OpenCV: detectMultiScale() gives too many points out of the object

Question

I trained my pc with opencv_traincascade all one day long to detect 2€ coins using more than 6000 positive images similar to the following:

Now, I have just tried to run a simple OpenCV program to see the results and to check the file cascade.xml. The final result is very disappointing:

There are many points on the coin but there are also many other points on the background. Could it be a problem with my positive images used for training? Or maybe, am I using the detectMultiScale() with wrong parameters?

Here's my code:

#include "opencv2/opencv.hpp"

using namespace cv;

int main(int, char**) {

  Mat src = imread("2c.jpg", CV_LOAD_IMAGE_COLOR);

  Mat src_gray;

  std::vector<cv::Rect> money;

  CascadeClassifier euro2_cascade;

  cvtColor(src, src_gray, CV_BGR2GRAY );
  //equalizeHist(src_gray, src_gray);

  if ( !euro2_cascade.load( "/Users/lory/Desktop/cascade.xml" ) ) {
     printf("--(!)Error loading\n");
     return -1;
  }

  euro2_cascade.detectMultiScale( src_gray, money, 1.1, 0, CV_HAAR_FIND_BIGGEST_OBJECT|CV_HAAR_SCALE_IMAGE, cv::Size(10, 10),cv::Size(2000, 2000) );

  for( size_t i = 0; i < money.size(); i++ ) {
     cv::Point center( money[i].x + money[i].width*0.5, money[i].y + money[i].height*0.5 );
     ellipse( src, center, cv::Size( money[i].width*0.5, money[i].height*0.5), 0, 0, 360, Scalar( 255, 0, 255 ), 4, 8, 0 );
  }

  //namedWindow( "Display window", WINDOW_AUTOSIZE );
  imwrite("result.jpg",src);
}

I have also tried to reduce the number of neighbours but the effect is the same, just with many less points... Could it be a problem the fact that in positive images there are those 4 corners as background around the coin? I generated png images with Gimp from a shot video showing the coin, so I don't know why opencv_createsamples puts those 4 corners.

Answer 1

Those positive images are just plain wrong

The more "noise" you give your images on the parts of the training data then the more robust it will be, but yes the longer it will take to train. This is however where your negative sampels will come into action. If you have as many negative training samples as possible with as many ranges as possible then you will create more robust detectors. You need to make sure your positive images only have your coins in, all your negative images have everything but coins in them

I've seen a couple of your questions up to now & I think you want to detect three different types of euro coins. You would be best training three classifiers all on those different coins and then running all three on your images.

I think also you are missing a key piece of knowledge on how HAAR works (or LBP or whatever) effectively it creates a set of "features" from your positive images then tries to find those features in the images you run the classifier over. It creates these features by working out what is different between your positive images and your negative images. You don't want anything that isnt going to be the thing you are trying to detect in your positive images.

Edit 1 - An Example

Imagine creating a classifier for a road stop sign, which is a similar detection to coins. It's big, it's red & it's hexagonal. Creating a classifier for this is relatively easy - as long as you don't confuse the training stage with erroneous data.

Edit 2 - Scaling of images:

You have to also remember that when running the detection stage it takes your classifier and starts small and then scales up. Large, obvious features will get detected quicker - in my previous example big red blobs & hexagonal shapes. It would then start on small features i.e. text, or numbers.

Edit 3 - a much better example

This example shows you really well how training a cascade object detector works. In fact it even has the same example as with a stop sign!

Answer 2

To detect image of euro coin you can use several methods:

1) Train OpenCV cascade (HAAR or LBP). Don't forget use the great amount of false images. Also extend image of coin (add border).

2) Estimate image with abs gradients of original image. Use Hough Transform to detect circles (coin has shape of circle).
