I am trying to plot some data over years with two y-axes in R. However, whenever I try to include a legend, the the legend dominates my plot. When I use solutions suggested elsewhere like keyword and/or using the cex argument, suggested in another post here, it either becomes unreadable or is still too big.

Here is my example with randomly generated data:

#Create years
year.df <- seq(1974, 2014, 1)

# Create y-axis data
set.seed(75)
mean1 <- rnorm(length(year.df), 52.49, 0.87)
mean2 <- rnorm(length(year.df), 52.47, 0.96)

#Create dataframe
df <- data.frame(cbind(year.df, mean1, mean2))

I want a second y-axis, the difference of the two means over the years

df$diff <- abs(df$mean1 - df$mean2)

When I plot using the code below to create two y-axes:

par(mfrow=c(1,1), mar=c(5.1,4.1,4.1,5.1))
with(df, plot(year.df, mean1, type = "l", lwd=4, xlab="Year", ylab="Mean", ylim=c(48,58)))
with(df, lines(year.df, mean2, type = "l", col="green", lwd=4))

par(new=TRUE)
with(df, plot(year.df, diff, type="l", axes=FALSE, xlab=NA, ylab=NA, col="red", lty=5, ylim=c(0,10)))
axis(side = 4)
mtext(side = 4, line = 3, "Annual Difference")
legend("topleft",
       legend=c("Calculated", "MST", "Diff"),
       lty=c(1,1,5), col=c("black", "green", "red"))

I get: enter image description here

When I use the cex=0.5 argument in the legend(), it starts to become unreadable: enter image description here

Is there a way to format my legend in a clear, readable manner? Better than what I have?

Community
  • 1
  • 1
Phil
  • 578
  • 3
  • 7
  • 17
  • (a) if you are saving the plot, the size of the text will depend on the dimensions of the file you are saving. (b) Have you tried other `cex` values? If `cex = 0.5` is too small, perhaps `cex = 0.65` is just right? (c) Your legend is taking up quite a bit of plot space. It might be better to label the lines directly with `text()` and let the y axes go up to 55 and 7 so your data takes up more of the plot space. – Gregor Thomas Aug 24 '16 at 22:24
  • I can't reproduce your plots: the legend in my plot is in the top-left corner with short lines and readable text. Side note, though; you've used `cex`, does `pt.cex` (instead of or in addition to `cex`) make things better? (That is, keep `cex` closer to 1, shrink `pt.cex`.) – r2evans Aug 25 '16 at 05:08

2 Answers2

7

The white space in the legend tells me that you manually widened your plot window. Legends do not scale well when it comes to manual re-sizing.

The solution is opening a plot of the exact size you need before plotting. In Windows, this is done with windows(width=10, height=8). Units are in inches. As you can see below, the legend sits tightly in the corner. enter image description here

Pierre Lapointe
  • 16,017
  • 2
  • 43
  • 56
1

Apparently, I forgot to do the first step of troubleshooting: turn things off an turn it on. I woke up this morning and ran the script again. Even with cex = 0.5 and it turned out fine. I chose to use cex = 0.75. I would still appreciate any help in why that might be. Spent many hours yesterday trying to fix my legend and the same code works and receives this product (cex=0.75): enter image description here
