How to make a charcoal drawing filter

Question

i'm interested in some kind of charcoal-filters like the photoshop Photocopy-Filter or the note-paper. Have someone a paper or some instructions how this filter works?

In best case i want to create the following:

input:

Output:

greetings

Answer 1

I think it's a process akin to pan-sharpening. I could get a quite similar image in gimp by:

• Converting to gray
• Duplicating into two layers
• Lightly blurring one layer
• Edge-detecting in the other layer with a DOG filter with large radius
• Compositing the two layers, playing a bit with the transparency.

Answer 2

What this is doing is converting the color picture into a 0-1 bitmap picture. They typically use a threshold function which returns 1 (white) for some values and 0 (black) for some other.

One simple function would be transform the image from color to gray-scale, and then select a shade of gray above which everything is white, and below it everything is black. The actual threshold you use could be made adaptive depending on the brightness of the picture (you want a certain percentage of pixels to be white).

It can also be adaptive based on the context within the picture (i.e. a dark area may still have some white pixels to show local contrast). The trees behind the house are not all black because the filtering is sensitive to the average darkness of the region.

Also note that the area close to the light gap in the tree has a cluster of dark pixels, because of its relative darkness. The edges of the home, the bench are also highlighted. There is an edge detection element at play.

Answer 3

I do not know exactly what effect you gave an example of but there are a variety that are similar to it. As VSOverFlow pointed out, thresholding an image would result in something very similar to that though I do not think it is what is being used. Open cv has a function for this, its documentation can be found here. You may also want to look into Otsu's method for thresholding.

Again as VSOverFlow pointed out, there is an edge detection element at play as well. You may want to investigate the Sobel and Prewitt filters. Those are 3 simple options that will give you something similar to the image you provided. Perhaps you could threshold the result from the Prewitt filter? I have no knowledge of how Photoshop implements its filters. If none of these options are close enough to what you are looking for I would recommend looking for information on the specific implementations of those filters in photoshop.
