I was trying to enumerate usb cdc device using pic24fj128gb206. Device seems to be enumerated properly.

But when I connect my device to Linux PC, I am getting the below warning message from kernel.

cdc_acm 1-8.1.6.7:1.0: failed to set dtr/rts

And this message will repeat when I try to connect using screen.

screen /dev/ttyACM9 115200

And I am not able to communicate with my device from PC [ Ubuntu, 14.04 ]

When analysing the data using wireshark, it looks like USB communication is fine until, host issues URB_CONTROL_out and the device responds with URB status as Broken Pipe (-EPIPE ) (-32) enter image description here

Can any one help me with how to debug this issue or any methods to debug further ?

AKV
  • 425
  • 7
  • 20

0 Answers0
