SnackBar and fitsSystemWindow

Question

I have an app that uses fitsSystemWindows to be able to draw an background behind Navigation- and Status-Bar - unfortunately the SnackBar seems to ignore the fitsSystemWindows=true from the container. I boiled the problem down to this minimal app:

problem

the style:

<resources>

    <style name="AppTheme" parent="Theme.AppCompat.Light">

        <item name="android:windowBackground">@color/accent_material_dark</item>
        <item name="android:fitsSystemWindows">false</item>

        <item name="android:windowTranslucentStatus">true</item>
        <item name="android:windowTranslucentNavigation">true</item>
    </style>

</resources>

the layout:

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
                xmlns:tools="http://schemas.android.com/tools"
                android:layout_width="match_parent"
                android:layout_height="match_parent"

                android:fitsSystemWindows="true"
                tools:context=".MainActivity">

    <Button

            android:id="@+id/button"
            android:text="@string/hello_world"
            android:layout_width="match_parent"
            android:layout_height="match_parent"/>

</RelativeLayout>

the activity:

public class MainActivity extends AppCompatActivity {

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);
        findViewById(R.id.button).setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(final View v) {
                Snackbar.make(v,"This Snackbar should fitSystemWindows",Snackbar.LENGTH_INDEFINITE).show();
            }
        });
    }

}

Anyone knows some workaround?

I published the minimal app to show the problem here: https://github.com/ligi/SnackBarFitsSystemWindowProblem

score 17 · Accepted Answer · answered Jul 18 '15 at 14:42

17

Snackbar will always look for a CoordinatorLayout to anchor itself in: when you don't have one, it uses the full content view (which in your case, includes the area under the status bar) - adding a CoordinatorLayout that has fitsSystemWindows=true should do it.

answered Jul 18 '15 at 14:42

ianhanniballake

191,609
30
470
443

1

Would this cascade down from Fragment? I have a fragment where I spawn this Snackbar though – Neon Warge Jun 22 '17 at 05:56
@NeonWarge - You mean cascade up from a Fragment whose view is contained within a `CoordinatorLayout`? Yup. – ianhanniballake Jun 23 '17 at 05:54
yes, in fact, there is something messing it up. It doesn't respect that attribute for me :/ Its a ViewPager on an activity with 4 fragments. – Neon Warge Jun 23 '17 at 05:59

score -1 · Answer 2 · answered Oct 13 '16 at 06:26

-1

You can also use the following line in place of any CoordinatorLayout in Snackbar declaration with findViewById(android.support.design.R.id.design_navigation_view) .

answered Oct 13 '16 at 06:26

Akshay Patel

35
6

score -3 · Answer 3 · answered Aug 24 '16 at 17:07

-3

Well The correct answer is add android:paddingbottom="50dp" to your CoordinatorLayout although i'm not sure if all navigation bar size's is 50 dp

answered Aug 24 '16 at 17:07

Sepehr Azizi

117
1
1
8

navigation bar size is not always same, so if you want to go this way, you need to check [windowInsets](https://developer.android.com/reference/android/view/WindowInsets.html) – yshrsmz Apr 11 '18 at 07:21
