Latex List of Figures

Question

So i'm trying to hide the label in my cover image.

>\begin{figure}
>\center
>\includegraphics[scale=0.5]{universidade}
>\caption* {Mycaption}
>\end {figure}

This way it's not labeling the figure but its not showing on the list of figures Help please ;D

Tim B · Answer 1 · 2014-12-06T00:10:09.163

0

You can give the caption package the option labelformat=empty to suppress the Figure 1 etc. labelling:

\usepackage[labelformat=empty]{caption}

You can use square brackets to specify the description for the figure list, and curly brackets for the actual figure caption. So I think you should be able to do the following to supress the caption but still have an entry in the figure list:

\begin{figure}
\center
\includegraphics[scale=0.5]{universidade}
\caption[Mycaption]{}
\end {figure}

edited Dec 06 '14 at 00:10

answered Dec 05 '14 at 23:57

Tim B

3,033
1
23
28

But using that package it will apply to all document, and i just want it to apply to this particular case. – Sir Hadez Dec 06 '14 at 00:16
Ah, sorry, that wasn't clear from the question. I'm not sure how to achieve that. If you don't use the empty labelformat option you will have a "Figure x" in the caption. – Tim B Dec 06 '14 at 00:25

score 0 · Answer 2 · answered Dec 06 '14 at 06:19

There are a couple of options, depending on what yo're after exactly:

enter image description here

\documentclass{article}

\usepackage{graphicx}
\setcounter{topnumber}{3}% Just for this example
\begin{document}

\listoffigures

\begin{figure}
  \addcontentsline{lof}{figure}{Example image A}%
  \centering
  \includegraphics[height=4\baselineskip]{example-image-a}

  Example image A
\end{figure}

\begin{figure}
  \addcontentsline{lof}{figure}{\protect\numberline{}Example image B}%
  \centering
  \includegraphics[height=4\baselineskip]{example-image-b}

  Example image B
\end{figure}

\begin{figure}
  \centering
  \includegraphics[height=4\baselineskip]{example-image-c}
  \caption{Example image C}
\end{figure}

\end{document}

The figure caption is added using \addcontentsline{lof}{figure}{<caption>}, where <caption> can either contain a blank \numberline{}, or just the regular caption. The above example shows the usage of either.

It would also be possible to have no label shows in the image, but have a numbered entry in the LoF using caption. But it would seem strange to have a numbered entry in the LoF and an unnumbered figure.
