I have this code: (I found somewhere on stackoverflow, just using it to illustrate my idea.)

x<-runif(20)
y<-runif(20)
z<-runif(20, -5,5)

library(rgl)
plot3d(x,y,z)

fit <- lm(z ~ poly(x,2) +poly(y,2) + x:y )

xnew <- seq(min(x), max(x), len=20)
ynew <- seq(min(y), max(y), len=20)
df <- expand.grid(x = xnew,
                  y = ynew)

df$z <- predict(fit, newdata=df)

surface3d(xnew, ynew, df$z, col="red")

enter image description here

My question is, how do I make the color a gradient of greens above zero, and reds below zero? Am I being clear?

I found this post: Formatting of persp3d plot

Which helps do the gradient, but I cannot figure out how to make it dependent on the positive/negative values of z, and how to restrict it to green and red, respectively.

Thanks for any help!

EDIT:

I tried to do some things below, adding this:

colors<-rep("red", length(df$z))
colors[(df$z > 0)] <- colorRampPalette(c("yellow","green"))(sum(df$z > 0))
colors[(df$z < 0)] <- colorRampPalette(c("red","yellow"))(sum(df$z < 0))

surface3d(xnew, ynew, df$z, col=colors)

Which produced this:

enter image description here

It looks like the gradient is along the wrong axis. It should be yellow near z = 0, getting more red aas z gets more negative, and more green as z gets more positive. But it is not doing that, applying the gradient (seemingly) along the y-axis.

Thoughts?
