a list on a data set and then added a chart inside the list i can see now multiple charts. It is still showing same device in all charts so doing further investigating that how i can show them for each device. New picture added in question –  Sep 07 '16 at 12:13
0

I found a solution basically we need to add a table and then add grouping inside tablet on desired field and then in footer need to add a chart and it should get the values from container rather than directly from Data set.
