iOS7 UIWebView has wrong scrollview inset on inital load

Question

Whenever I display a PDF file in my webView it looks like it's initial scrollview inset is not set correctly but as soon as I start scrolling or zooming, it jumps to it's correct place :/

The PDF is loaded but it's partially under the navigation bar

As soon as I start scrolling or zooming in, it snaps to it's intended default position

If I load PNGs into the same webview they have the perfect inset and are displayed right under the navigation bar (not a line of black pixels in between).

Does anyone know how I can solve this?

Some of the webView settings:

webView.clipsToBounds = NO;
webView.scalesPageToFit = YES;

Have you found a solution for this? – Klemens Zleptnig Sep 18 '14 at 18:10 — Klemens Zleptnig, Sep 18 '14 at 18:10
Opted to non-translucent navigationBar :/ – budiDino Sep 19 '14 at 14:35 — budiDino, Sep 19 '14 at 14:35
Having same problem, please help on this thread. – Divya Bhaloidiya Oct 28 '14 at 09:06 — Divya Bhaloidiya, Oct 28 '14 at 09:06

score 7 · Accepted Answer · answered Sep 29 '14 at 17:42

I implemented this workaround:

- (void)webViewDidFinishLoad:(UIWebView *)aWebView {

    dispatch_after(dispatch_time(DISPATCH_TIME_NOW, (int64_t)(0.15 * NSEC_PER_SEC)), dispatch_get_main_queue(), ^{
        self.webView.scrollView.contentOffset = CGPointMake(0, -(self.webView.scrollView.contentInset.top));
    });

}

It "jumps" a bit when the WebView is loaded, but at least the contentOffset is set correctly. You might also need to fine tune the delay (0.15 ms in this example).

score 2 · Answer 2 · answered May 04 '15 at 01:18

I ran into this same problem; very annoying. I was able to resolve it by first making my WebViewController a UIScrollViewDelegate.

@interface WebViewController () <UIWebViewDelegate, UIScrollViewDelegate>

When I added some debug in the scrollViewDidScroll delegate to inspect some properties and see what was going on, I was able to observe the framework readjust my content offset to be CGPointZero (which causes it to go behind the navigation bar). By checking for that condition, you can basically nullify the effect by resetting it immediately.

So once the UIWebView finished loading, I calculate the actual inset that I need based on the height of the navigation bar and the status bar.

- (void)webViewDidFinishLoad:(UIWebView *)webView {
    webView.scrollView.delegate = self;
    float inset = self.navigationController.navigationBar.bounds.size.height +
        [UIApplication sharedApplication].statusBarFrame.size.height;
    webView.scrollView.contentInset = UIEdgeInsetsMake(inset, 0.0, 0.0, 0.0);
}

Then whenever I detect a scroll, I just prevent the offset from canceling out my contentInset. I excluded this effect from when the user was zoomed so the document didn't jump around if the user happened to land on this boundary.

- (void)scrollViewDidScroll:(UIScrollView *)scrollView {
    if(scrollView.contentOffset.y == 0 && !scrollView.zooming)
        [scrollView setContentOffset:CGPointMake(0.0, -(scrollView.contentInset.top))];
}

The advantage here is that you don't need to depend on any timing elements, and you don't see the PDF jump around when the dispatch executes. The actual contentInset you need is also dynamically determined.
