UINavigation set back button image instead of the

Question

I am trying to change the Back button within the UINavigationController. This is what I tried so far and the output:

1

Code within the ViewDidLoad

self.navigationController?.navigationBar.backIndicatorImage = UIImage(named: "navBarBackButton")
    self.navigationController?.navigationBar.backIndicatorTransitionMaskImage = UIImage(named: "navBarBackButton")
    self.navigationItem.backBarButtonItem?.image = UIImage(named: "navBarBackButton")

Output:

I tried to add the below but id didn't help:

self.navigationItem.backBarButtonItem = UIBarButtonItem(title:"", style:.Plain, target:nil, action:nil)

2

Code within the AppDelegate

let backImg: UIImage = UIImage(named: "navBarBackButton")!
    UIBarButtonItem.appearance().setBackButtonBackgroundImage(backImg, forState: .Normal, barMetrics: .Default)

Output:

3

I tried to add the back button in Storyboard but nothing changed

4 - Thanks to sanandiya vipul. Still need it to be instead of the 'Back'. This only deletes the 'Back but keeps the image lower right side instead of the entire '

UIBarButtonItem.appearance().setBackButtonTitlePositionAdjustment(UIOffsetMake(0, -80.0), forBarMetrics: .Default)

This is the output:

This is the result I am hoping to achieve

May be this link has the answer http://stackoverflow.com/questions/12886274/storyboard-uinavigation-controller-back-button-text?rq=1 The second answer having 10 votes — LearneriOS, Dec 29 '15 at 12:50
I tried that solution but didn't work. Please see my third output — Tal Zion, Dec 29 '15 at 12:53
http://stackoverflow.com/questions/27499998/how-to-set-image-for-bar-button-with-swift show this link and tell done or not — Birendra, Dec 29 '15 at 12:54
Thanks @Birendra but my question is how to override the back button, not create a new bar button item. Thanks — Tal Zion, Dec 29 '15 at 12:56

Sanandiya Vipul · Accepted Answer · 2015-12-29T13:11:17.947

5

Below Code add your ViewDidLoad method. its work for you fine.

for Swift

UIBarButtonItem.appearance().setBackButtonTitlePositionAdjustment(UIOffsetMake(0, -80.0), forBarMetrics: .Default)

for Objective-c

[[UIBarButtonItem appearance] setBackButtonTitlePositionAdjustment:UIOffsetMake(0,- 80.f) forBarMetrics:UIBarMetricsDefault];

edited Dec 29 '15 at 13:11

answered Dec 29 '15 at 13:04

Sanandiya Vipul

764
4
16

Thanks, do you have it in Swift? Tried to convert but UIOffsetMake is not an option – Tal Zion Dec 29 '15 at 13:14
http://stackoverflow.com/questions/16501258/how-do-i-remove-text-from-back-button-on-navbar-within-xcode see it – Sanandiya Vipul Dec 29 '15 at 13:16
Thanks! for some reason first time when I go to the VC, it shows ' – Tal Zion Dec 29 '15 at 13:26
I added to a top VC and it works fine! I still see the image very small. I will post the 4th try to show what I get. Hope you can help – Tal Zion Dec 29 '15 at 13:29
@TalZion Any solution that worked for you? I am having a similar issue. Let me know, if you got your expected result. – viral Nov 16 '17 at 07:47

score 1 · Answer 2 · edited May 23 '18 at 09:29

1

Swift 4 version

Set Back title text color to clear

let barButtonItemAppearance = UIBarButtonItem.appearance()
barButtonItemAppearance.setTitleTextAttributes([NSAttributedStringKey.foregroundColor: UIColor.clear], for: .normal)
barButtonItemAppearance.setTitleTextAttributes([NSAttributedStringKey.foregroundColor: UIColor.clear], for: .highlighted)

edited May 23 '18 at 09:29

Krunal

77,632
48
245
261

answered May 23 '18 at 09:28

Tanya Berezovsky

91
5

score -1 · Answer 3 · answered Apr 19 '16 at 01:56

-1

Just added UIBarButtonItem and linked it to action.

    @IBAction func backTapped(sender: AnyObject) {
    self.navigationController?.popViewControllerAnimated(true)
}

answered Apr 19 '16 at 01:56

Atef

2,872
1
36
32

korgx9 · Answer 4 · 2020-10-26T10:11:57.937

-1

Swift 5 version

UIBarButtonItem.appearance().setBackButtonTitlePositionAdjustment(UIOffset(horizontal: 0, vertical: -80.0), for: .default)

edited Oct 26 '20 at 10:11

answered Mar 02 '17 at 11:56

korgx9

1,234
22
30
