HTML 5: Canvas copying Pixel Data within a Polygon

Question

Good afternoon,

I am new to Canvas in HTML 5 and in using it with Javascript. But I can see how powerful this really is and I needed help. I have done a search and could not find a clear answer to this. Perhaps someone here can help.

I have created a context on the Canvas with a background image in place. Now, I want crop or copy a part of that image which is contained in Polygon Data and place it else where on the screen. I know how to create the background image. I know how to create a polygon over that image and I know how to copy image data to another part of the screen.

So how would I copy all the image data/pixels within that polygon? Is there a simple way to this? Thanks in advance for your help. It is much appreciated.

EDIT: This is an example of what I am trying to do: http://jsfiddle.net/MFELx/

//I have no code, but it wouldn't let me post link. Hope this is allowed.

Only I am trying to do it without an external library or without JQUERY. I hope that makes a little more sense. Thanks for your help again!

EDIT AGAIN: SOLUTION:

OK So Mark E's Solution worked. I edited it this way for those who are interested without JQUERY:

HTML: Copy the polygon
Original background

CSS:

body{ background-color: ivory; }
#canvas{border:1px solid red;}

JS:

var canvas=document.getElementById("canvas");
var ctx=canvas.getContext("2d");
var cw=canvas.width;
var ch=canvas.height;

var polygonData=[];
polygonData.push({x:125,y:75});
polygonData.push({x:100,y:118});
polygonData.push({x:50,y:118});
polygonData.push({x:25,y:75});
polygonData.push({x:49,y:31});
polygonData.push({x:100,y:31});
polygonData.push({x:125,y:75});


var img=new Image();
img.onload=start;
img.src='https://dl.dropboxusercontent.com/u/139992952/multple/stars1.png';
function start(){

  // draw the original background
  ctx.drawImage(img,0,0);

  // copy the existing polygon to its new position


}


function copyPolygon(newStartingX,newStartingY){

  // calculate the copy's offset versus the original
  var dx=newStartingX-polygonData[0].x;
  var dy=newStartingY-polygonData[0].y;

  // define the path of the new polygon
  ctx.beginPath();
  ctx.moveTo(polygonData[0].x+dx,polygonData[0].y+dy);
  for(var i=1;i<polygonData.length;i++){
    ctx.lineTo(polygonData[i].x+dx,polygonData[i].y+dy);
  }
  ctx.closePath();

  // clip to the path of the new polygon
  ctx.save();
  ctx.clip();

  // use the clipping version of drawImage to
  // redraw the existing canvas over the new polygon position
  // Note: with clipping, new pixels will only be drawn in the new polygon
  ctx.drawImage(canvas, 0,0,cw,ch, dx,dy,cw,ch);

  // clean up -- un-clip by resetting the context state
  ctx.restore();

}
function myFunction() {
    copyPolygon(250,75);
}

Answer 1

Since you have the polygon data points that you want to copy, there's a simpler method to copy your polygon than using a second off-screen canvas.

Instead, you can:

• Use the polygon points to define the path of the new polygon copy.

• Use context.clip() to restrict all new drawings to be inside that polygon copy.

• Use the canvas as its own image source and draw it with an offset equal to how far the new polygon is from the previous polygon.

Here's example annotated code and a Demo:

var canvas=document.getElementById("canvas");
var ctx=canvas.getContext("2d");
var cw=canvas.width;
var ch=canvas.height;

var polygonData=[];
polygonData.push({x:125,y:75});
polygonData.push({x:100,y:118});
polygonData.push({x:50,y:118});
polygonData.push({x:25,y:75});
polygonData.push({x:49,y:31});
polygonData.push({x:100,y:31});
polygonData.push({x:125,y:75});


var img=new Image();
img.onload=start;
img.src='https://dl.dropboxusercontent.com/u/139992952/multple/stars1.png';
function start(){

  // draw the original background
  ctx.drawImage(img,0,0);

  // copy the existing polygon to its new position
  $('#copy').click(function(){
    copyPolygon(250,75);
    $('#status').text('With the polygon copied');
  });

}


function copyPolygon(newStartingX,newStartingY){

  // calculate the copy's offset versus the original
  var dx=newStartingX-polygonData[0].x;
  var dy=newStartingY-polygonData[0].y;

  // define the path of the new polygon
  ctx.beginPath();
  ctx.moveTo(polygonData[0].x+dx,polygonData[0].y+dy);
  for(var i=1;i<polygonData.length;i++){
    ctx.lineTo(polygonData[i].x+dx,polygonData[i].y+dy);
  }
  ctx.closePath();

  // clip to the path of the new polygon
  ctx.save();
  ctx.clip();

  // use the clipping version of drawImage to
  // redraw the existing canvas over the new polygon position
  // Note: with clipping, new pixels will only be drawn in the new polygon
  ctx.drawImage(canvas, 0,0,cw,ch, dx,dy,cw,ch);

  // clean up -- un-clip by resetting the context state
  ctx.restore();

}

body{ background-color: ivory; }
#canvas{border:1px solid red;}

<script src="https://ajax.googleapis.com/ajax/libs/jquery/1.9.1/jquery.min.js"></script>
<button id=copy>Copy the polygon</button>
<br>
<h4 id='status'>Original background</h4>
<canvas id="canvas" width=400 height=250></canvas>
