cvc-complex-type.3.2.2: Attribute 'key' is not allowed to appear in element 'props'

Question

I am new to use hibernate in spring. I am trying to set the properties of hibernate through properties prop tag, but it is giving some error, can you please tell what it means and how it can be resolved thanks.

SPRING.XML

<?xml version="1.0" encoding="UTF-8"?>
<beans
    xmlns="http://www.springframework.org/schema/beans"
    xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xmlns:aop="http://www.springframework.org/schema/aop"
    xmlns:context="http://www.springframework.org/schema/context"
    xsi:schemaLocation="
    http://www.springframework.org/schema/beans
    http://www.springframework.org/schema/beans/spring-beans-4.1.xsd
    http://www.springframework.org/schema/context
    http://www.springframework.org/schema/context/spring-context.xsd">

    <bean name="hibernateTest" class="com.secure.archeia.maintest.HibernateUtil" />

    <bean name="dataSource" class="org.springframework.jdbc.datasource.DriverManagerDataSource">
        <property name="driverClassName" value="com.mysql.jdbc.Driver" />
        <property name="url" value="jdbc:mysql://172.16.16.10:3306/SAMS?allowMultiQuery=true" />
        <property name="username" value="AccessControl" />
        <property name="password" value="_AccsCtrl1" />
    </bean>

    <bean name="sessionFactory" class="org.springframework.orm.hibernate4.LocalSessionFactoryBean">
        <property name="packagesToScan" value="com.secure.archeia.model" />
        <property name="dataSource" ref="dataSource" />

        <property name="hibernateProperties">
            <props key="dialect">org.hibernate.dialect.MySQLDialect</props>
        </property>
    </bean>
</beans>

ERROR

Oct 02, 2014 11:44:58 AM org.springframework.context.support.ClassPathXmlApplicationContext prepareRefresh
INFO: Refreshing org.springframework.context.support.ClassPathXmlApplicationContext@31c9b6eb: startup date [Thu Oct 02 11:44:58 PKT 2014]; root of context hierarchy
Oct 02, 2014 11:44:58 AM org.springframework.beans.factory.xml.XmlBeanDefinitionReader loadBeanDefinitions
INFO: Loading XML bean definitions from class path resource [spring.xml]
Exception in thread "main" org.springframework.beans.factory.xml.XmlBeanDefinitionStoreException: Line 28 in XML document from class path resource [spring.xml] is invalid; nested exception is org.xml.sax.SAXParseException; lineNumber: 28; columnNumber: 28; cvc-complex-type.3.2.2: Attribute 'key' is not allowed to appear in element 'props'.
    at org.springframework.beans.factory.xml.XmlBeanDefinitionReader.doLoadBeanDefinitions(XmlBeanDefinitionReader.java:398)
    at org.springframework.beans.factory.xml.XmlBeanDefinitionReader.loadBeanDefinitions(XmlBeanDefinitionReader.java:335)
    at org.springframework.beans.factory.xml.XmlBeanDefinitionReader.loadBeanDefinitions(XmlBeanDefinitionReader.java:303)
    at org.springframework.beans.factory.support.AbstractBeanDefinitionReader.loadBeanDefinitions(AbstractBeanDefinitionReader.java:180)
    at org.springframework.beans.factory.support.AbstractBeanDefinitionReader.loadBeanDefinitions(AbstractBeanDefinitionReader.java:216)
    at org.springframework.beans.factory.support.AbstractBeanDefinitionReader.loadBeanDefinitions(AbstractBeanDefinitionReader.java:187)
    at org.springframework.beans.factory.support.AbstractBeanDefinitionReader.loadBeanDefinitions(AbstractBeanDefinitionReader.java:251)
    at org.springframework.context.support.AbstractXmlApplicationContext.loadBeanDefinitions(AbstractXmlApplicationContext.java:127)
    at org.springframework.context.support.AbstractXmlApplicationContext.loadBeanDefinitions(AbstractXmlApplicationContext.java:93)
    at org.springframework.context.support.AbstractRefreshableApplicationContext.refreshBeanFactory(AbstractRefreshableApplicationContext.java:129)
    at org.springframework.context.support.AbstractApplicationContext.obtainFreshBeanFactory(AbstractApplicationContext.java:537)
    at org.springframework.context.support.AbstractApplicationContext.refresh(AbstractApplicationContext.java:452)
    at org.springframework.context.support.ClassPathXmlApplicationContext.<init>(ClassPathXmlApplicationContext.java:139)
    at org.springframework.context.support.ClassPathXmlApplicationContext.<init>(ClassPathXmlApplicationContext.java:83)
    at com.secure.archeia.maintest.MainTest.main(MainTest.java:10)
Caused by: org.xml.sax.SAXParseException; lineNumber: 28; columnNumber: 28; cvc-complex-type.3.2.2: Attribute 'key' is not allowed to appear in element 'props'.
    at com.sun.org.apache.xerces.internal.util.ErrorHandlerWrapper.createSAXParseException(ErrorHandlerWrapper.java:198)
    at com.sun.org.apache.xerces.internal.util.ErrorHandlerWrapper.error(ErrorHandlerWrapper.java:134)
    at com.sun.org.apache.xerces.internal.impl.XMLErrorReporter.reportError(XMLErrorReporter.java:437)
    at com.sun.org.apache.xerces.internal.impl.XMLErrorReporter.reportError(XMLErrorReporter.java:368)
    at com.sun.org.apache.xerces.internal.impl.XMLErrorReporter.reportError(XMLErrorReporter.java:325)
    at com.sun.org.apache.xerces.internal.impl.xs.XMLSchemaValidator$XSIErrorReporter.reportError(XMLSchemaValidator.java:458)
    at com.sun.org.apache.xerces.internal.impl.xs.XMLSchemaValidator.reportSchemaError(XMLSchemaValidator.java:3237)
    at com.sun.org.apache.xerces.internal.impl.xs.XMLSchemaValidator.processAttributes(XMLSchemaValidator.java:2714)
    at com.sun.org.apache.xerces.internal.impl.xs.XMLSchemaValidator.handleStartElement(XMLSchemaValidator.java:2056)
    at com.sun.org.apache.xerces.internal.impl.xs.XMLSchemaValidator.startElement(XMLSchemaValidator.java:746)
    at com.sun.org.apache.xerces.internal.impl.XMLNSDocumentScannerImpl.scanStartElement(XMLNSDocumentScannerImpl.java:378)
    at com.sun.org.apache.xerces.internal.impl.XMLDocumentFragmentScannerImpl$FragmentContentDriver.next(XMLDocumentFragmentScannerImpl.java:2778)
    at com.sun.org.apache.xerces.internal.impl.XMLDocumentScannerImpl.next(XMLDocumentScannerImpl.java:606)
    at com.sun.org.apache.xerces.internal.impl.XMLNSDocumentScannerImpl.next(XMLNSDocumentScannerImpl.java:117)
    at com.sun.org.apache.xerces.internal.impl.XMLDocumentFragmentScannerImpl.scanDocument(XMLDocumentFragmentScannerImpl.java:510)
    at com.sun.org.apache.xerces.internal.parsers.XML11Configuration.parse(XML11Configuration.java:848)
    at com.sun.org.apache.xerces.internal.parsers.XML11Configuration.parse(XML11Configuration.java:777)
    at com.sun.org.apache.xerces.internal.parsers.XMLParser.parse(XMLParser.java:141)
    at com.sun.org.apache.xerces.internal.parsers.DOMParser.parse(DOMParser.java:243)
    at com.sun.org.apache.xerces.internal.jaxp.DocumentBuilderImpl.parse(DocumentBuilderImpl.java:347)
    at org.springframework.beans.factory.xml.DefaultDocumentLoader.loadDocument(DefaultDocumentLoader.java:76)
    at org.springframework.beans.factory.xml.XmlBeanDefinitionReader.doLoadDocument(XmlBeanDefinitionReader.java:428)
    at org.springframework.beans.factory.xml.XmlBeanDefinitionReader.doLoadBeanDefinitions(XmlBeanDefinitionReader.java:390)
    ... 14 more

EDIT: Updated StackTrace

Oct 02, 2014 12:11:00 PM org.springframework.context.support.ClassPathXmlApplicationContext prepareRefresh
INFO: Refreshing org.springframework.context.support.ClassPathXmlApplicationContext@31c9b6eb: startup date [Thu Oct 02 12:11:00 PKT 2014]; root of context hierarchy
Oct 02, 2014 12:11:00 PM org.springframework.beans.factory.xml.XmlBeanDefinitionReader loadBeanDefinitions
INFO: Loading XML bean definitions from class path resource [spring.xml]
Oct 02, 2014 12:11:00 PM org.springframework.jdbc.datasource.DriverManagerDataSource setDriverClassName
INFO: Loaded JDBC driver: com.mysql.jdbc.Driver
Oct 02, 2014 12:11:00 PM org.springframework.context.support.ClassPathXmlApplicationContext refresh
WARNING: Exception encountered during context initialization - cancelling refresh attempt
org.springframework.beans.factory.BeanCreationException: Error creating bean with name 'sessionFactory' defined in class path resource [spring.xml]: Initialization of bean failed; nested exception is java.lang.NoClassDefFoundError: org/hibernate/SessionFactory
    at org.springframework.beans.factory.support.AbstractAutowireCapableBeanFactory.doCreateBean(AbstractAutowireCapableBeanFactory.java:548)
    at org.springframework.beans.factory.support.AbstractAutowireCapableBeanFactory.createBean(AbstractAutowireCapableBeanFactory.java:476)
    at org.springframework.beans.factory.support.AbstractBeanFactory$1.getObject(AbstractBeanFactory.java:302)
    at org.springframework.beans.factory.support.DefaultSingletonBeanRegistry.getSingleton(DefaultSingletonBeanRegistry.java:229)
    at org.springframework.beans.factory.support.AbstractBeanFactory.doGetBean(AbstractBeanFactory.java:298)
    at org.springframework.beans.factory.support.AbstractBeanFactory.getBean(AbstractBeanFactory.java:193)
    at org.springframework.beans.factory.support.DefaultListableBeanFactory.preInstantiateSingletons(DefaultListableBeanFactory.java:706)
    at org.springframework.context.support.AbstractApplicationContext.finishBeanFactoryInitialization(AbstractApplicationContext.java:757)
    at org.springframework.context.support.AbstractApplicationContext.refresh(AbstractApplicationContext.java:480)
    at org.springframework.context.support.ClassPathXmlApplicationContext.<init>(ClassPathXmlApplicationContext.java:139)
    at org.springframework.context.support.ClassPathXmlApplicationContext.<init>(ClassPathXmlApplicationContext.java:83)
    at com.secure.archeia.maintest.MainTest.main(MainTest.java:10)
Caused by: java.lang.NoClassDefFoundError: org/hibernate/SessionFactory
    at java.lang.Class.getDeclaredMethods0(Native Method)
    at java.lang.Class.privateGetDeclaredMethods(Class.java:2531)
    at java.lang.Class.privateGetPublicMethods(Class.java:2651)
    at java.lang.Class.getMethods(Class.java:1467)
    at org.springframework.beans.ExtendedBeanInfoFactory.supports(ExtendedBeanInfoFactory.java:54)
    at org.springframework.beans.ExtendedBeanInfoFactory.getBeanInfo(ExtendedBeanInfoFactory.java:46)
    at org.springframework.beans.CachedIntrospectionResults.<init>(CachedIntrospectionResults.java:270)
    at org.springframework.beans.CachedIntrospectionResults.forClass(CachedIntrospectionResults.java:189)
    at org.springframework.beans.BeanWrapperImpl.getCachedIntrospectionResults(BeanWrapperImpl.java:307)
    at org.springframework.beans.BeanWrapperImpl.getPropertyDescriptorInternal(BeanWrapperImpl.java:339)
    at org.springframework.beans.BeanWrapperImpl.isWritableProperty(BeanWrapperImpl.java:419)
    at org.springframework.beans.factory.support.AbstractAutowireCapableBeanFactory.applyPropertyValues(AbstractAutowireCapableBeanFactory.java:1473)
    at org.springframework.beans.factory.support.AbstractAutowireCapableBeanFactory.populateBean(AbstractAutowireCapableBeanFactory.java:1216)
    at org.springframework.beans.factory.support.AbstractAutowireCapableBeanFactory.doCreateBean(AbstractAutowireCapableBeanFactory.java:538)
    ... 11 more

Exception in thread "main" org.springframework.beans.factory.BeanCreationException: Error creating bean with name 'sessionFactory' defined in class path resource [spring.xml]: Initialization of bean failed; nested exception is java.lang.NoClassDefFoundError: org/hibernate/SessionFactory
    at org.springframework.beans.factory.support.AbstractAutowireCapableBeanFactory.doCreateBean(AbstractAutowireCapableBeanFactory.java:548)
    at org.springframework.beans.factory.support.AbstractAutowireCapableBeanFactory.createBean(AbstractAutowireCapableBeanFactory.java:476)
    at org.springframework.beans.factory.support.AbstractBeanFactory$1.getObject(AbstractBeanFactory.java:302)
    at org.springframework.beans.factory.support.DefaultSingletonBeanRegistry.getSingleton(DefaultSingletonBeanRegistry.java:229)
    at org.springframework.beans.factory.support.AbstractBeanFactory.doGetBean(AbstractBeanFactory.java:298)
    at org.springframework.beans.factory.support.AbstractBeanFactory.getBean(AbstractBeanFactory.java:193)
    at org.springframework.beans.factory.support.DefaultListableBeanFactory.preInstantiateSingletons(DefaultListableBeanFactory.java:706)
    at org.springframework.context.support.AbstractApplicationContext.finishBeanFactoryInitialization(AbstractApplicationContext.java:757)
    at org.springframework.context.support.AbstractApplicationContext.refresh(AbstractApplicationContext.java:480)
    at org.springframework.context.support.ClassPathXmlApplicationContext.<init>(ClassPathXmlApplicationContext.java:139)
    at org.springframework.context.support.ClassPathXmlApplicationContext.<init>(ClassPathXmlApplicationContext.java:83)
    at com.secure.archeia.maintest.MainTest.main(MainTest.java:10)
Caused by: java.lang.NoClassDefFoundError: org/hibernate/SessionFactory
    at java.lang.Class.getDeclaredMethods0(Native Method)
    at java.lang.Class.privateGetDeclaredMethods(Class.java:2531)
    at java.lang.Class.privateGetPublicMethods(Class.java:2651)
    at java.lang.Class.getMethods(Class.java:1467)
    at org.springframework.beans.ExtendedBeanInfoFactory.supports(ExtendedBeanInfoFactory.java:54)
    at org.springframework.beans.ExtendedBeanInfoFactory.getBeanInfo(ExtendedBeanInfoFactory.java:46)
    at org.springframework.beans.CachedIntrospectionResults.<init>(CachedIntrospectionResults.java:270)
    at org.springframework.beans.CachedIntrospectionResults.forClass(CachedIntrospectionResults.java:189)
    at org.springframework.beans.BeanWrapperImpl.getCachedIntrospectionResults(BeanWrapperImpl.java:307)
    at org.springframework.beans.BeanWrapperImpl.getPropertyDescriptorInternal(BeanWrapperImpl.java:339)
    at org.springframework.beans.BeanWrapperImpl.isWritableProperty(BeanWrapperImpl.java:419)
    at org.springframework.beans.factory.support.AbstractAutowireCapableBeanFactory.applyPropertyValues(AbstractAutowireCapableBeanFactory.java:1473)
    at org.springframework.beans.factory.support.AbstractAutowireCapableBeanFactory.populateBean(AbstractAutowireCapableBeanFactory.java:1216)
    at org.springframework.beans.factory.support.AbstractAutowireCapableBeanFactory.doCreateBean(AbstractAutowireCapableBeanFactory.java:538)
    ... 11 more

Runtime Libraries and Class Path

Expanded Version

as the erorrs indicates `props` doesn't have a key/value attribute. The `prop` element does have. — M. Deinum, Oct 02 '14 at 06:54
Hey Deinum thanks alot, but when I corrected this stupid error, i got something else now. Multiple annotations found at this line: - cvc-complex-type.2.4.a: Invalid content was found starting with element 'prop'. — Haris Mehmood, Oct 02 '14 at 06:58

score 0 · Accepted Answer · answered Oct 02 '14 at 06:57

0

The declaration of your properties is wrong. Try:

   <property name="hibernateProperties">
        <value>
            hibernate.dialect=org.hibernate.dialect.MySQLDialect
        </value>
    </property>

answered Oct 02 '14 at 06:57

Jens

67,715
15
98
113

how am I going to tell that this is for Hibernate Dialect ? – Haris Mehmood Oct 02 '14 at 06:57
1

@HarisMehmood the key (before equals sign) is `hibernate.dialect` that is enough. – Jens Oct 02 '14 at 06:59
Jens, thank you. Now I am getting an error about creating bean. I will mark your answer correct after 6mins. In the mean time can you tell me why I am getting this : Error creating bean with name 'sessionFactory' defined in class path resource [spring.xml]: Initialization of bean failed; nested exception is java.lang.NoClassDefFoundError: org/hibernate/SessionFactory – Haris Mehmood Oct 02 '14 at 07:03
@HarisMehmood Looks like you miss the hibernate jar in your classpath. – Jens Oct 02 '14 at 07:10
it is in my Java Run Time Libraries : Hibernate-core-4.3.5.Final.jar I have checked SessionFactory.class its also located in it. I am having the same issue with Spring AOP Around class and I couldnt find a solution to that. – Haris Mehmood Oct 02 '14 at 07:13
@HarisMehmood Do you run it from eclipse or in a webserver like tomcat? – Jens Oct 02 '14 at 07:14
its just a desktop app , i am running it from eclispe Luna – Haris Mehmood Oct 02 '14 at 07:17
@HarisMehmood Can you add the hole Stacktrace to the question as an update or make a new question? – Jens Oct 02 '14 at 07:21
I have also added the image for libraries and updated with stacktrace – Haris Mehmood Oct 02 '14 at 07:26
@HarisMehmood Can you show an expanded version of your buildpath? – Jens Oct 02 '14 at 07:29
@HarisMehmood And you run it with "Run"->"Run As"->"Java Application"? – Jens Oct 02 '14 at 07:35
@HarisMehmood Can you try to add the file directly not as a jar in a library? – Jens Oct 02 '14 at 07:41
